EnOcean PTM 215ZE User Manual

2.4 ghz zigbee pushbutton switch transmitter module
Hide thumbs Also See for PTM 215ZE:
Table of Contents

Advertisement

Quick Links

Download this manual
USER MANUAL
PTM 215ZE - 2.4 GHz Zigbee Pushbutton Switch Transmitter Module
PTM 215ZE
2.4 GHz Zigbee
25 May 2023
Observe precautions! Electrostatic sensitive devices!
Patent protected:
WO98/36395, DE 100 25 561, DE 101 50 128,
WO 2004/051591, DE 103 01 678 AI, DE 10309334,
WO 04/109236, WO 05/096482, WO 02/095707,
US 6,747,573, US 7,019,241
© EnOcean | www.enocean.com F-710-017, V1.0
®
Pushbutton Switch Transmitter Module
PTM 215ZE User Manual | v1.8 | May 2023 | Page 1/50

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PTM 215ZE and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for EnOcean PTM 215ZE

Summary of Contents for EnOcean PTM 215ZE

  • Page 1 WO98/36395, DE 100 25 561, DE 101 50 128, WO 2004/051591, DE 103 01 678 AI, DE 10309334, WO 04/109236, WO 05/096482, WO 02/095707, US 6,747,573, US 7,019,241 © EnOcean | www.enocean.com F-710-017, V1.0 PTM 215ZE User Manual | v1.8 | May 2023 | Page 1/50...
  • Page 2 As far as patents or other rights of third parties are concerned, liability is only assumed for modules, not for the described applications, processes and circuits. EnOcean does not assume responsibility for use of modules described and limits its liability to the replacement of modules determined to be defective due to workmanship. Devices or sys- tems containing RF components must meet the essential requirements of the local legal au- thorities.

  • Page 3: Table Of Contents

    Enabling direct commissioning ............28 3.6.3 Sequential commissioning by button press ..........29 3.6.3.1 Commissioning request ..............29 3.6.3.2 Example of sequential commissioning ..........30 © EnOcean | www.enocean.com F-710-017, V1.0 PTM 215ZE User Manual | v1.8 | May 2023 | Page 3/50...
  • Page 4 7.3.2 Regulatory Statement ................48 7.3.2.1 English version ................. 48 7.3.2.2 French version .................. 49 Product history .................... 50 References ....................50 © EnOcean | www.enocean.com F-710-017, V1.0 PTM 215ZE User Manual | v1.8 | May 2023 | Page 4/50...

  • Page 5: General Description

    Green Power standard [1]. PTM 215ZE product revision DB integrates an NFC interface which can be used to configure device parameters. Product revision DA does not provide this functionality. PTM 215ZE is mechanically compatible with the established PTM 21x form factor enabling quick integration into a wide range of designs.

  • Page 6: Technical Data

    Tray / Box (10 units per tray, 10 trays per box) Ordering information Type Ordering Code Frequency 2.4 GHz Zigbee PTM 215ZE:DB S3271-A216:DB © EnOcean | www.enocean.com F-710-017, V1.0 PTM 215ZE User Manual | v1.8 | May 2023 | Page 6/50...

  • Page 7: Functional Information

    Figure 2 – Electro-dynamic powered pushbutton transmitter module PTM 215ZE Basic functionality PTM 215ZE devices contain an electro-dynamic energy transducer which is actuated by an energy bow (1). This bow is pushed by an appropriate push button, switch rocker or a similar construction mounted onto the device.

  • Page 8: Block Diagram

    Transmits the data in the form of a series of short Zigbee Green Power radio telegrams using the integrated antenna In addition, PTM 215ZE product revision DB provides an integrated NFC interface according to ISO 14443 that can be used to configure device parameters.

  • Page 9: User Interface

    PTM 215ZE - 2.4 GHz Zigbee Pushbutton Switch Transmitter Module User interface PTM 215ZE devices provide four button contacts. They are grouped into two channels (Channel A and Channel B) each containing two button contacts (State O and State I).

  • Page 10: Radio Communication

    Green Power standard [1]. Other models can be selected as described in chapter 3.3.1. PTM 215ZE radio channel parameters PTM 215ZE supports all sixteen IEEE 802.15.4 / Zigbee Green Power radio channels in the 2.4 GHz band (channels 11 … 26 according to IEEE 802.15.4 notation).

