Terms
P Peak value display
Piping-port size
PNP (open collector) output
Power saving mode
Pressure-sensing part
Pressure setting
Proof pressure
R
Rated pressure range
Repeatability
Residual voltage
Resolution
Response time
Reversed output
Ripple
S
Sampling cycle
Setting of function
Setting pressure range
Stainless steel diaphragm
Switch output
T
TSJ fitting
U
URJ fitting
Units selection function
W Wetted part
(or part exposed to fluid)
Window comparator mode
Withstand voltage
Z Zero clear function
Displays the maximum pressure reached up to that moment.
The size of the port on the switch body with which a device can be connected.
The switch output that uses the PNP transistor for output.
The condition in which the display is turned off to reduce current consumption.
The pressure-detecting part of a pressure-detecting element.
The setting of pressure to determine the point at which the Pressure switch turns
on and off.
The pressure beyond which the Pressure switch will be damaged.
The pressure range in which the Pressure switch meets the specifications.
Values outside of this range can be set if they are within the set pressure range,
but cannot be guaranteed to meet the product specifications.
Reproducibility of the displayed value for pressure and ON-OFF output operating
point when the pressure changes.
The difference between the ideal ON voltage and the actual voltage when the
switch output is on. It depends on present load current and ideally should be "0"..
Refer to "Indication resolution".
The elapsed time until the ON-OFF output begins operating, since the pressure
supplied to the Pressure switch has reached the set value. Generally, the shorter
the response time, the better the performance.
The switch output operation in which the switch is turned on when pressure
equal to or less than the set value is detected. In the (hysteresis mode) window
comparator mode, it indicates the operation in which a switch is turned on when
pressure is outside the switch output range (n1L to n1H or n2L to n2H).
(Refer to "List of output modes" on page 26).
A type of chattering.
The frequency in which the detected pressure should be reflected to the digital
display.
Refer to "Function selection mode".
The pressure range within which the switch output can be set.
A stainless steel pressure-detecting part of the pressure-detecting element. It is
suitable for measuring fluid such as water.
Alternatively called "ON-OFF output".
Abbreviation for Tube Swage Joint. The recommended fitting is Swagelok fitting
made by Swagelok.
Abbreviation for Union Ring Joint. The recommended fitting is VCR fitting made
by Swagelok.
Function to change the unit in which the value of pressure is displayed. Only a
product with this function can change the unit. A product with Units selection
function cannot be purchased if it is used within Japan. Pressure is indicated only
by SI units in Japan.
The part of the Pressure switch which is in contact with the detected fluid, such
as a pressure sensor, seal, or fitting.
An output type which holds the output when the pressure is within a certain
range. (Refer to "List of output modes" on page 26).
The ability to withstand a voltage applied between an electrical circuit and the
body. If more voltage is applied to the product, the product may be damaged.
(voltage mentioned here is not power voltage to activate the product).
The function which can adjust the displayed pressure value to "0".
