USER MANUAL
PTM 535 / PTM 535U / PTM 535J – ENOCEAN TRANSMITTER MODULE
PTM 535 / PTM 535U / PTM 535J
EnOcean Transmitter Module
21.09.2020
Observe precautions! Electrostatic sensitive devices!
Patent protected:
WO98/36395, DE 100 25 561, DE 101 50 128,
WO 2004/051591, DE 103 01 678 A1, DE 10309334,
WO 04/109236, WO 05/096482, WO 02/095707,
US 6,747,573, US 7,019,241
© 2019 EnOcean | www.enocean.com
F-710-017, V1.0
PTM 535 / 535J User Manual | v1.5 | September 2020 | Page 1/36
Advertisement
Table of Contents
Related Manuals for EnOcean PTM 535
Summary of Contents for EnOcean PTM 535
- Page 1 WO 2004/051591, DE 103 01 678 A1, DE 10309334, WO 04/109236, WO 05/096482, WO 02/095707, US 6,747,573, US 7,019,241 © 2019 EnOcean | www.enocean.com F-710-017, V1.0 PTM 535 / 535J User Manual | v1.5 | September 2020 | Page 1/36...
- Page 2 Components of the modules are considered and should be disposed of as hazardous waste. Local government regulations are to be observed. Packing: Please use the recycling operators known to you. © 2019 EnOcean | www.enocean.com F-710-017, V1.0 PTM 535 / 535J User Manual | v1.5 | September 2020 | Page 2/36...
-
Page 3: Table Of Contents
ISED regulatory statement ..............32 6.3.2.1 English version ................. 32 6.3.2.2 French version .................. 33 6.4 ARIB (Japan) ....................34 © 2019 EnOcean | www.enocean.com F-710-017, V1.0 PTM 535 / 535J User Manual | v1.5 | September 2020 | Page 3/36... - Page 4 PTM 535 / PTM 535U / PTM 535J – ENOCEAN TRANSMITTER MODULE 6.4.1 ARIB (Japan) certificate ................ 34 6.4.2 ARIB (Japan) regulatory requirements ............ 35 Product history .................... 36 © 2019 EnOcean | www.enocean.com F-710-017, V1.0 PTM 535 / 535J User Manual | v1.5 | September 2020 | Page 4/36...
-
Page 5: General Description
Operating frequency 928.350 MHz All three variants contain a pre-installed whip antenna, support enhanced security and are delivery in a cardboard box. The term “PTM 535” is subsequently used to describe all three product variants unless otherwise noted. © 2019 EnOcean | www.enocean.com F-710-017, V1.0... -
Page 6: Technical Data
A0, A1, B0, B1, Voltage on digital input pins SECURE, STANDARD, CFG Physical dimensions PCB dimensions 26.2 x 21.15 x 3.5 mm © 2019 EnOcean | www.enocean.com F-710-017, V1.0 PTM 535 / 535J User Manual | v1.5 | September 2020 | Page 6/36... -
Page 7: Device Drawing
PTM 535 / PTM 535U / PTM 535J – ENOCEAN TRANSMITTER MODULE Device drawing Figure 1 – PTM 535 outline © 2019 EnOcean | www.enocean.com F-710-017, V1.0 PTM 535 / 535J User Manual | v1.5 | September 2020 | Page 7/36... -
Page 8: Environmental Conditions
902.875 MHz Whip antenna, Delivered in cardboard box PTM 535J S3061-A535 928.350 MHz Whip antenna, Delivered in cardboard box © 2019 EnOcean | www.enocean.com F-710-017, V1.0 PTM 535 / 535J User Manual | v1.5 | September 2020 | Page 8/36... -
Page 9: Functional Description
Functional Principle PTM 535 is designed to be powered by an ECO 200 kinetic energy harvester from EnOcean. PTM 535 can be mechanically connected to the contact springs of ECO 200 by means of its integrated PCB contacts. PTM 535 provides 4 digital input pads and two PCB meander structures allowing the imple- mentation of push button functions either via external connection or via conductive rubber pads. -
Page 10: Interface Pin Layout
PTM 535 / PTM 535U / PTM 535J – ENOCEAN TRANSMITTER MODULE Interface pin layout Figure 3 below shows the pin out and external interfaces of PTM 535 as seen from the top (component side). Items marked in green are on the component side while items in grey are on the bottom side. -
Page 11: Interface Pin Functionality
50 Ohm output for external antenna Test pin Do not connect Table 1 – PTM 535 interface pin functionality © 2019 EnOcean | www.enocean.com F-710-017, V1.0 PTM 535 / 535J User Manual | v1.5 | September 2020 | Page 11/36... -
Page 12: Radio Telegram Format
PTM 535 / PTM 535U / PTM 535J – ENOCEAN TRANSMITTER MODULE Radio telegram format Standard mode In standard configuration, PTM 535 transmits the same telegram type as the PTM 210 pushbutton module. The telegram information is encoded within a 7 byte RPS telegram as shown in Figure 4 below. - Page 13 The DATA field format of such N-Message is shown in Figure 7 below. Figure 7 – DATA field format for U-Messages (no, three or four button pressed) © 2019 EnOcean | www.enocean.com F-710-017, V1.0 PTM 535 / 535J User Manual | v1.5 | September 2020 | Page 13/36...