  • Page 11: Telegram Structure

    USER MANUAL PTM 215ZE - 2.4 GHz Zigbee Pushbutton Switch Transmitter Module Telegram structure PTM 215ZE transmits radio telegrams in the 2.4 GHz band as defined by the Zigbee Green Power standard which uses an IEEE 802.15.4 frame structure [1].

  • Page 12: Ieee 802.15.4 Phy Header

    Data telegram ◼ Length = 25 bytes (0x19) Commissioning telegram ◼ Length= 46 bytes (0x2E) Decommissioning telegram ◼ Length = 24 bytes (0x18) © EnOcean | www.enocean.com F-710-017, V1.0 PTM 215ZE User Manual | v1.8 | May 2023 | Page 12/50...

  • Page 13: Ieee 802.15.4 Mac Header

    The IEEE 802.15.4 MAC Header contains the following fields: Frame Control Field (2 byte) ◼ The Frame Control Field is set to 0x0801 in all PTM 215ZE telegrams in order to iden- tify them as data telegrams with short addresses based on version IEEE 802.15.4- 2003 Sequence Number (1 byte) ◼...

  • Page 14: Ieee 802.15.4 Payload (Zgp Telegram Data)

    Zigbee Green Power device model as described in the next chapters. 3.3.1.1 Zigbee Green Power device models PTM 215ZE supports a wide range of Zigbee Green Power device models allowing the use of PTM 215ZE in a wide variety of applications. Table 2 below lists the Device Models supported by PTM 215ZE.

  • Page 15: Command-Based Device Models

    PTM 215ZE uses by default the command-based device model “ON / OFF Switch” identified by Device ID 0x02. PTM 215ZE can be configured via NFC to use one of the other command- based device models or the Generic Switch device model via the NFC PC configuration tool as described in chapter 4.2.
  • Page 16 Note that 0xFF means that no telegram will be sent for that specific button action. Table 3 – Default command table for command-based device models © EnOcean | www.enocean.com F-710-017, V1.0 PTM 215ZE User Manual | v1.8 | May 2023 | Page 16/50...

  • Page 17: Generic Switch Device Model

    PTM 215ZE - 2.4 GHz Zigbee Pushbutton Switch Transmitter Module 3.3.1.2 Generic Switch device model PTM 215ZE can be configured via NFC to use the Generic Switch model defined by the Zigbee Green Power standard to encode the button status.

  • Page 18: Commissioning Telegram

    3.3.2.1 Format for command-based models without Application Info By default, PTM 215ZE does not transmit the Application Information fields to provide back- wards-compatibility with previous revisions of PTM 215ZE. If Application Information is not present, then the Commissioning telegram contains the following fields:...

  • Page 19: Format For Command-Based Models With Application Info

    PTM 215ZE - 2.4 GHz Zigbee Pushbutton Switch Transmitter Module 3.3.2.2 Format for command-based models with Application Info PTM 215ZE can be configured via NFC as described in chapter 4.2. to provide Application Information as part of the Commissioning Telegram to provide compatibility with newer im- plementations.

  • Page 20: Format For Generic Switch Model

    5 representing the 4 buttons contacts and the energy bar (actuated without button press). This parameter can be changed via the NFC PC configuration tool as described in chapter 4.2.to match the actual product. © EnOcean | www.enocean.com F-710-017, V1.0 PTM 215ZE User Manual | v1.8 | May 2023 | Page 20/50...

  • Page 21: Decommissioning Telegram

    Decommissioning telegram Zigbee Green Power Decommissioning telegrams are used to inform the network of devices to which PTM 215ZE had been commissioned that PTM 215ZE will leave the network due to a change of radio channel. Decommissioning telegrams are therefore sent each time PTM 215ZE changes radio channel during commissioning as described in chapter 3.5.

  • Page 22: Telegram Authentication

    To avoid message replay (capture and retransmission of a valid message), it is required that the receiver tracks the value of the sequence counter used by PTM 215ZE and only accepts messages with higher sequence counter values (meaning that the receiver does not accept telegrams having an equal or lower sequence counter value as the last received telegram).

  • Page 23: Algorithm Parameters

    PTM 215ZE - 2.4 GHz Zigbee Pushbutton Switch Transmitter Module 3.4.2 Algorithm parameters PTM 215ZE implements telegram authentication according to the Zigbee Green Power stand- ard [1]. It uses AES128 in CCM (Counter with CBC-MAC) mode as described in IETF RFC3610 [3].
  • Page 24 DMC code as shown in chapter 5.3.1. For Zigbee Green Power receivers, it is also provided as part of the Commissioning telegram as described in chapter 3.3.2. © EnOcean | www.enocean.com F-710-017, V1.0 PTM 215ZE User Manual | v1.8 | May 2023 | Page 24/50...

