18
Page AN-X2-MOD-MON
Keyword
IP
Netmask
DefGtwy
Hostname
Firmware
If you edit the file and AN-X2 finds an error during startup, it flashes an error code on the
MS LED, see page 55.
Example config.txt files
Example: Link- Local IP address
IP: LOCAL
Hostname: ANX2Mod
Firmware: AN-X2-MOD-MON
Example: DHCP
IP: DHCP
Hostname: ANX2Mod
Firmware: AN-X2-MOD-MON
Example: static IP address
IP: 192.168.1.14
NetMask: 255.255.255.0
DefGtwy: 192.168.1.1
HostName: ANX2Mod
Firmware: AN-X2-MOD-MON

If the link-local address is not accessible...

Addresses 169.254.1.0 to 169.254.254.255 are reserved for use on a local network.
AN-X2 modules are shipped set to the address 169.254.42.84 for initial configuration.
This address is almost always accessible from a computer on the same local Ethernet as
the AN-X.
If you cannot access the AN-X2 at address 169.254.42.84 using a web browser, there are
two options for setting the AN-X Ethernet parameters.
Possible Values
LOCAL
DHCP
static IP address
Ethernet netmask, used only if IP is a static IP address
default gateway, used only if IP is a static IP address
Ethernet host name, from 1 to 30 characters
Firmware file to run at startup, must be present on microSD card
May 2016
