- Page 1 Charge Amps Aura The Electric Vehicles (Smart Charge Points) Regulation 2021 Installation English Manual Charge Amps Aura 131293 Charge Amps Aura 131294 www.chargeamps.com...
-
Page 2: Table Of Contents
Before installation Recommended tools Materials provided by installer Mounting requirements Electric requirements 4.4.1 Short circuit safety 4.4.2 Residual current safety Internet access 4.5.1 Wi-Fi 4.5.2 4G-LTE 4.5.3 4.5.4 Network daisy chain of Charge Amps Aura Installation Mounting Connection 5.2.1 Cable connection... - Page 3 English Before configuration Configuration Connect via Charge Amps Aura Wi-Fi access point Connect via LAN Connect via 4G-LTE Local management interface settings 7.4.1 Electrical installation settings 7.4.2 RFID management for offline chargers Configuration in the Fuuse Charge Point Management platform 7.5.1...
- Page 4 Neglecting to follow and carry out the directions, instructions and safety precautions in this Installation Manual implies that any warranty provisions will be cancelled and that Charge Amps can reject any and all claims for compensation in connection with any injuries/damage or incidents – direct or indirect –...
-
Page 5: Safety
• The product must only be installed or opened by a qualified electrician in accordance with the Installation Manual. • Charge Amps Aura complies with the device-level requirements set out under the Electric Vehicles (Smart Charge Point) Regulations 2021, as detailed in the technical file, which is available online. - Page 6 English • Do not immerse the product in water, subject it to physical abuse or insert foreign objects in any part of the product. • Never attempt to disassemble the product in any way other then what is described in the Installation Manual. •...
-
Page 7: Technical Data
English 2 Technical data Charging mode Mode 3 EV power supply identifier Metering 1 to 3 phase voltage, current and power Socket Type 2, up to 2x22 kW Rated voltage (U 230/400 V Rated insulation voltage (U 250/400 V Rated impulse withstand voltage 4 kV Rated operational voltage (U 230/400 V... - Page 8 English Pollution degree Electromagnetic compatibility Environment B Operating temperatures -35°C to +45°C Altitude 0 m to 2000 m IP code IP55 IK code IK10 Mechanical resistance High Dimensions (W x D x H) 367 x 159 x 405 mm Weight 10 kg Characteristics of power supply and AC EV supply equipment connected...
- Page 9 English RFID Type: ISO/IEC 14443 Typ A 13.56MHz Mifare Range: 13.553 – 13.567 MHz Output: 31 dBm Wi-Fi Type: 802.11 b/g/n Range: 2400 – 2500 MHz Max output: 20/17/14 dBm@802.11 b/g/n Communication protocol OCPP 1.6J Cellular netoworks communication Type: GSM, GPRS, EDGE, UMTS/ HSPA+, LTE (only applies to 131293).
-
Page 10: Product Overview
English 3 Product overview RFID reader Cylinder lock RFID light Back cover EV socket Front cover Socket light Cable slide: data and power cable in/out... -
Page 11: Package Contents
English 3.1 Package contents Cable slide Cable fitting Plugs M32 insert Screws RFID tag Cylinder key Wago jumper... - Page 12 English Charge Amps Aura Accessories: • Cable slide • Cable fitting for power (M32): 13 - 17.5 mm and 17 - 25 mm • Cable fitting for data (M12): 4 -8 mm • Plugs for non-used cover entries. • M32 insert only •...
