9. APPLICATION EXAMPLE – SYNCHRONOUS BOOST CONVERTER
This section shows how to set up the SpeedVal Kit platform to run as a synchronous boost converter.
Figure 47 shows the SpeedVal Kit platform outfitted with the optional control board to supply the PWM
pulses and the buck/boost filter board. An external function generator could have been used instead of
the control board.
Table 8 shows the parameters for the test. The load for this test was a combination of an electronic and
resistive load. It is advised to always include some fixed resistive load when running in boost
configurations. This prevents the output voltage from increasing to dangerous levels if an
electronic load were to shut off unexpectedly.
PRD-06829 REV. 1, December 2022
© 2022 Wolfspeed, Inc. All rights reserved. Wolfspeed® and the Wolfstreak logo are registered trademarks and the
SpeedVal Kit™ and Wolfspeed logo is a trademark of Wolfspeed, Inc. Other trademarks, product and company names
are the property of their respective owners and do not imply specific product and/or vendor endorsement,
sponsorship or association.
Items
Parameters
Input Voltage
200 V
Output Voltage
≈385 V
Output
11.7 A
Output Power
4560 W
Switching
66 khz
Duty Cycle
48.5%
Deadtime
200 ns
Inductor
450 uF
Output
48 uf
Input
48 uf
Upper MOSFET C3M0045065J1
Lower MOSFET C3M0045065J1
T
8: T
C
ABLE
EST
ONDITIONS
SpeedVal Kit™ Half-Bridge User Guide
48
