Tempest GP27Q (GP27-FQS)
Cooler Master 27" Gaming Monitor
User Manual
1

Advertisement

Table of Contents
loading

Summary of Contents for Cooler Master Tempest GP27Q

  • Page 1 Tempest GP27Q (GP27-FQS) Cooler Master 27" Gaming Monitor User Manual...
  • Page 2: Table Of Contents

    Table of Contents Requirements and Safety Notice ��������������������������������������������������������������������������������������������������1 Important Safety Instructions ��������������������������������������������������������������������������������������������������������3 Package Contents ������������������������������������������������������������������������������������������������������������������������4 Installing the Monitor Stand and Base ������������������������������������������������������������������������������������������5 Adjusting the Monitor ��������������������������������������������������������������������������������������������������������������������7 Wall Mount Installation Instructions ����������������������������������������������������������������������������������������������8 External Control Buttons���������������������������������������������������������������������������������������������������������������9 Main Menu ����������������������������������������������������������������������������������������������������������������������������������10 [Input Select] ������������������������������������������������������������������������������������������������������������������������������������������������� 10 [Picture Setting] ��������������������������������������������������������������������������������������������������������������������������������������������...
  • Page 3: Requirements And Safety Notice

    ● If assistance is needed, contact the distributor or a professional radio/TV technician� CE Compliance Statement Cooler Master Technology Inc� hereby declares that the monitor conforms to the following key standards and other related provisions: EMC Directive 2014/30/EU, Low Voltage Directive 2014/35/EU, RoHS Directive 2011/65/EU and Directive 2009/125/EC establishing a framework for the setting of eco-design requirements for energy-related products�...
  • Page 5: Important Safety Instructions

    Important Safety Instructions Please read the following instructions carefully� 1� To clean the LCD monitor screen: Turn off the LCD monitor and unplug the power cord� Spray a non-solvent cleaning solution onto a rag and clean the screen gently� 2� Do not place the LCD monitor near a window� Exposing the monitor to rain, moisture or sunlight can severely damage it�...
  • Page 6: Package Contents

    Package Contents Monitor Stand Base Power cord (Optional) HDMI cable (Optional) DP cable (Optional) Cable clip Base screw Type C cable (Optional) (Used for fixing cables on the (Used for installing the base back of the stand) and stand) USB Type A to B cable (Optional) Adapter (PC and Monitor data transmission)
  • Page 7: Installing The Monitor Stand And Base

    Installing the Monitor Stand and Base...
  • Page 8 USB1 USB2 USB-UP Type C...
  • Page 9: Adjusting The Monitor

    Adjusting the Monitor ● For the best results, it is recommended to look directly at the front of the monitor and make any adjusts as necessary� ● Ensure that the monitor is mounted upright on the stand base� ● When adjusting the monitor viewing angles, avoid touching the screen and hold the stand in order to prevent it from falling over�...
  • Page 10: Wall Mount Installation Instructions

    Wall Mount Installation Instructions VESA: 100 x 100 mm Screws M4 x 10 mm...
  • Page 11: External Control Buttons

    External Control Buttons Menu/Navi/OK button Short press to turn on the monitor and Long press to turn off� When the OSD menu is activated, pull up/down/left/right the button to adjust the settings you need� When finished, you can pull the Button Back to return to the previous level or use the Button Exit to close the OSD menu�...
  • Page 12: Main Menu

    Main Menu [Input Select] Sync Off HDR Off OD Off 2560 1440 × Input Select Type-C Picture Setting Color Adjust HDMI 2 Gaming Setup HDMI 1 Advanced System MOVE BACK ENTER ● Enter the Input Select menu to switch the input signal� ■...
  • Page 13: [Color Adjust]

    [Color Adjust] Sync Off HDR Off OD Off 2560 1440 × Input Select Color Temperature Native Picture Setting Gamma Color Adjust 6-axis Color Gaming Setup Color Domain Auto Advanced Color Space Auto System Blue Light Filter MOVE BACK ENTER ● Enter the Color Adjust menu to adjust the color mode� ■...
  • Page 14: [Advanced]

    [Advanced] Sync Off HDR Off OD Off 2560 1440 × Input Select Picture Setting Local Dimming Color Adjust HDMI Range Auto Gaming Setup USB Off Advanced RGB Light System Move BACK ENTER ● Enter the Advanced Setting menu to select the advanced mode� ■...
  • Page 15: Specifications

    Specifications Size 27” Pixel pitch 0�2331(H) x 0�2331(V)mm Brightness 600 nits (Typ�) LCD panel Contrast 1000:1 (Typ�) Viewing angle 178°(Horizontal) 178°(Vertical) Response time 1 ms** Display colors 1�07 billion colors 2560×1440@144 Hz (HDMI) Maximum display frequency (Resolution H * V/Fv) 2560×1440@165 Hz (DP &...
  • Page 16: Supported Timing

    Supported Timing [PC Timing] Port Frame Pixel H� Frequency Mode Resolution Rate Clock HDMI1 HDMI2 Type-C (kHz) DP1 Input (Hz) (MHz) Input Input Input 640×480@59Hz 31�463 59�9286 25�17 31�5 25�2 640×480@60Hz 27�788 59�9286 25�17 640×480@67Hz 33�438 66�6086 26�75 640×480@72Hz 37�861 72�8088 31�5 640×480@75Hz...
  • Page 17 Port Frame Pixel H� Frequency Mode Resolution Rate Clock HDMI1 HDMI2 Type-C (kHz) DP1 Input (Hz) (MHz) Input Input Input 1152×864@60Hz 88�787 95�9506 241�5 1152×864@75Hz 67�5 1152×864@100Hz 148�099 99�9995 402�83 1152×864@120Hz 178�784 119�989 486�29 1152×864@144Hz 213�264 580�08 1152×864@165Hz 244�364 164�999 664�67 1152×872@60Hz 88�787...
  • Page 18 Port Frame Pixel H� Frequency Mode Resolution Rate Clock HDMI1 HDMI2 Type-C (kHz) DP1 Input (Hz) (MHz) Input Input Input 1440×900@60Hz 55�935 59�8874 106�50 182�997 119�998 497�75 1440×900@120Hz 178�784 119�989 486�29 1440×900@144Hz 213�264 580�08 1440×900@165Hz 244�364 164�999 664�67 1600×900@60Hz 1600×900@100Hz 148�099 99�9995 402�83...
  • Page 19 Port Frame Pixel H� Frequency Mode Resolution Rate Clock HDMI1 HDMI2 Type-C (kHz) DP1 Input (Hz) (MHz) Input Input Input 159�976 143�993 332�75 1920×1080@144Hz 213�264 580�08 1920×1080@165Hz 244�364 164�999 664�67 1920×1200@60Hz 88�787 59�9506 241�5 1920×1200@100Hz 148�099 99�9995 402�83 182�997 119�998 497�75 1920×1200@120Hz 178�784...
  • Page 20: [Video Timing]

    [Video Timing] Video Aspect Field Rate Horizontal Vertical Pixel Clock Formats H-Total V-Total ID Code Ratio (Hz) (kHz) (Hz) (MHz) 59�94 31�469 59�94 25�175 640x480p 31�500 60�00 25�200 720x480p 31�469 59�94 27�000 720x480p 16:9 31�469 27�000 59�94 44�955 59�94 74�176 1650 1280x720p 16:9...
  • Page 21: Product Outline Dimensions

    Product Outline Dimensions -5°~20° 110mm ��° ��° ° °...
