Table 2. Elements of the PSU (see Fig. 3).
Element no.

1.4. Specifications:

- electrical specifications (tab.3)
- mechanical specifications (tab.4)
- operation safety (tab.5)
- operating specifications (tab. 6)
Table 3. Electrical specifications.
PSU type
Mains supply
Current consumption
PSU power
Output voltage
Isolation transformer
Pcb of the PSU (Tab. 1, Fig. 2)
TAMPER; micro switch of tamper protection (NC)
L-N 230V/AC power supply connector,
F fuse in the battery circuit 230V, T315mA / 250V
MAIN
Battery connectors +BAT = red, - BAT = black
Fig. 3. The view of the PSU.
AWZ110
Description
PE protection connector
A (EPS - External Power Source),
protection class 1÷2, II environmental class
230V AC / 50Hz (-15%/+10%)
0,16 A @230V AC
14 W
11V÷ 13,8V DC – buffer operation
10V÷ 13,8V DC – battery-assisted operation
5
GREY POWER plus
