Icom IC-7300 Service Manual page 7

October 2016
[MAIN UNIT]
REF PART
NO. NO.
C669 4030019990 S.CER C1005 JB 1C 104K-T
C670 4030017650 S.CER C1005 CH 1H 270J-T
C671 4030019990 S.CER C1005 JB 1C 104K-T
C672 4030019560 S.CER GRM21BB31C106KE15L
C673 4030019560 S.CER GRM21BB31C106KE15L
C674 4030019560 S.CER GRM21BB31C106KE15L
C675 4030019120 S.CER GRM188B31E105KA75D
C676 4030019990 S.CER C1005 JB 1C 104K-T
C681 4030019990 S.CER C1005 JB 1C 104K-T
C682 4030019560 S.CER GRM21BB31C106KE15L
C683 4030019560 S.CER GRM21BB31C106KE15L
C692 4030017460 S.CER C1005 JB 1H 102K-T
4030017460 S.CER C1005 JB 1H 102K-T
4030017460 S.CER C1005 JB 1H 102K-T
C693 4030017620 S.CER C1005 CH 1H 100C-T
C695 4030019990 S.CER C1005 JB 1C 104K-T
C701 4030019990 S.CER C1005 JB 1C 104K-T
C720 4510010570 S.ELE 16 CE 470 LX
C721 4510010570 S.ELE 16 CE 470 LX
C722 4030019120 S.CER GRM188B31E105KA75D
C723 4030019620 S.CER GRM188B31C225KE14D
C724 4030017400 S.CER C1005 CH 1H 220J-T
C725 4030019990 S.CER C1005 JB 1C 104K-T
C726 4030019560 S.CER GRM21BB31C106KE15L
C727 4030019620 S.CER GRM188B31C225KE14D
C728 4030019570 S.CER C1608 CH 1H 332J-T
C731 4030020020 S.CER C1005 CH 1H 391J-T
C732 4030021340 S.CER C1608 JB 1H 474KT ATEX
C733 4030019990 S.CER C1005 JB 1C 104K-T
C734 4030021530 S.CER C1608 JB 1E 224K-T
C735 4030021530 S.CER C1608 JB 1E 224K-T
C741 4510010570 S.ELE 16 CE 470 LX
C746 4030019120 S.CER GRM188B31E105KA75D
C747 4030019990 S.CER C1005 JB 1C 104K-T
C751 4510010570 S.ELE 16 CE 470 LX
C752 4030017430 S.CER C1005 CH 1H 101J-T
C753 4030016790 S.CER C1005 JB 1E 103K-T
C754 4030016790 S.CER C1005 JB 1E 103K-T
C761 4030017460 S.CER C1005 JB 1H 102K-T
C762 4030017460 S.CER C1005 JB 1H 102K-T
C763 4030017460 S.CER C1005 JB 1H 102K-T
C764 4030017460 S.CER C1005 JB 1H 102K-T
C771 4030016790 S.CER C1005 JB 1E 103K-T
C773 4030016790 S.CER C1005 JB 1E 103K-T
C774 4030016790 S.CER C1005 JB 1E 103K-T
C775 4030016790 S.CER C1005 JB 1E 103K-T
C776 4030016790 S.CER C1005 JB 1E 103K-T
C778 4030016790 S.CER C1005 JB 1E 103K-T
C779 4030016790 S.CER C1005 JB 1E 103K-T
C780 4030016790 S.CER C1005 JB 1E 103K-T
C781 4030016790 S.CER C1005 JB 1E 103K-T
C782 4030017460 S.CER C1005 JB 1H 102K-T
C783 4030016790 S.CER C1005 JB 1E 103K-T
