- Page 1 WAFER GSM-KEY REMOTE CONTROL UNIT GSM-KEY MANUAL AC200 VERSION 3.2 SHANGHAI WAFER MICROELECTRONICS CO.,LTD http://www.waferstar.com...
-
Page 2: Product Description
GSM-KEY OPERATING INSTRUCTIONS PRODUCT DESCRIPTION WAFER GSM-KEY is an electronic board with an on-board GSM modem.The purpose of this device is to open an electric gate by means of a GSM phone.It has a door open relay whose contact has to be connected in parallel with the button which opens the gate. It has a White List of regular user numbers who are enabled to open the phone, up to 200 and also it has up to 150 number for time zone. -
Page 3: Installation
WAFER GSM-KEY REMOTE CONTROL UNIT INSTALLATION !Note! Please read this entire manual before installation Take EXTREME care with the high voltage AC220V Power line installation In case of fault pull the mains adapter out from 220V network immediately. If device is connect into electricity, you couldn’t take off its cover. - Page 4 WAFER GSM-KEY REMOTE CONTROL UNIT WAFER GSM-KEY PROGRAMMING You can program the GSM-KEY with SMS commands using your phone. It is safe to do so because in addition to the fact that other people may not know the number of the SIM inserted in it, we also use a Password that makes it impossible for anybody who doesn't know it to access the system by chance.
- Page 5 WAFER GSM-KEY REMOTE CONTROL UNIT The following compand is used in the GSM-KEY : #PWD: Password #CAP: Change password #WHL: White List (add or remove numbers) #GOT: Gate pulse time #ALARM: Alarm information setting #MODE: Relay mode #CSQ: Check Signal Quality...
- Page 6 WAFER GSM-KEY REMOTE CONTROL UNIT #PWD123456#WHL001=61143815 Acknowledge would be : WHL001 SET TO 61143815 OK Where 01 is the position in the list and 61143815 is the number enabled. Please note that it is possible to program up to a maximum of 10 digits for a number. If it has more digits you should use the rightmost ones.
- Page 7 WAFER GSM-KEY REMOTE CONTROL UNIT Or #PWD123456#PHL001=0000 #PWD123456#QHL01=0000 (or you can write over it another number you wish to add) List All numbers in the List #PWD123456#SHL=ALL? (Instruction Only for Acknowledge SHL01 IS XXX SHL03 IS XXX QHL08 IS XXX ……...
- Page 8 WAFER GSM-KEY REMOTE CONTROL UNIT If at SMS mode: When receive the alarm input,then will send the SMS to the number in the alarm phone list until you send the SMS to PAUSE the alarm . In this instruction,that ALARM-IN1=ON:SMS:2,ALARM-IN2=ON:PHONE:3 That means that alarm1 signal would be triggered when the alarm1 is shorted to The alarm input1 and last to 2 seconds.
-
Page 9: Pc Software Interface
WAFER GSM-KEY REMOTE CONTROL UNIT PC Software interface: COM Port parameters config interface and connect to the device Before program the device through the PC,firstly you need to config the COM port paramters and then connect the device to PC software. - Page 10 WAFER GSM-KEY REMOTE CONTROL UNIT Special Phones Setting: Special phone number is used to setup the special number to control the device. It has three user mode: From Time to Time: Which days in a week and when can control the device.
- Page 11 WAFER GSM-KEY REMOTE CONTROL UNIT Alarm Phone Numbers Setting: That is used to setup the alarm phone number, when the alarm input is triggered ,then device would call the number or send the SMS to the number. Log Interface http://www.waferstar.com...
- Page 12 3. You can use the Relay Status selection box to check if that relay output can work well or not. 4. Battery backup function is not available on the normal Wafer products. http://www.waferstar.com...
-
Page 13: Troubleshooting
· GSM Signal is not good and cann’t register to GSM,try to move to another place to test. · If still cann’t registered to the GSM net, try to contact wafer to get the technical support · When LED D6 is flashing slowly,try to call the SIM card,the calling status would be in busy. - Page 14 WAFER GSM-KEY REMOTE CONTROL UNIT This brochure provides an overview of the products and services of WEIFU GSM Modules, For further information and queries kindly contact: Email: coinco_cn@yahoo.com.cn Web: www.waferstar.com Tel: 0086-21-51870528 Also accessible via our online MSN service: frank_ic2001@hotmail.com Copyright 2008, WEFU GSM V2011-V3.2...