-
Page 14: Enhanced Security Mode
The initial counter value is transmitted from PTM 535 to the receiver as part of the teach-in telegram when entering secure mode. Subsequent secure telegrams do not specify this counter value;... -
Page 15: Switching Between Operation Modes
PTM 535 can be switched from standard mode (default) to enhanced security mode by con- necting SECURE with VCC_MODE (see chapter 3 for details) and triggering the ECO 200. Upon entry into enhanced security mode, a teach-in telegram is sent by PTM 535. The type of the teach-in telegram (Teach_In_Info : Type) is: 1-PTM. -
Page 16: Ptm 535 Configuration
2 subtelegrams. If PTM 535 is powered by another energy source such as a battery and operating in enhanced security mode, then it can be selected if it should transmit 2 or 3 subtele- grams. -
Page 17: Ptm 535 Configuration Interface
PTM 535 / PTM 535U / PTM 535J – ENOCEAN TRANSMITTER MODULE PTM 535 configuration interface The PTM 535 configuration interface consists of test points MP1- MP6. The function of these test points is summarized in Table 2 below. Signal... -
Page 18: Connection Between Segger J-Link And Ptm 535
Supplying power by Segger J-Link to PTM 535 is the recommended approach. It requires a 6 pin test interface. In this case, power is supplied by Segger J-Link to PTM 535 via PTM 535 MP5 (V+) con- nected to Segger Pin 19. The “5V Target Power Supply” option has to be activated at the Segger user interface. -
Page 19: External Power Supply (4 Pin Configuration Interface)
Existing 4 needle adapters built for PTM 335 can be reused. It requires to supply PTM 535 by an external power supply (2.0 - 3.3 V) connected to PTM 535 MP1 and to Segger VTref (IO voltage reference). The external power supply ground has to be connected to PTM 535 MP2 (GND) and Segger GND. -
Page 20: Required Tools
PTM 535 Configurator uses Segger tools to communicate with the radio chip. If a window pops up “to unlock” the device you must select NO (details see PTM 535 Config help). Due to radio approval requirements a wrong configuration will lead the module to stop radio transmission. -
Page 21: Configuration Setup
Figure 13 below shows the user interface of the PTM 535 Configurator. Figure 13 – User interface of PTM 535 Configurator © 2019 EnOcean | www.enocean.com F-710-017, V1.0 PTM 535 / 535J User Manual | v1.5 | September 2020 | Page 21/36... -
Page 22: Execution Sequence
“Write to PTM 535” the modified configuration to additional module Quit Segger info window with no (details see PTM Config help)! PTM 535 Configurator uses Segger tools to communicate with the radio chip. If a window pops up “to unlock” the device, you must select NO (for details, see PTM 535 Config help). -
Page 23: Application Information
How to populate a teach-in button (for enhanced security mode) PTM 535 provides two landing pads for a LRN button called SECURE and VCC_MODE. If a pushbutton is mounted then this will act as secure teach-in button. By pressing the button and triggering the ECO 200, the secure teach-in process is triggered, the module switches to secure mode and transmits a secure teach-in telegram. -
Page 24: Antenna Specification