C791 4030019990 S.CER C1005 JB 1C 104K-T
C801 4030016790 S.CER C1005 JB 1E 103K-T
C811 4030019620 S.CER GRM188B31C225KE14D
C812 4030019620 S.CER GRM188B31C225KE14D
C901 4030017400 S.CER C1005 CH 1H 220J-T
C902 4550007200 S.TAN F930J476MBABMA
C903 4550007200 S.TAN F930J476MBABMA
C904 4030017400 S.CER C1005 CH 1H 220J-T
C905 4030019990 S.CER C1005 JB 1C 104K-T
C906 4030019990 S.CER C1005 JB 1C 104K-T
C907 4030019990 S.CER C1005 JB 1C 104K-T
C908 4030019990 S.CER C1005 JB 1C 104K-T
C909 4030019990 S.CER C1005 JB 1C 104K-T
C910 4030019990 S.CER C1005 JB 1C 104K-T
C911 4030019990 S.CER C1005 JB 1C 104K-T
C912 4030019990 S.CER C1005 JB 1C 104K-T
C913 4030019990 S.CER C1005 JB 1C 104K-T
C914 4030019990 S.CER C1005 JB 1C 104K-T
C915 4030019990 S.CER C1005 JB 1C 104K-T
C916 4030016790 S.CER C1005 JB 1E 103K-T
C917 4550007200 S.TAN F930J476MBABMA
C918 4550007200 S.TAN F930J476MBABMA
C919 4030019990 S.CER C1005 JB 1C 104K-T
C920 4030019990 S.CER C1005 JB 1C 104K-T
C921 4030019990 S.CER C1005 JB 1C 104K-T
C922 4030019990 S.CER C1005 JB 1C 104K-T
C923 4030019990 S.CER C1005 JB 1C 104K-T
C924 4030019990 S.CER C1005 JB 1C 104K-T
C925 4030019990 S.CER C1005 JB 1C 104K-T
C926 4030019990 S.CER C1005 JB 1C 104K-T
C927 4030019990 S.CER C1005 JB 1C 104K-T
C928 4030019990 S.CER C1005 JB 1C 104K-T
C929 4030019990 S.CER C1005 JB 1C 104K-T
C930 4030019990 S.CER C1005 JB 1C 104K-T
C931 4030019990 S.CER C1005 JB 1C 104K-T
C932 4030019990 S.CER C1005 JB 1C 104K-T
C933 4030019990 S.CER C1005 JB 1C 104K-T
C934 4030019990 S.CER C1005 JB 1C 104K-T
C935 4030019990 S.CER C1005 JB 1C 104K-T
C936 4550007200 S.TAN F930J476MBABMA
C937 4550007200 S.TAN F930J476MBABMA
C938 4030019990 S.CER C1005 JB 1C 104K-T
C939 4550007200 S.TAN F930J476MBABMA
C940 4030019990 S.CER C1005 JB 1C 104K-T
C941 4030019990 S.CER C1005 JB 1C 104K-T
C942 4030019990 S.CER C1005 JB 1C 104K-T
C943 4030019990 S.CER C1005 JB 1C 104K-T
C944 4030019990 S.CER C1005 JB 1C 104K-T
C945 4030019990 S.CER C1005 JB 1C 104K-T
C946 4030019990 S.CER C1005 JB 1C 104K-T
C947 4030019990 S.CER C1005 JB 1C 104K-T
Eqv.= This component is equivalent to the REF No. component listed above,
and may be substituted on parts orders and repairs.
DESCRIPTION M.
