QTS AN-X2-MOD-MON User Manual page 35

Rack
Slot 1 2 3 4
1 0L 0H 1L 1H
2 8L 8H 9L 9H
3 16L 16H 17L 17H
4 24L 24H 25L 25H
To map the module status data for a given Quantum drop, include a line with the keyword
dnModSts, where n is the drop number, from 1 to 32, and the length of the module status
data, in 16-bit words, in the input section of a connection.
The length must be large enough to include all modules in the configuration. For
example, if the last module is in rack 1 slot 3, the size must be at least 2.
If the length is omitted, AN-X uses a default length of 10. If a length of 10 is not large
enough to include all modules in the drop, AN-X generates an error when you download
the configuratuion to the AN-X.
If you omit the offset, the line must start with a comma.
Examples:
,d4ModSts,17
30, d4ModSts ; offset 30
Connection Statistics
The module maintains statistics for each exclusive owner scheduled connection. In the
following table, O represents the connection originator (ControlLogix) and T represents
the connection target (AN-X).
There are 10 words of connection statistics data for each connection, of which three are
used.
Offset Description
0 Average update time, average of last 32 updates
1 Reserved
2 Minimum update time since last reset of statistics
3 Reserved
4 Maximum update time since last reset of statistics
5 Reserved
6 Reserved
7 Reserved
Location
5 6 7 8 9 10
2L 2H 3L 3H 4L 4H
10L 10H 11L 11H 12L 12H
18L 18H 19L 19H 20L 20H
26L 26H 27L 27H 28L 28H
AN-X2-MOD-MON Page
11 12 13 14 15 16
5L 5H 6L 6H 7L 7H
13L 13H 14L 14H 15L 15H
21L 21H 22L 22H 23L 23H
29L 29H 30L 30H 31L 31H
35
Offset
Offset
Offset
Offset
