Riello 3473784 Installation, Use And Maintenance Instructions
Riello 3473784 Installation, Use And Maintenance Instructions

Riello 3473784 Installation, Use And Maintenance Instructions

Pressure jet burner

Advertisement

Quick Links

Installation, use and maintenance instructions
Pressure jet burner
CODE
MODEL
TYPE
3473784
PRESS GW
605 T80
2915897 (2) - 08/2012

Advertisement

loading
Need help?

Need help?

Do you have a question about the 3473784 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Riello 3473784

  • Page 1 Installation, use and maintenance instructions Pressure jet burner CODE MODEL TYPE 3473784 PRESS GW 605 T80 2915897 (2) - 08/2012...
  • Page 3 Thermal power 107 / 178 - 350 kW - 92.000 / 153.000 - 301.000 kcal/h Output 9/15 - 30 kg/h Fuel Gas oil, max. viscosity at 20 °C: 6 mm /s (1.5 °E) Electrical supply Single-phase 220V +10% -10% ~ 60Hz Motor 1.85 A / 220V Capacitor...
  • Page 4 PRESSURE IN THE COMBUSTION CHAMBER - OUTPUT (in compliance with DIN 4787) Burner output kg/h The burner is drawn for on-off operation and high-low operation. Minimum firing-rate at on-off operation is 15 kg/h (two nozzles) and 9 kg/h (one nozzle) with high-low operation. DIMENSIONS OF THE TEST COMBUSTION-CHAMBER (DIN 4787) D = Boiler diameter in mm P = Position of the mobile...
  • Page 5: Hydraulic System

    HYDRAULIC SYSTEM Gravity feed from the bottom of the oil storage tank The dimension P should not exceed 10 m, to avoid breakage of pump seals. L meters meters I.D. 8 mm I.D. 10 mm Gravity feed over the top of the oil storage tank The dimension P should not exceed 10 m, to avoid breakage of pump seals.
  • Page 6 BURNER ELECTRICAL WIRING (carried out by the factory) 2463 KEY TO LAYOUT Capacitor Ignition transformer Photocell Burner ground (earth) connection Wiring terminal block stage solenoid valve Fan motor stage solenoid valve Control box 5897...
  • Page 7 ELECTRICAL CONNECTIONS TO THE WIRING TERMINAL BLOCK (to be carried out by the installer) 2646 KEY TO LAYOUT Remote lock - out signal Limit control device system Wiring terminal block High - low mode control device system Lock - out reset button Safety control device system Burner ground (earth) connection NOTICE...
  • Page 8 FIXING OF THE ELECTRICAL WIRES All the electrical wires, which are to be connected to the terminal block 6) (fig. 1) shall pass through the fair leads 8) (fig. 1) as per this scheme. 1 - Single phase supply: fair lead Pg 13.5 2 - Adjustment thermostat: fair lead Pg 13.5 3 - Safety thermostat:...
  • Page 9: Burner Adjustment

    BURNER ADJUSTMENT Establish, on the basis of the output desired, and in accordance with the table and the diagram underneath: - the type of nozzle; - the pump pressure; - the combustion head setting. EXAMPLE The burner has to be matched with a boiler of 210 kW. Assuming an efficiency of 90%, we need to develop approximately 233 kW i.e.
  • Page 10 (3) The indicated outputs are drawn from the average statistical data of our tests. Real output may well vary by ± 5%. (4) The rear level of the control-shaft (7) (fig. 1) must line-up with the set-point number, indicated by the diagram. In the sketch on the right, the shaft is shown, in the position required by the example on page 7.
  • Page 11 All burner controls are clearly indicated into the instruction. Only the air damper adjustment for the second flame, is determined at the place of installation, depending on the boiler pressure. ATTENTION At the first ignition, passing from the first to the second flame, the oil pressure decrease noticeably because of the filling of the second nozzle line - this decreasing can cause the burner shutdown, sometimes with strong pulsations.
  • Page 12: Burner Start-Up Cycle Diagnostics

    PRIMING THE PUMP In case of a gravity feed system, from the bottom of the oil-storage tank (see page 3), loosen the screw of the suc- tion-gauge fixing point 3 (fig. 1), until the fuel flows out. In the other two cases, remove the high voltage cable from the ignition transformer and release air from the pressure gauge fixing point, by loosening the screw 4 (fig.
  • Page 13: Operating Fault Diagnostics

    OPERATING FAULT DIAGNOSTICS The control box has a self-diagnostic system, which easily allows identifying the operating faults (RED LED signal). ITo use this function, wait at least ten seconds from the safety lock out, and then press the reset button for a minimum of 3 sec- onds.
  • Page 16 RIELLO S.p.A. I-37045 Legnago (VR) Tel.: +39.0442.630111 http:// www.riello.it http:// www.rielloburners.com Subject to modifications...