LOCATION
T 49.6/151.0
T 55.8/144.9
T 52.2/145.5
T 50.8/144.1
T 50.8/142.3
T 48.4/147.7
T 49.3/157.4
T 51.5/159.3
T 38.7/148.9
T 42.9/147.4
T 37.1/150.7
[#03] T 68.4/185.8
[#05]
[#06]
T 68.4/183.7
T 17.5/157.6
T 16.2/173.5
T 73.9/173.4
T 80.5/144.5
T 93.7/156.5
T 90.2/157.6
T 96.7/165.0
T 90.3/161.4
T 95.2/160.2
T 91.4/162.7
T 94.0/162.7
T 96.6/157.0
T 96.6/162.7
T 96.9/160.1
T 96.6/163.9
T 111.5/169.4
T 107.5/146.7
T 105.5/169.4
T 100.4/167.9
T 98.5/173.0
T 104.7/177.0
T 104.7/175.0
T 89.2/176.5
T 92.3/169.6
T 92.3/170.9
T 92.3/172.2
T 92.3/173.1
T 25.3/173.0
T 33.0/168.0
T 27.1/171.8
T 27.1/179.0
T 27.0/180.0
T 52.6/178.2
T 27.0/181.0
T 27.0/185.0
T 52.3/183.6
T 52.3/182.6
T 27.0/187.0
T 25.3/174.3
T 29.1/163.5
T 50.5/180.7
T 51.8/180.7
T 109.2/66.1
T 102.7/58.1
T 99.4/56.0
T 106.8/68.7
T 102.8/61.4
T 102.8/69.6
T 102.8/70.8
T 102.8/72.2
T 102.8/74.0
T 102.8/74.9
T 102.8/75.8
T 102.8/77.6
T 102.8/78.8
T 102.8/81.3
T 102.8/64.8
T 102.8/65.8
T 104.7/91.5
T 104.6/87.9
T 96.2/58.0
T 97.1/87.7
T 95.3/88.6
T 92.4/57.6
T 91.4/87.7
T 89.8/57.6
T 88.1/87.3
T 86.8/57.6
T 85.9/87.7
T 84.9/87.7
T 84.4/57.6
T 82.4/87.7
T 82.3/57.8
T 79.9/87.7
T 78.8/57.6
T 77.4/57.6
T 77.4/87.7
T 70.0/63.4
T 76.9/55.2
T 107.4/84.7
T 67.6/71.8
T 72.4/62.3
T 72.4/65.3
T 72.4/67.3
T 72.4/68.3
T 72.4/70.3
T 72.4/71.3
T 72.4/72.3
T 72.4/73.3
(Amended page)
[MAIN UNIT]
H/V REF PART
NO. NO.
C948 4030019990 S.CER C1005 JB 1C 104K-T
C949 4030019990 S.CER C1005 JB 1C 104K-T
C950 4030019990 S.CER C1005 JB 1C 104K-T
C951 4030019990 S.CER C1005 JB 1C 104K-T
C952 4030019990 S.CER C1005 JB 1C 104K-T
C953 4030019990 S.CER C1005 JB 1C 104K-T
C954 4550007200 S.TAN
C955 4030017430 S.CER C1005 CH 1H 101J-T
C961 4030019620 S.CER GRM188B31C225KE14D
C962 4030019620 S.CER GRM188B31C225KE14D
C971 4030019560 S.CER GRM21BB31C106KE15L
C972 4030019990 S.CER C1005 JB 1C 104K-T
C973 4030019560 S.CER GRM21BB31C106KE15L
C974 4030017700 S.CER C1005 CH 1H 151J-T
C975 4030017700 S.CER C1005 CH 1H 151J-T
C976 4030019990 S.CER C1005 JB 1C 104K-T
C977 4030019990 S.CER C1005 JB 1C 104K-T
C981 4030019990 S.CER C1005 JB 1C 104K-T
C991 4030019560 S.CER GRM21BB31C106KE15L
C992 4030019990 S.CER C1005 JB 1C 104K-T
C993 4030019560 S.CER GRM21BB31C106KE15L
C994 4030019560 S.CER GRM21BB31C106KE15L
C995 4030019570 S.CER C1608 CH 1H 332J-T
C996 4030019570 S.CER C1608 CH 1H 332J-T
C997 4030019990 S.CER C1005 JB 1C 104K-T
