The AN-X module contains a webserver capable of communicating with standard web
browsers such as Internet Explorer.
Use the web interface to:
•
Configure the AN-X, either by autoconfiguration or manually
•
Transfer configuration files to and from the AN-X
•
View the results of the last configuration
•
Monitor I/O and Ethernet diagnostic counters
•
Configure the Ethernet settings and select the firmware to run
•
Archive the AN-X configuration
•
Update the AN-X firmware
•
Restart the AN-X
•
View AN-X logs
It also contains contact information for support.
To use the web interface, you must know the IP address of the AN-X.
To access the web interface, start your web browser and type the AN-X IP address where
you normally enter web addresses in the browser.
The left pane contains commands. Click on the arrows at the left of the main headings to
expand or contract the sections.
