- Page 1 WAFER GSM-CTL REMOTE CONTROL UNIT GSM-CTL MANUAL V5.0 From 2015 SHANGHAI WAFER MICROELECTRONICS CO.,LTD http://www.waferstar.com...
-
Page 2: Product Description
WAFER GSM-CTL REMOTE CONTROL UNIT GSM-CTL OPERATING INSTRUCTIONS PRODUCT DESCRIPTION WAFER GSM-CTL is an electronic board with an on-board GSM modem.The purpose of this device is to do the real time and interactive GSM remote control by means of a GSM phone. CONNECTOR DESCRIPTION... -
Page 3: Installation
You should install the GSM-CTL in a place where there is GSM signal coming from the operator you want to use. Check it with a phone before proceeding with the installation. If you need to install the device in a place with little signal, you may consider using an external antenna that we may supply as an option to be purchased separately with 50cm cable. - Page 4 The below wire picture is to show how to connect the cable to the PC program connector with the Program adapter.Please connect it in the right direction with the picture. The following compand is used in the GSM-CTL : #PWD:...
- Page 5 WAFER GSM-CTL REMOTE CONTROL UNIT #PWD123456#CAP333444#CAP333444 Acknowledge SMS: PWD SETUP OK If you wrote correctly, or an Error message if you made a mistake. If the old password is error,then conformation would be : Error Old Password If you input two different new password,then reply would be :...
- Page 6 WAFER GSM-CTL REMOTE CONTROL UNIT • To check which is the number in a place of the list: #PWD123456#WHL01? Acknowledge : WHL01 IS 61143815 OK • To erase a number: #PWD123456#WHL01=0000000 (or you can write over it another number you wish to add)
- Page 7 (PC$PHONE) This command is useful to see what is the GSM network signal level your GSM-CTL is receiving. It ranges from 0 to 32 (if it is 0 we doubt it will ever answer...). You should have a signal above 12 to be sure of being able to control the relay sets in any condition.
- Page 8 WAFER GSM-CTL REMOTE CONTROL UNIT Acknowledge: CSQ IS 26 #PWD123456#STATUS? Acknowledge: ACM=ON,REPLY=ON,RELAY=MODE0,GOT=3S, CSQ=20,OUT=0000000 Customized Text Command to control the OUTPUT: #PWD123456#OUT1-ON-TEXT:XXXX #PWD123456#OUT1-OFF-TEXT:XXXX #PWD123456#OUT1-ON-REPLY-TEXT:XXXX #PWD123456#OUT1-OFF-REPLY-TEXT:XXXX #PWD123456#OUT2-ON-TEXT:XXXX #PWD123456#OUT2-OFF-TEXT:XXXX #PWD123456#OUT2-ON-REPLY-TEXT:XXXX #PWD123456#OUT2-OFF-REPLY-TEXT:XXXX #PWD123456#RLY1-TEXT:XXXX #PWD123456#RLY1-REPLY-TEXT:XXXX #PWD123456#RLY2-TEXT:XXXX #PWD123456#RLY2-REPLY-TEXT:XXXX Text Command QUERY: #PWD123456#OUT-TEXT? (only for PC command)
- Page 9 WAFER GSM-CTL REMOTE CONTROL UNIT Reply would be as following data: ……… LOGS015:201501072143:18017370819:PHONE LOGS016:201501072143:18017370819:PHONE LOGS017:201501072141:18017370819:PHONE LOGS018:201501071937:+8613564121668:WSDRLY2=13 LOGS019:201501071937:+8613564121668:WSDRLY6=6 LOGS020:201501071937:+8613564121668:RLY3=8………. ………. (Normally don’t need to use and test the instruction) Program software: Please download from the product link: http://www.waferstar.com/en/GSM-CTL.html On board Reset:...
-
Page 10: Troubleshooting
· GSM Signal is not good and cann’t register to GSM,try to move to another place to test. · If still cann’t registered to the GSM net, try to contact wafer to get the technical support · When LED D6 is flashing slowly,try to call the SIM card,the calling status would be in busy. - Page 11 Power supply for the each load mustn’t exceed 30VDC/30A or 230VAC/30A Warning: GSM-CTL device is only working as a high power switch, don’t power the LOAD directly. This brochure provides an overview of the products and services of WEIFU GSM...
- Page 12 WAFER GSM-CTL REMOTE CONTROL UNIT Also accessible via our online skype service: wafer-service Copyright 2008, WEFU GSM V2015New V20111107 - Trouble shooting V20111126 - Relay connection example V20150101 – Customized command support V20150101 – ACM,REPLY function built-in http://www.waferstar.com...