C998 4030019990 S.CER C1005 JB 1C 104K-T
C999 4030017700 S.CER C1005 CH 1H 151J-T
C1000 4030020980 S.CER C1005 CH 1H 821JT
C1001 4030019560 S.CER GRM21BB31C106KE15L
C1002 4030019560 S.CER GRM21BB31C106KE15L
C1003 4030019990 S.CER C1005 JB 1C 104K-T
C1004 4030019560 S.CER GRM21BB31C106KE15L
C1005 4030019990 S.CER C1005 JB 1C 104K-T
C1006 4030019990 S.CER C1005 JB 1C 104K-T
C1007 4030019560 S.CER GRM21BB31C106KE15L
C1008 4030019560 S.CER GRM21BB31C106KE15L
C1009 4030019560 S.CER GRM21BB31C106KE15L
C1010 4030019620 S.CER GRM188B31C225KE14D
C1011 4030019620 S.CER GRM188B31C225KE14D
C1012 4030017690 S.CER C1005 CH 1H 121J-T
C1013 4030017440 S.CER C1005 CH 1H 221J-T
C1014 4030019990 S.CER C1005 JB 1C 104K-T
C1015 4030019560 S.CER GRM21BB31C106KE15L
C1016 4030019620 S.CER GRM188B31C225KE14D
C1017 4510010570 S.ELE
C1018 4030019560 S.CER GRM21BB31C106KE15L
C1019 4030019990 S.CER C1005 JB 1C 104K-T
C1020 4030019560 S.CER GRM21BB31C106KE15L
C1021 4030017420 S.CER C1005 CH 1H 470J-T
C1022 4030017420 S.CER C1005 CH 1H 470J-T
C1023 4030017420 S.CER C1005 CH 1H 470J-T
C1024 4030017420 S.CER C1005 CH 1H 470J-T
C1025 4030017420 S.CER C1005 CH 1H 470J-T
C1201 4030016790 S.CER C1005 JB 1E 103K-T
C1202 4030019990 S.CER C1005 JB 1C 104K-T
C1203 4030017460 S.CER C1005 JB 1H 102K-T
C1204 4030019990 S.CER C1005 JB 1C 104K-T
C1205 4030017460 S.CER C1005 JB 1H 102K-T
C1206 4030017600 S.CER C1005 CH 1H 080C-T
C1207 4030016790 S.CER C1005 JB 1E 103K-T
C1208 4030017530 S.CER C1005 CH 1H 0R5B-T
C1209 4030016790 S.CER C1005 JB 1E 103K-T
C1211 4030017460 S.CER C1005 JB 1H 102K-T
C1212 4030019990 S.CER C1005 JB 1C 104K-T
C1213 4030016790 S.CER C1005 JB 1E 103K-T
C1220 4030019620 S.CER GRM188B31C225KE14D
C1221 4030019990 S.CER C1005 JB 1C 104K-T
C1222 4030017460 S.CER C1005 JB 1H 102K-T
C1223 4030017460 S.CER C1005 JB 1H 102K-T
C1224 4030017460 S.CER C1005 JB 1H 102K-T
C1231 4030019990 S.CER C1005 JB 1C 104K-T
C1232 4030019990 S.CER C1005 JB 1C 104K-T
C1233 4030019990 S.CER C1005 JB 1C 104K-T
C1235 4030019990 S.CER C1005 JB 1C 104K-T
C1236 4030019990 S.CER C1005 JB 1C 104K-T
C1237 4030019990 S.CER C1005 JB 1C 104K-T
C1241 4030019620 S.CER GRM188B31C225KE14D
C1242 4030019620 S.CER GRM188B31C225KE14D
C1251 4030019990 S.CER C1005 JB 1C 104K-T
C1252 4030019990 S.CER C1005 JB 1C 104K-T
C1253 4030019990 S.CER C1005 JB 1C 104K-T
C1254 4030019990 S.CER C1005 JB 1C 104K-T
C1255 4030019990 S.CER C1005 JB 1C 104K-T