-
Page 13: Before Installation
English 4 Before installation N.B: This Installation Manual is only applicable to Charge Amps Aura with product number 131293 and 131294. 4.1 Recommended tools • 3.5 mm flat head screwdriver • Drill • Multimeter • Laser/spirit level • Wire stripper for cabling •... -
Page 14: Mounting Requirements
English 4.3 Mounting requirements • If possible, do not mount the Charge Amps Aura in direct sunlight. • Make sure the wall can support a weight of 10 kg and the tractive force from the inserted cabling. • Do not install Charge Amps Aura in confined spaces. -
Page 15: Electric Requirements
Cables must not be passed through the rear housing. 4.4.1 Short circuit safety Make sure the installation for Charge Amps Aura is properly fused up to 63 A with one of the following: • B- or C-curve MCB* with energy limiting class 3. -
Page 16: Internet Access
Charge Amps Aura. 4.5.1 Wi-Fi Once the power is switched on, Charge Amps Aura will provide a Wi-Fi access point which is available for 10 minutes. Use the Wi-Fi access point to connect Charge Amps Aura to the Wi-Fi network of the facility. -
Page 17: Lte
The Charge Amps Aura 4G-LTE model comes with the 4G-LTE modem connected to one of the RJ45 ports on the main card. Once the power is on, and a SIM card is inserted, Charge Amps Aura will automatically connect to the 4G-LTE network. -
Page 18: Installation
N.B: Mounting shall only be performed by an qualified electrician. 1. Unpack Charge Amps Aura. Make sure that Charge Amps Aura is in a good condition and that all cables are properly seated. Do not place the face plate directly on to the ground. - Page 19 English 3. Unlock the cylinder lock. Rotate the front cover upwards and suspend the front. 4. Remove the cable slide by unscrewing the two M6 screws.
- Page 20 English 5. Attach the cable fittings for power and data (NOTE: cable fitting for data is only applicable for Charge Amps Aura with LAN connection). Important! Make sure to cover non used cable entries with suitable plugs from the accessories.
- Page 21 English 7. Align Charge Amps Aura to the wall and mount.
-
Page 22: Connection
• Cable connection: L1, L2, L3, N, PE. The WAGO terminals are designed for a cable area of 2.5 to 16 mm². • Make sure the incoming cabling is dimensioned to connect the Charge Amps Aura. 5.2.1 Cable connection N.B: Only insert the power cable through the specific cable entry. - Page 23 English 3. For TN/TT network connection, connect the conductors to the terminal block: TN/TT - single installation TN/TT - daisy chain installation...
- Page 24 English 4. For IT network connection, connect the conductors to the terminal block using the provided Wago jumper (MPN: 2016- 433). NOTE: The Wago jumper should be placed between L2 and N. IT - single installation...
- Page 25 English IT - daisy installation...
- Page 26 English 5. Once the cables are connected to the teminal block, minimize the risk of squeezing any cables by making sure no cables are sticking out above the red dotted line.
- Page 27 For 4G-LTE connection: insert the SIM card into the SIM card holder and make sure the modem is connected to the RJ45 port. N.B: Only applicable for Charge Amps Aura with LAN connection or Charge Amps Aura with 4G-LTE connection. LAN connection...
- Page 28 English 5.3 Reassemble 1. Once the cables are installed, make sure that the RCDs and the MCB are turned on. 2. Make sure that none of the internal cables that are highlighted below were disconnected during installation and make sure the connectors are fully inserted in their sockets.