  • Page 25: Security Keys

    ◼ The transmission of the security key is protected by a user-defined key (IC). This is an optional operation mode of PTM 215ZE that can be selected via the NFC PC con- figuration tool as described in chapter 4.2. The default operation mode of PTM 215ZE is to use TCLK. If protection with an Installation Code (IC) is selected, then SECURITY_KEY3 will be used as Installation Code.

  • Page 26: Commissioning

    If the intended receiver or network operates on one of the primary radio channels (channel 11, 15, 20 or 25) and PTM 215ZE is integrated into a double rocker or four button switch, then PTM 215ZE can be commissioned directly using a simplified but- ton sequence.

  • Page 27: Direct Commissioning By Button Press

    3.6.2.1 Commissioning request The commissioning request is triggered by long-pressing (for 7 seconds or more) one of the four buttons of PTM 215ZE. Upon detection of such long button press, PTM 215ZE will transmit a commissioning request on the corresponding radio channel.

  • Page 28: Radio Channel Confirmation

    Otherwise (for instance for the case of a single rocker switch design), PTM 215ZE would have to be removed from the housing design first. Upon press of AI and B0, PTM 215ZE will permanently adjust the radio channel to the one selected by the long-pressed button as defined in...

  • Page 29: Sequential Commissioning By Button Press

    Figure 14 below for the case where selection from all channels is enabled. Figure 14 – Button sequence for sequential commissioning © EnOcean | www.enocean.com F-710-017, V1.0 PTM 215ZE User Manual | v1.8 | May 2023 | Page 29/50...

  • Page 30: Example Of Sequential Commissioning

    2. Press the same button shortly 7 times to select channel 17. PTM 215ZE will follow the channel sequence 11 -> 12 -> 13 -> 14 ->15 -> 16 -> 17 3. Confirm selection of radio channel 17 by pressing a button different from the one used during the previous two steps.

  • Page 31: Disabling Sequential Commissioning

    Consider the case where PTM 215ZE operates on channel 15 and the user executed a long – short - long sequence on button B0. In this case, upon the first long button press of the...

  • Page 32: Disabling Channel Change By Button Press

    NFC PC configuration tool as described in chapter 4.2. Factory reset PTM 215ZE can be reset to factory state by pressing buttons A0, AI, B0 and BI at the same time for at least 7 seconds (long press) or via the NFC PC configuration tool as described in chapter 4.2.

  • Page 33: Nfc Interface

    14443 Part 2 and 3 standards. For a detailed description about the NFC functionality, please refer to the ISO/IEC 14443 standard. The NFC functionality in PTM 215ZE can be used to access (read and write) the PTM 215ZE configuration memory and thereby configure the device as described in the following chap- ters.

  • Page 34: Using The Nfc Interface

    This reader is shown in Figure 15 below. Figure 15 – Elatec TWN4 MultiTech Desktop NFC Reader EnOcean provides a PC application called EnOcean NFC configurator which can be used to configure PTM 215ZE devices. This tool is available here: https://www.enocean.com/en/product/enocean-nfc-configurator/ 4.2.2 Mobile app configuration NFC functionality is available in certain Android (e.g.

  • Page 35: Device Integration

    PTM 215ZE - 2.4 GHz Zigbee Pushbutton Switch Transmitter Module Device integration PTM 215ZE is designed for integration into button or rocker-based switches. It implements the established PTM 2xx mechanical form factor and can therefore be used with a wide variety of existing designs.
  • Page 36 PTM 215ZE - 2.4 GHz Zigbee Pushbutton Switch Transmitter Module 1) these catwalks are not needed when using one single rocker only 2) dimensions of rocker part Figure 17 – PTM 215ZE, top view (note cut A, B and C marking) © EnOcean | www.enocean.com F-710-017, V1.0...
  • Page 37 PTM 215ZE - 2.4 GHz Zigbee Pushbutton Switch Transmitter Module Figure 18 – PTM 215ZE, cut A 2) dimensions of rocker part Figure 19 – PTM 215ZE, cut B and C © EnOcean | www.enocean.com F-710-017, V1.0 PTM 215ZE User Manual | v1.8 | May 2023 | Page 37/50...
  • Page 38 USER MANUAL PTM 215ZE - 2.4 GHz Zigbee Pushbutton Switch Transmitter Module Hatched areas: support planes Figure 20 – PTM 215ZE rear view © EnOcean | www.enocean.com F-710-017, V1.0 PTM 215ZE User Manual | v1.8 | May 2023 | Page 38/50...
  • Page 39 2) dimensions of rocker part Figure 21 – PTM 215ZE, side view If the rocker is not mounted on the rotation axis of PTM 215ZE several tolerances have to be considered! The measure from support plane to top of the energy bow is 7.70 mm +/- 0.3 mm!
  • Page 40 PTM 215ZE is powered by the electromagnetic generator ECO 200. For proper func- tion there has to be a keep out zone of 60mm for magnets or ferromagnetic mate- rials around the center of PTM 215ZE.

