USER MANUAL
PTM 216Z - 2.4 GHz Zigbee Pushbutton Switch Transmitter Module
PTM 216Z
2.4 GHz Zigbee
25 May 2023
Observe precautions! Electrostatic sensitive devices!
Patent protected:
WO98/36395, DE 100 25 561, DE 101 50 128,
WO 2004/051591, DE 103 01 678 AI, DE 10309334,
WO 04/109236, WO 05/096482, WO 02/095707,
US 6,747,573, US 7,019,241
© 2023 EnOcean | www.enocean.com
®
Pushbutton Switch Transmitter Module
F-710-017, V1.0
PTM 216Z User Manual | v1.2 | May 2023 | Page 1/49

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PTM 216Z and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for EnOcean PTM 216Z

Summary of Contents for EnOcean PTM 216Z

  • Page 1 WO98/36395, DE 100 25 561, DE 101 50 128, WO 2004/051591, DE 103 01 678 AI, DE 10309334, WO 04/109236, WO 05/096482, WO 02/095707, US 6,747,573, US 7,019,241 © 2023 EnOcean | www.enocean.com F-710-017, V1.0 PTM 216Z User Manual | v1.2 | May 2023 | Page 1/49...
  • Page 2 As far as patents or other rights of third parties are concerned, liability is only assumed for modules, not for the described applications, processes and circuits. EnOcean does not assume responsibility for use of modules described and limits its liability to the replacement of modules determined to be defective due to workmanship. Devices or sys- tems containing RF components must meet the essential requirements of the local legal au- thorities.

  • Page 3: Table Of Contents

    Disabling direct commissioning ............27 3.6.3 Sequential commissioning by button press ..........28 3.6.3.1 Commissioning request ..............28 3.6.3.2 Example of sequential commissioning ..........29 © 2023 EnOcean | www.enocean.com F-710-017, V1.0 PTM 216Z User Manual | v1.2 | May 2023 | Page 3/49...
  • Page 4 Regulatory Statement ................47 7.3.2.1 English version ................. 47 7.3.2.2 French version .................. 48 Product history .................... 49 References ....................49 © 2023 EnOcean | www.enocean.com F-710-017, V1.0 PTM 216Z User Manual | v1.2 | May 2023 | Page 4/49...

  • Page 5: General Description

    2.4 GHz Zigbee Green Power standard [1]. ® Starting with product revision DB, PTM 216Z integrates an NFC interface which can be used to configure device parameters. PTM 216Z is mechanically compatible with the established PTM 21x form factor enabling quick integration into a wide range of designs.

  • Page 6: Technical Data

    Tray / Box (10 units per tray, 10 trays per box) Ordering information Type Ordering Code Frequency 2.4 GHz Zigbee PTM 216Z:DB S3271-A216:DB © 2023 EnOcean | www.enocean.com F-710-017, V1.0 PTM 216Z User Manual | v1.2 | May 2023 | Page 6/49...

  • Page 7: Functional Information

    Figure 2 – Electro-dynamic powered pushbutton transmitter module PTM 216Z Basic functionality PTM 216Z devices contain an electro-dynamic energy transducer which is actuated by an en- ergy bow (1). This bow is pushed by an appropriate push button, switch rocker or a similar construction mounted onto the device.

  • Page 8: Block Diagram

    Transmits the data in the form of a series of short Zigbee Green Power radio telegrams using the integrated antenna In addition, PTM 216Z contains an integrated NFC interface according to ISO14443 that can be used to configure device parameters.

  • Page 9: User Interface

    PTM 216Z - 2.4 GHz Zigbee Pushbutton Switch Transmitter Module User interface PTM 216Z devices provide four button contacts. They are grouped into two channels (Channel A and Channel B) each containing two button contacts (State O and State I).

  • Page 10: Radio Communication

    Green Power standard [1]. Other models can be selected as described in chapter 3.3.1. PTM 216Z radio channel parameters PTM 216Z supports all sixteen IEEE 802.15.4 / Zigbee Green Power radio channels in the 2.4 GHz band (channels 11 … 26 according to IEEE 802.15.4 notation).