C1256 4030019990 S.CER C1005 JB 1C 104K-T
C1261 4030019990 S.CER C1005 JB 1C 104K-T
C1262 4030019990 S.CER C1005 JB 1C 104K-T
C1263 4030017460 S.CER C1005 JB 1H 102K-T
C1266 4030017460 S.CER C1005 JB 1H 102K-T
C1267 4030017460 S.CER C1005 JB 1H 102K-T
C1268 4030019990 S.CER C1005 JB 1C 104K-T
C1269 4030019990 S.CER C1005 JB 1C 104K-T
C1270 4030019560 S.CER GRM21BB31C106KE15L
C1273 4030017460 S.CER C1005 JB 1H 102K-T
C1274 4030017460 S.CER C1005 JB 1H 102K-T
C1277 4030017420 S.CER C1005 CH 1H 470J-T
C1278 4030019990 S.CER C1005 JB 1C 104K-T
C1279 4030019990 S.CER C1005 JB 1C 104K-T
C1281 4030017660 S.CER C1005 CH 1H 330J-T
C1283 4030017680 S.CER C1005 CH 1H 820J-T
C1285 4030017660 S.CER C1005 CH 1H 330J-T
C1294 4030019560 S.CER GRM21BB31C106KE15L
C1300 4030019990 S.CER C1005 JB 1C 104K-T
C1301 4030019560 S.CER GRM21BB31C106KE15L
C1302 4030019990 S.CER C1005 JB 1C 104K-T
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
H/V LOCATION=See the BOARD LAYOUTS for details.
5
DESCRIPTION M.
T
T
T
T
T
T
F930J476MBABMA T
T
T
T
T
T
T
T
T
T
T
T
T
T
T
T
T
T
T
T
T
T
T
T
T
T
T
T
T
T
T
T
T
T
T
T
T
T
16 CE 470 LX T
T
T
T
T
T
T
T
T
T
T
T
T
T
T
T
T
T
T
T
T
T
T
T
T
T
T
T
T
T
T
T
T
T
T
T
T
T
T
T
T
T
T
T
T
T
T
T
T
T
T
T
T
T
T
T
T
T
T
T
H/V
LOCATION
72.4/75.3
72.4/76.8
72.4/77.8
72.4/79.3
72.4/80.8
72.4/81.7
67.6/75.8
96.9/55.4
38.0/158.0
37.9/163.0
33.6/134.0
34.2/143.5
34.2/144.9
36.1/156.9
34.1/151.5
31.3/155.0
29.0/149.7
32.4/149.2
47.8/133.2
47.8/136.0
46.4/136.9
39.1/145.0
43.5/139.9
46.7/139.9
40.5/145.6
49.6/145.9
43.6/142.0
46.2/142.1
39.6/141.6
50.8/140.5
60.8/133.6
60.7/131.5
64.0/143.9
62.2/143.9
65.1/146.2
62.5/145.3
68.5/142.5
68.2/146.0
67.0/139.6
69.7/147.6
69.3/138.2
73.2/135.5
74.1/142.8
72.8/148.1
69.0/153.9
63.4/153.3
66.8/148.5
69.0/134.9
106.8/76.0
107.4/76.9
106.9/78.2
105.7/82.3
105.7/83.2
51.8/77.5
49.3/75.9
48.2/77.5
52.8/76.6
49.3/80.6
50.5/80.2
49.5/87.2
50.5/81.1
51.2/85.9
52.0/91.9
48.5/94.0
52.7/97.5
68.6/132.9
71.0/131.2
58.4/128.1
66.3/130.4
63.4/130.9
106.1/127.5
97.6/124.5
94.6/124.5
102.8/129.4
97.4/121.0
95.1/121.0
93.0/118.6
98.1/118.8
100.6/117.2
101.9/120.3
102.4/117.2
107.7/120.9
107.2/116.4
112.8/117.3
102.5/115.4
101.6/115.4
103.4/115.4
101.1/108.7
102.8/108.7
101.1/109.6
102.8/109.6
101.4/107.2
99.3/110.1
98.4/113.3
98.8/112.1
83.3/96.8
87.1/95.3
99.1/129.9
92.9/129.0
93.1/127.8
94.0/102.7
59.2/132.3
96.0/103.7
93.4/110.5