-
Page 29: Before Configuration
Before starting the configuration, make sure you have access to: • The serial number for Charge Amps Aura. • The PIN code for Charge Amps Aura, which can be found in the documentation included in the packaging. N.B: Make sure to store and keep the PIN code safe for later... -
Page 30: Connect Via Charge Amps Aura Wi-Fi Access Point
N.B: The Charge Amps Aura Wi-Fi access point is deactivated if one of the RJ45 ports is actively connected. Once the power is switched on, Charge Amps Aura will provide a Wi-Fi access point which is available for 10 minutes. Connect to... -
Page 31: Connect Via Lan
N.B: It is possible to daisy chain the LAN connection using the two RJ45 ports of Charge Amps Aura. 1. Make sure that Charge Amps Aura is connected to the local network via an ethernet cable in the RJ45 port. -
Page 32: Local Management Interface Settings
When the Charge Amps Aura is connected to a cloud service as the charge point management system, all RFID management is handled in the cloud. If the Charge Amps Aura is to be operated offline, without a connection to a cloud service, management of RFID tags can be handled locally in the local management interface. -
Page 33: Configuration In The Fuuse Charge Point Management Platform
English 7.5 Configuration in the Fuuse Charge Point Management platform Once Charge Amps Aura is connected to the internet and configured in the local management interface, it will automatically connect to the OCPP endpoint of the Fuuse platform. Once connected, adding and registration of Charge Amps Aura inside the Fuuse platform is required. -
Page 34: Adding Chargers As A New Fuuse Admin User
1. Open a window in your web browser and enter: app.fuuse.io 2. Use your credentials to log into the Fuuse web portal. 3. When logged in, register and configure the installation of Charge Amps Aura by following the steps in this guide: • https://support.fuuse.io/knowledge/creating-a-new-charging- site 7.5.3 Adding drivers in the Fuuse web portal... -
Page 35: Set Up And Enable Rfid Payment In The Fuuse Web Portal
N.B: For Charge Amps Aura 131293 with a 4G-LTE modem, make sure to first disconnect the modem from the RJ45 port inside Charge Amps Aura to be able to reach the local management interface and re-set the OCPP endpoint. 1. Turn on Charge Amps Aura. - Page 36 English 4. When asked, enter the PIN code of Charge Amps Aura as ”Network key”. 5. Once connected, open a new window in the network browser on the same device. Enter ”192.168.250.1” in the address field to reach the local management interface.
- Page 37 English 7. Once logged in, press the ”Wi-Fi” tab to connect Charge Amps Aura to the internet.
- Page 38 English 8. Enter following details and press ”Update”: • Network name of the local Wi-Fi network (SSID). • Password for the Wi-Fi network.
- Page 39 9. Once logged in, click the ”OCPP” tab and enter following in the field: • wss://hw.fuuse.io:9999/ 10. Press ”Update” to save the settings. 11. Reboot the Charge Amps Aura. You will now be able to manage your Charge Amps Aura via your Fuuse account.
-
Page 40: Complete The Installation
Electric Vehicle (Smart Charge Point) Regulations 2021, a tamper evident label should be applied upon completion of the installation of Charge Amps Aura. This is to provide the end user with the possibility to detect any attempts of breaching the tamper- protection. -
Page 41: Handover And Training
8.2 Handover and training To comply with the Electric Vehicle (Smart Charge Point) Regulations 2021, the installer must: • Ensure that the charging schedule of Charge Amps Aura is set in accordance with the Electric Vehicle (Smart Charge Point) Regulations 2021. -
Page 42: Use
English 9 Use N.B: If Charge Amps Aura is connected to other Charge Point Management Platforms, please refer to your provider for inquiries about portals and apps. When connecting Charge Amps Aura to Fuuse Charge Point Management Platform, please use following portals and apps for configuration and operation of Charge Amps Aura. -
Page 43: Dismounting
The power supply to the charger must be isolated before dismounting starts. 1. Perform a factory reset of Charge Amps Aura before powering it down. Contact the supplier before performing this action. 2. Turn the power off at the main switch. -
Page 44: Preventative Maintenance
1. For questions related to the cloud service, contact Fuuse Charge Point Management Platform support: • ChargeAmps@fuuse.io 2. If you need service or repair, start by contacting the supplier from whom you purchased the product. 3. For additional information, visit Charge Amps Help Center at www.chargeamps.com/support. -
Page 45: Warranty
English 13 Warranty Warranty terms may differ from market to market. Contact your supplier regarding the warranty terms. - Page 46 Charge Amps AB (publ) Frösundaleden 2B, 8th floor SE–169 75 Solna, Sweden Charge Amps UK Ltd 4th Floor, 3 More London Riverside London SE1 2AQ, United Kingdom Doc. Nr: 131342 © Copyright Charge Amps AB. Rev: 01 All rights reserved...