  • Page 11: Telegram Structure

    USER MANUAL PTM 216Z - 2.4 GHz Zigbee Pushbutton Switch Transmitter Module Telegram structure PTM 216Z transmits radio telegrams in the 2.4 GHz band as defined by the Zigbee Green Power standard which uses an IEEE 802.15.4 frame structure [1].

  • Page 12: Ieee 802.15.4 Phy Header

    ◼ Length = 25 bytes (0x19) Commissioning telegram ◼ Length= 46 bytes (0x2E) Decommissioning telegram ◼ Length = 24 bytes (0x18) © 2023 EnOcean | www.enocean.com F-710-017, V1.0 PTM 216Z User Manual | v1.2 | May 2023 | Page 12/49...

  • Page 13: Ieee 802.15.4 Mac Header

    The IEEE 802.15.4 MAC Header contains the following fields: Frame Control Field (2 byte) ◼ The Frame Control Field is set to 0x0801 in all PTM 216Z telegrams in order to iden- tify them as data telegrams with short addresses based on version IEEE 802.15.4- 2003 Sequence Number (1 byte) ◼...

  • Page 14: Ieee 802.15.4 Payload (Zgp Telegram Data)

    Zigbee Green Power Device Model as described in the next chapters. 3.3.1.1 Device Models PTM 216Z supports a wide range of Zigbee Green Power device models allowing the use of PTM 216Z in a wide variety of applications. Table 2 below lists the Device Models supported by PTM 216Z.

  • Page 15: Generic Switch Model

    USER MANUAL PTM 216Z - 2.4 GHz Zigbee Pushbutton Switch Transmitter Module 3.3.1.2 Generic Switch model By default, PTM 216Z uses the Generic Switch model defined by the Zigbee Green Power standard to encode the button status. In this model, button press events are transmitted using Command ID 0x69 followed by 1 byte button status.

  • Page 16: Command-Based Models

    0x10 as defined in Table 2. PTM 216Z can be configured via NFC to use one of the command-based device models as described in chapter 4.2. If a command-based device model is selected, then the correspond- ence between button action and transmitted command is configurable via NFC as described in chapter 4.2.
  • Page 17 Note that 0xFF means that no telegram will be sent for that specific button action. Table 3 – Default command table for command-based device models © 2023 EnOcean | www.enocean.com F-710-017, V1.0 PTM 216Z User Manual | v1.2 | May 2023 | Page 17/49...

  • Page 18: Commissioning Telegram

    PTM 216Z - 2.4 GHz Zigbee Pushbutton Switch Transmitter Module 3.3.2 Commissioning telegram Zigbee Green Power Commissioning telegrams are used to commission PTM 216Z into Zigbee Green Power networks. Commissioning telegrams are identified by the Command ID 0xE0 and contain the required information about the properties of PTM 216Z.

  • Page 19: Commissioning Telegram Payload For Command-Based Models

    Security Key Hash 4 byte hash of the encrypted security key ◼ Outgoing Security Counter 4 byte value of security counter ◼ © 2023 EnOcean | www.enocean.com F-710-017, V1.0 PTM 216Z User Manual | v1.2 | May 2023 | Page 19/49...

  • Page 20: Decommissioning Telegram

    Decommissioning telegram Zigbee Green Power Decommissioning telegrams are used to inform the network of devices to which PTM 216Z had been commissioned that PTM 216Z will leave the network due to a change of radio channel. Decommissioning telegrams are therefore sent each time PTM 216Z changes radio channel during commissioning as described in chapter 3.5.

  • Page 21: Telegram Authentication

    To avoid message replay (capture and retransmission of a valid message), it is required that the receiver tracks the value of the sequence counter used by PTM 216Z and only accepts messages with higher sequence counter values (meaning that the receiver does not accept telegrams having an equal or lower sequence counter value as the last received telegram).

  • Page 22: Algorithm Parameters

    PTM 216Z - 2.4 GHz Zigbee Pushbutton Switch Transmitter Module 3.4.2 Algorithm parameters PTM 216Z implements telegram authentication according to the Zigbee Green Power stand- ard [1]. It uses AES128 in CCM (Counter with CBC-MAC) mode as described in IETF RFC3610 [3].
  • Page 23 The security key required for the telegram authentication can be obtained from the product DMC code as shown in chapter 5.3.1. © 2023 EnOcean | www.enocean.com F-710-017, V1.0 PTM 216Z User Manual | v1.2 | May 2023 | Page 23/49...

