- Page 1 WAFER GSM-CTL-AC REMOTE CONTROL UNIT GSM-CTL-AC MANUAL SHANGHAI WAFER MICROELECTRONICS CO.,LTD http://www.waferstar.com...
-
Page 2: Product Description
GSM remote control by means of a GSM phone. GSM-CTL-AC is designed for the industrial remote control project. That can be used to switch on and off the power supply up to 6000W. -
Page 3: Installation
To maximise reception, install the GSM antenna in a prominent elevated position if possible, and vertically mounted. To install the GSM-CTL-AC, you need to power on the board with AC100V to 230V. and also connect the relay output according to your project. The relay contacts can stand 230V 30A maximum, this is enough for its operation but don't try to switch higher voltages or currents. - Page 4 2 seconds per time. You can program the GSM-CTL-AC with SMS commands using your phone. It is safe to do so because in addition to the fact that other people may not know the number of the SIM inserted in it, we also use a Password that makes it impossible for anybody who doesn't know it to access the system by chance.
- Page 5 WAFER GSM-CTL-AC REMOTE CONTROL UNIT The following compand is used in the GSM-CTL-AC : #PWD: Password #CAP: Change password #WHL: White List (add or remove numbers) #GOT: Relay working output delay time #ALARM: Alarm information setting #MODE: Relay mode #CSQ:...
- Page 6 WAFER GSM-CTL-AC REMOTE CONTROL UNIT Please note that it is possible to program up to a maximum of 10 digits for a number. If it has more digits you should use the rightmost ones. For example, if your number is 33446665555 you should program 3446665555.
- Page 7 #SCA Service center address If you want the GSM-CTL-AC to be able to send an SMS you should tell it what is the number of the SMS service center. Most of the times the unit answers anyway because it gets it from the SIM.
-
Page 8: Troubleshooting
· MCU is not working properly,Check the system power No tone can be heard after line off-hook · Check the telephone line connection. · GSM-CTL-AC is not initialized properly upon start (approx. 10s after power up). · GSM-CTL-AC is not supplied with power. GSM-CTL-AC reject the call immediately ·... - Page 9 WAFER GSM-CTL-AC REMOTE CONTROL UNIT Relay connection example to Output Driver The relay control outputs are suitable to control two different household and other devices as are air-conditioning and heating,connected directly or through external relay modules. Each relay output has NO , NC and COM contacts.
- Page 10 WAFER GSM-CTL-AC REMOTE CONTROL UNIT This brochure provides an overview of the products and services of WEIFU GSM Modules, For further information and queries kindly contact: Email: coinco_cn@yahoo.com.cn Web: www.waferstar.com Tel: 0086-21-51870528 Also accessible via our online MSN service: frank_ic2001@hotmail.com Copyright 2011, WEFU GSM V20111126-V1.4...
