ZURN AquaSense ZER-SM Series Installation, Operation, Maintenance And Parts Manual
Automatic battery-powered flush valve
Hide thumbs
Also See for AquaSense ZER-SM Series:
Advertisement
Quick Links
ZER6000-SM
Series
All goods sold hereunder are warranted to be free from defects in material and factory workmanship for a period of three years from the date of
purchase. Decorative finishes warranted for one year. We will replace at no costs goods that prove defective provided we are notified in writing of
such defect and the goods are returned to us prepaid at Sanford, NC, with evidence that they have been properly maintained and used in accordance
with instructions. We shall not be responsible for any labor charges or any loss, injury or damages whatsoever, including incidental or consequential
damages. The sole and exclusive remedy shall be limited to the replacement of the defective goods. Before installation and use, the purchaser shall
determine the suitability of the product for his intended use and the purchaser assumes all risk and liability whatever in connection therewith. Where
permitted by law, the implied warranty of merchantability is expressly excluded. If the products sold hereunder are "consumer products," the implied
warranty of merchantability is limited to a period of three years and shall be limited solely to the replacement of the defective goods. All weights stated
in our catalogs and lists are approximate and are not guaranteed.
WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov
!
ADVERTENCIA: Cáncer y Daño Reproductivo - www.P65Warnings.ca.gov
!
AVERTISSEMENT: Cancer et effet nocif sur la reproduction - www.P65Warnings.ca.gov
!
Rev. B | Date: 04/27/23 | C.N. No. 145288 | Prod./Dwg. No. FV828
Patent zurn.com/patents
US 1.855.ONE.ZURN CANADA 1.877.892.5216
ZURN.COM
AquaSense
ZER-SM Series
Automatic Battery-Powered
Flush Valve
Installation, Operation, Maintenance
and Parts Manual
ZER6003-SM
Series
LIMITED WARRANTY
®
ZER6200-SM
Series
ZER6203-SM
Series
Advertisement
Related Manuals for ZURN AquaSense ZER-SM Series
Summary of Contents for ZURN AquaSense ZER-SM Series
- Page 1 WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov ADVERTENCIA: Cáncer y Daño Reproductivo - www.P65Warnings.ca.gov AVERTISSEMENT: Cancer et effet nocif sur la reproduction - www.P65Warnings.ca.gov Rev. B | Date: 04/27/23 | C.N. No. 145288 | Prod./Dwg. No. FV828 Patent zurn.com/patents US 1.855.ONE.ZURN CANADA 1.877.892.5216 ZURN.COM...
- Page 2 This Page Intentionally Left Blank...
-
Page 3: Specifications
35°F to 104°F [2°C to 40°C] Important Safety Information • Do not convert or modify this Zurn product. All warranties will be voided. • All plumbing is to be installed in accordance with applicable codes and regulations. • Water supply lines must be sized to provide an adequate volume of water for each fixture. -
Page 4: Package Contents
Package Contents Control Stop with Vandal Cap Diaphragm Piston E-Z Flush (Optional with Aqua Flush) Valve Body Valve Body ® Sweat solder Connection with Cast Wall Escutcheon E-Z Flush Hex Key Wrench Vacuum Breaker Vacuum Breaker and Valve and Spud and Spud Gasket Connection for... - Page 5 Sweat Solder Adapter Installation NOTE: Before installation, turn off water supplies to existing fixture and remove flushometer if replacing an existing device. 1. Measure distance from finished wall to the center line of the fixture 2. Slide threaded sweat solder adapter onto water supply pipe until spud.
- Page 6 Flush Valve Installation Prior to attaching flush valve tailpiece to control stop, inspect and Control Stop verify that the O-ring seal is located within the O-ring groove at the tailpiece. Ensure that the locking nut and locking snap ring O-Ring Groove are also present on the tailpiece.
- Page 7 Flushing the System When all flush valves are connected to the fixtures and water pressure is available, it is recommended that the supply piping be Body Cover flushed to remove dirt, pipe chips, etc., from system. Use the following procedure to flush out the supply piping: Plastic Cover 1.
- Page 8 Each E-Z Flush comes calibrated from the factory to work optimally in most restroom environments. In low light or highly reflective envi- ronments however, it may be necessary to adjust the calibration distance of an E-Z Flush unit. To do this, a Zurn Magic Magnet may be used.
- Page 9 Flush Valve Trouble Shooting Guide PROBLEM CAUSE SOLUTION User LED continuously blinks every Low battery life. Replace batteries. five seconds. Insufficient flow of water. Stop Valve improperly adjusted. Adjust stop valve (open). Excessive flow of water. Stop Valve improperly adjusted. Adjust stop valve (close).
- Page 10 ZER-SM Series Parts Breakdown FV828 Rev. B 04/27/23 Page 8...
- Page 11 Part Identification 1. Valve Cup Seal 16. Vacuum Breaker Tube Nut 31. Piston 2. Valve Gasket 17. Spud Nut 32. Stop Spring 3. Metal Cover, Lens, Electronics Assembly 18. Spud Friction Washer 33. Guide O-Ring 4. Sensor Lens 19. Spud Sleeve 34.