  • Page 24: Security Keys

    PTM 216Z that can be selected via NFC as described in chapter 4.2. The default operation mode of PTM 216Z is to use TCLK. If protection with an Installation Code (IC) is selected, then SECURITY_KEY3 will be used as Installation Code.

  • Page 25: Commissioning

    If the intended receiver or network operates on one of the primary radio channels (channel 11, 15, 20 or 25) and PTM 216Z is integrated into a double rocker or four button switch, then PTM 216Z can be commissioned directly using a simplified but- ton sequence.

  • Page 26: Direct Commissioning By Button Press

    3.6.2.1 Commissioning request The commissioning request is triggered by long-pressing (for 7 seconds or more) one of the four buttons of PTM 216Z. Upon detection of such long button press, PTM 216Z will transmit a commissioning request on the corresponding radio channel.

  • Page 27: Radio Channel Confirmation

    If the new radio channel is different from the previously used radio channel, then PTM 216Z will send a decommissioning command (0xE1) on the previously used radio channel upon release of AI and B0. If the radio channel remains unchanged, then PTM 216Z will send a data telegram upon release of AI and B0.

  • Page 28: Sequential Commissioning By Button Press

    Figure 14 below for the case where selection from all channels is enabled. Figure 14 – Button sequence for sequential commissioning © 2023 EnOcean | www.enocean.com F-710-017, V1.0 PTM 216Z User Manual | v1.2 | May 2023 | Page 28/49...

  • Page 29: Example Of Sequential Commissioning

    2. Press the same button shortly 7 times to select channel 17. PTM 216Z will follow the channel sequence 11 -> 12 -> 13 -> 14 ->15 -> 16 -> 17 3. Confirm selection of radio channel 17 by pressing a button different from the one used during the previous two steps.

  • Page 30: Disabling Sequential Commissioning

    Consider the case where PTM 216Z operates on channel 15 and the user executed a long – short - long sequence on button AI. In this case, upon the first long button press of the...

  • Page 31: Disabling Channel Change By Button Press

    NFC interface as described in chapter 4.2. Factory reset PTM 216Z can be reset to factory state by pressing buttons A0, AI, B0 and BI at the same time for at least 7 seconds (long press) or via the NFC interface as described in chapter 4.2.

  • Page 32: Nfc Interface

    14443 Part 2 and 3 standards. For a detailed description about the NFC functionality, please refer to the ISO/IEC 14443 standard. The NFC functionality in PTM 216Z can be used to access (read and write) the PTM 216Z configuration memory and thereby configure the device as described in the following chap- ters.

  • Page 33: Using The Nfc Interface

    This reader is shown in Figure 15 below. Figure 15 – Elatec TWN4 MultiTech Desktop NFC Reader EnOcean provides a PC application called EnOcean NFC configurator which can be used to configure PTM 215ZE devices. This tool is available here: https://www.enocean.com/en/product/enocean-nfc-configurator/ 4.2.2 Mobile app configuration NFC functionality is available in certain Android (e.g.

  • Page 34: Device Integration

    PTM 216Z - 2.4 GHz Zigbee Pushbutton Switch Transmitter Module Device integration PTM 216Z is designed for integration into button or rocker-based switches. It implements the established PTM 2xx mechanical form factor and can therefore be used with a wide variety of existing designs.
  • Page 35 PTM 216Z - 2.4 GHz Zigbee Pushbutton Switch Transmitter Module 1) these catwalks are not needed when using one single rocker only 2) dimensions of rocker part Figure 17 – PTM 216Z, top view (note cut A, B and C marking) © 2023 EnOcean | www.enocean.com F-710-017, V1.0...
  • Page 36 Figure 18 – PTM 216Z, cut A 2) dimensions of rocker part Figure 19 – PTM 216Z, cut B and C © 2023 EnOcean | www.enocean.com F-710-017, V1.0 PTM 216Z User Manual | v1.2 | May 2023 | Page 36/49...
  • Page 37 PTM 216Z - 2.4 GHz Zigbee Pushbutton Switch Transmitter Module Hatched areas: support planes Figure 20 – PTM 216Z rear view © 2023 EnOcean | www.enocean.com F-710-017, V1.0 PTM 216Z User Manual | v1.2 | May 2023 | Page 37/49...
  • Page 38 2) dimensions of rocker part Figure 21 – PTM 216Z, side view If the rocker is not mounted on the rotation axis of PTM 216Z several tolerances have to be considered! The measure from support plane to top of the energy bow is 7.70 mm +/- 0.3 mm!
  • Page 39 PTM 216Z is powered by the electromagnetic generator ECO 200. For proper func- tion there has to be a keep out zone of 60mm for magnets or ferromagnetic mate- rials around the center of PTM 216Z.

