- Page 1 GITRÈ LN GITRÈ B/100 LN GITRÈ LN EN USER MANUAL...
- Page 2 GITRÈ LN boiler. Please accept our renewed thanks for your purchase. Riello S.p.A. CONFORMITY GITRÈ LN boilers conform to the following directives: − Directive 92/42/EEC on efficiency requirements −...
-
Page 3: Table Of Contents
CONTENTS 1 GENERAL INFORMATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4 General Safety Information . -
Page 4: General Information
GENERAL INFORMATION GENERAL INFORMATION 1.2 Precautions The operation of any appliance that uses fuel, electrical power 1.1 General Safety Information and water demands that a number of fundamental safety pre- cautions be respected: This product must be installed by a legally qualified heat- Do not allow children or infirm persons to operate the sys- ing engineer. -
Page 5: Description Of The Appliance
GENERAL INFORMATION 1.3 Description of the appliance 1.5 System layout The GITRÈ LN boiler is an oil fuelled hot water boiler capable GITRÈ LN of low temperature functioning. GITRÈ LN versions are designed only for central heating applications. The GITRÈ B/100 LN version is equipped with a 100 litre vitrified storage cylinder and can be used for central heating and domestic hot water production. - Page 6 GENERAL INFORMATION GITRÈ B/100 LN Control panel Burner Storage cylinder drain cock 12 Boiler body CH circuit drain cock 13 Flue gas diaphragm Automatic vent valve 14 Flue gas exhaust fitting Storage cylinder 15 Domestic cold water inlet Casing 16 DHW circulation Non-return valve 17 Storage cylinder temperature sensor socket Boiler circulator...
-
Page 7: Control Panel
GENERAL INFORMATION 1.6 Control panel GITRÈ LN Function selector Remote burner reset Boiler temperature gauge Displays the temperature of the central heating water Boiler thermostat Allows you to set the temperature of the central heating water (setting range 55-82°C) Electrical power indicator (green) Lights to show that the boiler is receiving electrical power Burner lockout indicator (red) Lights to show that the burner locked out... - Page 8 GENERAL INFORMATION GITRÈ B/100 LN Function selector Remote burner reset Boiler temperature gauge Displays the temperature of the central heating water Boiler thermostat Allows you to set the temperature of the central heating water (setting range 55-82°C) Electrical power indicator (green) Lights to show that the boiler is receiving electrical power Burner lockout indicator (red) Lights to show that the burner locked out...
-
Page 9: Use
2 USE − Open the control panel access door; 2.1 Putting into service Have the Technical Assistance Service start up your GITRÈ LN boiler for the first time. Once this has been done, the boiler can be left to function automatically. Under certain circumstances, such as after long periods of dis- use, the user may need to re-start it without involving the Tech- nical Assistance Service. -
Page 10: Ignition Failure
− Set the room thermostat to the required temperature (~ − turn the function selector to (I) ON and make sure that 20°C) or, if the system has a timer or timer-thermostat, the green power indicator lights. make sure that this is switched “ON” and adjusted to the required temperature (~ 20°C).;... -
Page 11: Temporary Shutdown
Proceed as follows to reset the safety thermostat: Then proceed as follows: − Wait until boiler temperature falls below 80°C; − Adjust the boiler thermostat to its minimum setting; − Open the control panel cover; − Unscrew the cap over the safety thermostat reset button; −... -
Page 12: Preparing For Extended Periods Of Disuse
2.3 Preparing for extended periods of disuse 2.4 Cleaning and servicing the boiler If the boiler is not going to be used for an extended period of Please remember that THE PERSON RESPONSIBLE FOR SYSTEM MAN- time, proceed as follows to prepare it for shut-down AGEMENT MUST ENSURE THAT PROFESSIONALLY QUALIFIED HEATING −... -
Page 13: Troubleshooting
2.6 Troubleshooting FAULT CAUSE SOLUTION − Contact your local Technical Assistance The boiler does not reach its tempera- Problem with boiler control thermostat Service ture setpoint − Check the temperature setting − Contact your local Technical Assistance Problem with boiler control thermostat Service The generator triggers a thermal safety block... -
Page 14: Recycling And Disposal
RECYCLING AND DISPOSAL ONLY FOR GITRÈ B/100 LN MODELS FAULT CAUSE SOLUTION − Contact your local Technical Assistance Storage cylinder safety valve Service The storage cylinder safety valve keeps − Contact your local Technical Assistance Incorrect DHW circuit pressure opening Service −... - Page 15 RECYCLING AND DISPOSAL...
- Page 16 RIELLO S.p.A. 37045 Legnago (VR) - Italy Tel. 0442630111 - Fax 044222378 - www.riello.it The manufacturer strives to continuously improve all products. Appearance, dimensions, technical specifications, standard equipment and accessories are therefore liable to modification without notice.
