25
AN-X2-MOD-MON Page
CfgLen=1,0x1191
Refer to the document AN-X-MOD-Parameters supplied with the AN-X for detailed
information about parameters for specific Quantum modules.
Drop Hold Time
The drop hold time is sent to a drop to tell it how long it should wait before timing out if
it hasn't received a packet from the scanner. The units are 100 ms. The value can range
from from 1 to 65535. The default is 3 = 300 ms.
Each time the drop gets a packet from the scanner, it sets the timeout to the drop hold
time. If the timeout reaches 0, the drop times out.
The drop hold time is what the drop does, not what the scanner does! If the drop goes
offline, the scanner sets the bit in the drop error table immediately.
AN-X captures the drop hold time for a drop and adds a line immediately after the drop
definition that consists of the keyword HoldTime, an equals sign, and the value.
Example:
Drop=1,
HoldTime=3

Sending and Retrieving Configurations

To transfer an S908 configuration file to the AN-X2-MOD-MON, first select Automation
Network/Modicon S908 I/O Network Configuration in the web interface.
Click the Browse button and select the file, then click the Send File to AN-X button to
transfer the configuration.
To transfer a configuration from the AN-X2-MOD-MON, first select Automation
Network/View Configuration Files in the web interface.
Right click on AN-X2-MOD-MON RIO Network Configuration File and select save link
as and save the file on your computer.