  • Page 40: Device Label

    In addition, it contains an installation QR code providing information about this module in an electronically readable format. The structure of this installation QR code is described in the next chapter. © 2023 EnOcean | www.enocean.com F-710-017, V1.0 PTM 216Z User Manual | v1.2 | May 2023 | Page 40/49...

  • Page 41: Installation Qr Code

    Figure 22 above encodes the following string: 30PS3071-A216+2PDB04+30S01521234+Z6ED1E82DBA5971B4CA29EE1BD0C6B4D +3Z175A172AECF5452BB5F6A26558CB9E96+31Z12345678+S01123401000001 Table 5 below describes the ANSI/MH10.8.2 data identifiers used by the PTM 216Z device label and shows the interpretation of the data therein. Identifier Length of data (excl. identifier) Content 10 characters...

  • Page 42: Application Information

    The distance between the receiver and other transmitting devices such as computers, audio and video equipment that also emit high-frequency signals should be at least 0.5 m. © 2023 EnOcean | www.enocean.com F-710-017, V1.0 PTM 216Z User Manual | v1.2 | May 2023 | Page 42/49...

  • Page 43: Regulatory Information

    PTM 216Z - 2.4 GHz Zigbee Pushbutton Switch Transmitter Module Regulatory information PTM 216Z has been certified according to RED (Europe) regulations. Changes or modifications not expressly approved by EnOcean could void the user's authority to operate the equipment. RED for the European market The Radio Equipment Directive (2014/53/EU, typically referred to as RED) replaces R&TTE...

  • Page 44: Fcc (United States)

    USER MANUAL PTM 216Z - 2.4 GHz Zigbee Pushbutton Switch Transmitter Module FCC (United States) 7.2.1 Certificate © 2023 EnOcean | www.enocean.com F-710-017, V1.0 PTM 216Z User Manual | v1.2 | May 2023 | Page 44/49...

  • Page 45: Regulatory Statement

    Connect the equipment into an outlet on a circuit different from that to which the re- ◼ ceiver is connected. Consult the dealer or an experienced radio/TV technician for help. ◼ © 2023 EnOcean | www.enocean.com F-710-017, V1.0 PTM 216Z User Manual | v1.2 | May 2023 | Page 45/49...

  • Page 46: Ised (Former Industry Canada)

    USER MANUAL PTM 216Z - 2.4 GHz Zigbee Pushbutton Switch Transmitter Module ISED (former Industry Canada) 7.3.1 Certificate © 2023 EnOcean | www.enocean.com F-710-017, V1.0 PTM 216Z User Manual | v1.2 | May 2023 | Page 46/49...

  • Page 47: Regulatory Statement

    Connect the equipment into an outlet on a circuit different from that to which the re- ◼ ceiver is connected. Consult the dealer or an experienced radio/TV technician for help ◼ © 2023 EnOcean | www.enocean.com F-710-017, V1.0 PTM 216Z User Manual | v1.2 | May 2023 | Page 47/49...

  • Page 48: French Version

    Connecter l'équipement à une sortie sur un circuit différent de celui sur lequel le ré- ◼ cepteur est branché. Consulter le revendeur ou un technicien radio / télévision expérimenté pour de l'aide ◼ © 2023 EnOcean | www.enocean.com F-710-017, V1.0 PTM 216Z User Manual | v1.2 | May 2023 | Page 48/49...

  • Page 49: Product History

    DB-05 May 2023 Addition of NFC interface Table 6 – Product History References Consult the references listed below for additional information about PTM 216Z functionality. Zigbee Green Power Specification IEEE 802.15.4 Specification RFC3610 Specification © 2023 EnOcean | www.enocean.com F-710-017, V1.0...
