- Page 1 WAFER GSM-RELAY REMOTE CONTROL UNIT GSM-RELAY MANUAL V5.0 From 2017 SHANGHAI WAFER MICROELECTRONICS CO.,LTD http://www.waferstar.com...
-
Page 2: Product Description
WAFER GSM-RELAY REMOTE CONTROL UNIT GSM-RELAY OPERATING INSTRUCTIONS PRODUCT DESCRIPTION WAFER GSM-RELAY is an electronic board with an on-board GSM modem.The purpose of this device is to do the real time and interactive GSM remote control by means of a GSM phone. CONNECTOR DESCRIPTION ADVANTAGES OF WAFER GSM-RELAY ˇ... -
Page 3: Installation
WAFER GSM-RELAY REMOTE CONTROL UNIT INSTALLATION To install the GSM-RELAY, you need to power on the board with AC/DC 9V-24V. and also connect the relay output according to your project. The relay contacts can stand 230V 10A maximum, this is enough for its operation but don't try to switch higher voltages or currents. - Page 4 WAFER GSM-RELAY REMOTE CONTROL UNIT The following compand is used in the GSM-RELAY : #PWD: Password #CAP: Change password #WHL: White List (add or remove numbers) #ACM: Safety control mode or free control mode #REPLY: When send the SMS to control,if need to reply the SMS...
- Page 5 WAFER GSM-RELAY REMOTE CONTROL UNIT #REPLY SMS reply enable or disable for relay output control command This command is used to save the cost for SMS reply when no need the SMS reply back #PWD123456#REPLY=ON or #PWD123456#REPLY=OFF When REPLY=OFF,then any relay output control text command would no confirmed SMS reply from controller,including the OUT, RLY and the Customized Text Command #WHL White List.
- Page 6 WAFER GSM-RELAY REMOTE CONTROL UNIT …… #QUERY White List. If you are not sure a number in the position of the device,you can use the SMS #PWD123456#QUERY=132324242 The device would answer the SMS with: QUERY RESULT: 132324242 AT WHL121 Or QUERY RESULT: 132324242 NOT EXIT #GOT Relay working output delay time.
- Page 7 #CSQ Check GSM signal quality. (PC$PHONE) This command is useful to see what is the GSM network signal level your GSM-RELAY is receiving. It ranges from 0 to 32 (if it is 0 we doubt it will ever answer...). You should have a signal above 12 to be sure of being able to control the relay sets in any condition.
- Page 8 WAFER GSM-RELAY REMOTE CONTROL UNIT Customized Text Command to control the OUTPUT: Customized command is user-friendly, and user can control the device with easy-to-understand SMS text,no need to remember the password and the Relatively difficult SMS instructions. For example if you setup: #PWD123456#OUT1-ON-TEXT:open1 then user only need to send the sms “...
- Page 9 WAFER GSM-RELAY REMOTE CONTROL UNIT OUT2-ON-REPLY-TEXT:WSD2ON OK OUT2-OFF-REPLY-TEXT:WSD2OFF OK OUT3-ON-REPLY-TEXT:WSD3ON OK OUT3-OFF-REPLY-TEXT:WSD3OFF OK OUT4-ON-REPLY-TEXT:WSD4ON OK OUT4-OFF-REPLY-TEXT:WSD4OFF OK OUT5-ON-REPLY-TEXT:WSD5ON OK OUT5-OFF-REPLY-TEXT:WSD5OFF OK OUT6-ON-REPLY-TEXT:WSD6ON OK OUT6-OFF-REPLY-TEXT:WSD6OFF OK OUT7-ON-REPLY-TEXT:WSD7ON OK OUT7-OFF-REPLY-TEXT:WSD7OFF OK PWD123456#RLY-TEXT? (only for PC command) RLY1-TEXT:WSDRLY1 RLY1-REPLY-TEXT:WSDRLY1 OK RLY2-TEXT:WSDRLY2 RLY2-REPLY-TEXT:WSDRLY2 OK...
- Page 10 · GSM Signal is not good and cann’t register to GSM,try to move to another place to test. · If still cann’t registered to the GSM net, try to contact wafer to get the technical support · When LED D6 is flashing slowly,try to call the SIM card,the calling status would be in busy.
- Page 11 Each relay output has NO and COM contacts. Note: Power supply for the each load mustn’t exceed 30VDC/10A or 230VAC/10A Warning: GSM-RELAY device only work as a high power switch, don’t power the LOAD directly. http://www.waferstar.com...
- Page 12 Also accessible via our online skype service: wafer-service Copyright 2008, WEFU GSM V2017New V20111107 - Trouble shooting V20111126 - Relay connection example V20150101 – Customized command support V20150101 – ACM,REPLY function built-in V20160801 – New GSM-RELAY and DTMF function built-in http://www.waferstar.com...
