Installation, use and maintenance instructions
Pressure jet burner
CODE
MODE
TYPE
3475982
PRESS 3G
608 T80
2915903 (1) - 05/2010

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PRESS 3G and is the answer not in the manual?

Questions and answers

Related Manuals for Riello PRESS 3G

Summary of Contents for Riello PRESS 3G

  • Page 1 Installation, use and maintenance instructions Pressure jet burner CODE MODE TYPE 3475982 PRESS 3G 608 T80 2915903 (1) - 05/2010...
  • Page 2 Thermal power 273 / 534 - 1186 kW - 234.800 / 459.200 - 1.020.000 kcal/h Output 23 / 45 - 100 kg/h Fuel Gas oil, max. viscosity at 20 °C: 6mm /s (1.5 °E) Three-phase 220V +10% -10% ~ 60Hz without neutral Electrical supply 380V +10% -10% ~ 60Hz with neutral Motor...
  • Page 3 PRESSURE IN THE COMBUSTION CHAMBER - OUTPUT (in compliance with DIN 4787) Burner output kg/h The burner is drawn for on-off operation and high-low operation. Minimum firing-rate at on-off operation is 45 kg/h (two nozzles) and 23 kg/h (one nozzle) with high-low operation. DIMENSIONS OF THE TEST COMBUSTION-CHAMBER (DIN 4787) D = Boiler diameter in mm P = Position of the mobile...

  • Page 4: Hydraulic System

    HYDRAULIC SYSTEM Gravity feed from the bottom of the oil storage tank The dimension P should not exceed 10 m, to avoid breakage of pump seals. L meters meters I.D. 10 mm I.D. 12 mm Gravity feed over the top of the oil storage tank The dimension P should not exceed 10 m, to avoid breakage of pump seals.
  • Page 5 BURNER ELECTRICAL WIRING (carried out by the factory) 2464 KEY TO LAYOUT Fan motor contact - maker Thermal cutout Photocell Ignition transformer Wiring terminal block Burner ground (earth) connection Fan motor stage solenoid valve Control box stage solenoid valve 5903...
  • Page 6 ELECTRICAL CONNECTIONS TO THE WIRING TERMINAL BLOCK (to be carried out by the installer) 2647 220V 380V F Ampere S mm KEY TO LAYOUT Remote lock - out signal Limit control device system Wiring terminal block High - low mode control device system Lock - out reset button Safety control device system Burner ground (earth) connection...
  • Page 7 FIXING OF THE ELECTRICAL WIRES All the electrical wires, which are to be connected to the terminal block 6) (fig. 1) shall pass through the fair leads 8) (fig. 1) as per this scheme. 1 - Three phase supply: fair lead Pg 21 2 - Single phase supply: fair lead Pg 13.5 3 - Adjustment thermostat:...

  • Page 8: Burner Adjustment

    BURNER ADJUSTMENT Establish, on the basis of the output desired, and in accordance with the table and the diagram underneath: - the type of nozzle; - the pump pressure; - the combustion head setting. EXAMPLE The burner has to be matched with a boiler of 700 kW. Assuming an efficiency of 90%, we need to develop approximately 778 kW i.e.

  • Page 9: Air Damper Adjustment

    (3) The indicated outputs are drawn from the average statistical data of our tests. Real output may well vary by ± 5%. (4) The rear level of the control-shaft (7) (fig. 1) must line-up with the set-point number, indicated by the diagram. In the sketch on the right, the shaft is shown, in the position required by the example on page 7.

  • Page 10: Priming The Pump

    All burner controls are clearly indicated into the instruction. Only the air damper adjustment for the second flame, is determined at the place of installation, depending on the boiler pressure. ATTENTION At the first ignition, passing from the first to the second flame, the oil pressure decrease noticeably because of the filling of the second nozzle line - this decreasing can cause the burner shutdown, sometimes with strong pulsantions.

  • Page 11: Burner Start-Up Cycle Diagnostics

    BURNER START-UP CYCLE DIAGNOSTICS During start-up, indication is according to the followin table: COLOUR CODE TABLE Sequences Colour code Pre-purging Ignition phase Operation, flame ok Operating with weak flame signal Electrical supply lower than ~ 170V Lock-out Extraneous light Yellow Green Key: OPERATING FAULT DIAGNOSTICS...
  • Page 12 RIELLO S.p.A. I-37045 Legnago (VR) Tel.: +39.0442.630111 http:// www.riello.it http:// www.rielloburners.com Subject to modifications...
