Electric Screwdriver
VZ Series
Operation Manual
(September 2020)
Transformerless Screwdriver
100V
VZ-1510/VZ-1510PS
VZ-1812/VZ-1812PS
VZ-1820/VZ-1820PS/VZ-3012/VZ-3012PS/
VZ-3007/VZ-3007PS
VZ-4506/VZ-4506PS with Shockless Stand
120V
VZ-1820/VZ-1820PS/VZ-3012/VZ-3012PS/
VZ-4506/VZ-4506PS
220-240V
VZ-1812/VZ-1812PS/VZ-3007/VZ-3007PS/
VZ-4504/VZ-4504PS
ET-A003 20A
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for HIOS VZ-1510
Summary of Contents for HIOS VZ-1510
- Page 1 Electric Screwdriver VZ Series Operation Manual (September 2020) Transformerless Screwdriver 100V VZ-1510/VZ-1510PS VZ-1812/VZ-1812PS VZ-1820/VZ-1820PS/VZ-3012/VZ-3012PS/ VZ-3007/VZ-3007PS VZ-4506/VZ-4506PS with Shockless Stand 120V VZ-1820/VZ-1820PS/VZ-3012/VZ-3012PS/ VZ-4506/VZ-4506PS 220-240V VZ-1812/VZ-1812PS/VZ-3007/VZ-3007PS/ VZ-4504/VZ-4504PS ET-A003 20A...
- Page 2 SAVE THESE INSTRUCTIONS We thank you for your purchase of Hios Electric Screw Driver. WARNING When using electric tools, basic safety precautions should always be followed to reduce the risk of fire, electric shock and personal injury, including the following: READ ALL INSTRUCTIONS 1.
- Page 3 10. Dress Properly. Do not wear loose clothing or jewelry. They can be caught moving parts. Wear protective hair covering to contain long hair. 11. Use Safety Glasses. Also use face or dust mask if operation is dusty. 12. Don't Abuse Cord. Never carry tool by cord or yank it to disconnect from receptacle.
- Page 4 TABLE 1 MINIMUM GAGE FOR CORD SETS Volts Total Length of Cord in Feet 120V 0 - 25 26 - 50 51 - 100 101 - 150 240V 0 - 50 51 - 100 101 - 200 201 - 300 Ampere Rating More Not More...
-
Page 5: Grounding Instructions
GROUNDING INSTRUCTIONS The tool should be grounded while in use to protect the operator from electric shock. The tool is equipped with a three-conductor cord and three- prong grounding-type plug to fit the proper grounding-type receptacle. The green (or green and yellow) conductor in the cord is the grounding wire. -
Page 6: Cautions In Operation
Please use this tool with caution, as Carpal Tunnel Syndrome (CTS) or other trauma disorders may result. HIOS shock-Resistant Stand is available to absorb the torque to the operator's hand during operation. SUMMARY This VZ Series Screw Driver is a Control Function Built-in Type. - Page 7 ■ Specifications *: Numeric data in ( ) is weight of push-to-start driver. - 7 -...
- Page 8 - 8 -...
- Page 9 - 9 -...
-
Page 10: Parts Name
• Torque adjusting spring (for VZ-1510, VZ-1510PS) • Carbon brushes • Screw for adjustment M 2.6 (Phillips screw) for VZ-1812, VZ- 1812PS, VZ-1820, VZ-1820PS, VZ-3007, VZ-3007PS, VZ-3012, VZ-3012PS • 3PIN to 2PIN power cable adaptor is attached (for VZ-1510, VZ-1510PS) - 10 -... -
Page 11: How To Use
HOW TO USE ■ OPERATION 1. Insert the Bit into the Joint Shaft Collar of the Screwdriver. 2. Turn the Torque Adjusting Nut and adjust the tightening torque. 3. Make sure the Forward/Off/Reverse Switch is in the "OFF" position. 4. Insert the AC Plug into the AC socket. 5. - Page 12 (5HEX). Take note of the following precautions when using the hexagonal bit. • Always use our standard HIOS shank type bits H4 and H5. ■ Types of driver bits that can be used with the VZ- 1812, VZ-1820, VZ-3007 and VZ-3012 series...
- Page 13 (Caution) 5mm wide Hexagonal Bit When using the 5 mm wide Hexagonal W Bit, tighten 5mm wide the Phillips adjustment screw (supplied screw) 14mm tightly into the driver bit chuck. * If the Phillips adjustment screw is not tightened for enough, the driver bit will not be locked and may result in unreliable screw fastening.
- Page 14 Torque adjusting nut strongly fasten the Nut fixing ring by holding the Torque adjusting nut. ■ We recommend to use the HIOS Torque meter Tools to set the torque of Screw Driver or to check the torque of screw. (HP, HDP series) •...
- Page 15 • Be careful so as not to tighten the Carbon Brush Cap too strongly. Concave ■ List carbon brushes and compatible screwdriver (1 pair = 2pcs) Applicable models Oder Cord VZ-1510 VZ-1820, VZ-3012, VZ-3007, VZ-4506 (including PS type) (including PS type) ACL10-0490 VZ18-0480 - 15 -...
- Page 16 ■ Approximate Guidance of Output Torque VZ-1510 VZ-1510PS · N·m Torque Adjustment Scale (Upper edge of Nut) 1 2 3 4 5 6 7 Torque Scale VZ-1820 VZ-3012 VZ-1820PS VZ-3012PS 1 2 3 4 5 6 7 8 9 10...
- Page 17 VZ-1812 VZ-3007 VZ-1812PS VZ-3007PS 1 2 3 4 5 6 7 8 9 10 1 2 3 4 5 6 7 8 9 10 Torque Scale Torque Scale - 17 -...
- Page 20 HIOS Inc. 1-35-1 Oshiage, Sumida-ku Tokyo, Japan 131-0045 TEL: 81-3-6661-8821 FAX: 81-3-6661-8828...