  • Page 41: Device Label

    In addition, it contains an installation QR code providing information about this module in an electronically readable format. The structure of this installation QR code is described in the next chapter. © EnOcean | www.enocean.com F-710-017, V1.0 PTM 215ZE User Manual | v1.8 | May 2023 | Page 41/50...

  • Page 42: Installation Qr Code

    Figure 22 above encodes the following string: 30PS3071-A216+2PDB04+30S01521234+Z6ED1E82DBA5971B4CA29EE1BD0C6B4D +3Z175A172AECF5452BB5F6A26558CB9E96+31Z12345678+S01123401000001 Table 5 below describes the ANSI/MH10.8.2 data identifiers used by the PTM 215ZE device label and shows the interpretation of the data therein. Identifier Length of data (excl. identifier) Content 10 characters...

  • Page 43: Application Information

    The distance between the receiver and other transmitting devices such as computers, audio and video equipment that also emit high-frequency signals should be at least 0.5 m. © EnOcean | www.enocean.com F-710-017, V1.0 PTM 215ZE User Manual | v1.8 | May 2023 | Page 43/50...

  • Page 44: Regulatory Information

    PTM 215ZE - 2.4 GHz Zigbee Pushbutton Switch Transmitter Module Regulatory information PTM 215ZE has been certified according to RED (Europe) regulations. Changes or modifica- tions not expressly approved by EnOcean could void the user's authority to operate the equip- ment. RED for the European market The Radio Equipment Directive (2014/53/EU, typically referred to as RED) replaces R&TTE...

  • Page 45: Fcc (United States)

    USER MANUAL PTM 215ZE - 2.4 GHz Zigbee Pushbutton Switch Transmitter Module FCC (United States) 7.2.1 Certificate © EnOcean | www.enocean.com F-710-017, V1.0 PTM 215ZE User Manual | v1.8 | May 2023 | Page 45/50...

  • Page 46: Regulatory Statement

    Connect the equipment into an outlet on a circuit different from that to which the re- ◼ ceiver is connected. Consult the dealer or an experienced radio/TV technician for help. ◼ © EnOcean | www.enocean.com F-710-017, V1.0 PTM 215ZE User Manual | v1.8 | May 2023 | Page 46/50...

  • Page 47: Ised (Former Industry Canada)

    USER MANUAL PTM 215ZE - 2.4 GHz Zigbee Pushbutton Switch Transmitter Module ISED (former Industry Canada) 7.3.1 Certificate © EnOcean | www.enocean.com F-710-017, V1.0 PTM 215ZE User Manual | v1.8 | May 2023 | Page 47/50...

  • Page 48: Regulatory Statement

    Connect the equipment into an outlet on a circuit different from that to which the re- ◼ ceiver is connected. Consult the dealer or an experienced radio/TV technician for help ◼ © EnOcean | www.enocean.com F-710-017, V1.0 PTM 215ZE User Manual | v1.8 | May 2023 | Page 48/50...

  • Page 49: French Version

    Connecter l'équipement à une sortie sur un circuit différent de celui sur lequel le ré- ◼ cepteur est branché. Consulter le revendeur ou un technicien radio / télévision expérimenté pour de l'aide ◼ © EnOcean | www.enocean.com F-710-017, V1.0 PTM 215ZE User Manual | v1.8 | May 2023 | Page 49/50...

  • Page 50: Product History

    May 2023 Addition of NFC interface for device configuration Table 6 – Product History References Consult the references listed below for additional information about PTM 215ZE functionality. Zigbee Green Power Specification IEEE 802.15.4 Specification RFC3610 Specification © EnOcean | www.enocean.com F-710-017, V1.0...
