Quick Start - QTS AN-X2-MOD-MON User Manual

Step Operation
1 Power up the AN-X, connect it to Ethernet and assign an
IP address
2 Connect AN-X to the Modicon S908 network
3 Use the web interface to autoconfigure the AN-X from
the attached Modicon network
4 Configure the AN-X in RSLogix 5000
5 Monitor I/O, read inputs and write outputs
6 Use the web interface to create aliases for RSLogix 5000
7 Import the aliases into RSLogix 5000
8 Use the aliases to access the Modicon I/O
9 Create your application using the aliases
13
AN-X2-MOD-MON Page

Quick Start

See page
14
11
21
27
38
38