Figure 15 – Whip antenna specification PTM 535: L=86 mm, PTM 535U / PTM 535J: L = 64 mm © 2019 EnOcean | www.enocean.com F-710-017, V1.0 PTM 535 / 535J User Manual | v1.5 | September 2020 | Page 24/36... -
Page 25: Layout Recommendations
Figure 16 – PCB footprint for PTM 535 Figure 17 below shows the required keep out area on a host PCB form PTM 535. No copper surface area is allowed within this area. Figure 17 – Keep out area on host PCB for PTM 535 ©... -
Page 26: Transmission Range
The following figures for expected transmission range are considered by using a PTM 535 radio transmitter device and a TCM 310 / TCM 310U / TCM 410J radio receiver device with... -
Page 27: Regulatory Information
At the time of writing, the text of the RED legislation was available from this link: http://eur-lex.europa.eu/eli/dir/2014/53/oj Dolphin radio modules such as PTM 535 are components which are delivered to OEM manu- facturers for their use in final or combined products. -
Page 28: Fcc (United States)
PTM 535 / PTM 535U / PTM 535J – ENOCEAN TRANSMITTER MODULE FCC (United States) 6.2.1 FCC grant of equipment authorization © 2019 EnOcean | www.enocean.com F-710-017, V1.0 PTM 535 / 535J User Manual | v1.5 | September 2020 | Page 28/36... -
Page 29: Fcc Regulatory Statement
Connect the equipment into an outlet on a circuit different from that to which the ◼ receiver is connected. Consult the dealer or an experienced radio/TV technician for help. ◼ © 2019 EnOcean | www.enocean.com F-710-017, V1.0 PTM 535 / 535J User Manual | v1.5 | September 2020 | Page 29/36... -
Page 30: Ised (Canada)
PTM 535 / PTM 535U / PTM 535J – ENOCEAN TRANSMITTER MODULE ISED (Canada) 6.3.1 ISED technical acceptance certificate © 2019 EnOcean | www.enocean.com F-710-017, V1.0 PTM 535 / 535J User Manual | v1.5 | September 2020 | Page 30/36... - Page 31 USER MANUAL PTM 535 / PTM 535U / PTM 535J – ENOCEAN TRANSMITTER MODULE © 2019 EnOcean | www.enocean.com F-710-017, V1.0 PTM 535 / 535J User Manual | v1.5 | September 2020 | Page 31/36...
-
Page 32: Ised Regulatory Statement
Connect the equipment into an outlet on a circuit different from that to which the ◼ receiver is connected. Consult the dealer or an experienced radio/TV technician for help ◼ © 2019 EnOcean | www.enocean.com F-710-017, V1.0 PTM 535 / 535J User Manual | v1.5 | September 2020 | Page 32/36... -
Page 33: 6.3.2.2 French Version
Connecter l'équipement à une sortie sur un circuit différent de celui sur lequel le ré- ◼ cepteur est branché. Consulter le revendeur ou un technicien radio / télévision expérimenté pour de l'aide ◼ © 2019 EnOcean | www.enocean.com F-710-017, V1.0 PTM 535 / 535J User Manual | v1.5 | September 2020 | Page 33/36... -
Page 34: Arib (Japan)
USER MANUAL PTM 535 / PTM 535U / PTM 535J – ENOCEAN TRANSMITTER MODULE ARIB (Japan) 6.4.1 ARIB (Japan) certificate © 2019 EnOcean | www.enocean.com F-710-017, V1.0 PTM 535 / 535J User Manual | v1.5 | September 2020 | Page 34/36... - Page 35 PTM 535J has been designed and tested to fulfil the approval requirements for ARIB STD- T108 based on the built-in firmware. When products using PTM 535 are placed on the Japanese market, they must carry the Specified Radio Equipment marking.
- Page 36 USER MANUAL PTM 535 / PTM 535U / PTM 535J – ENOCEAN TRANSMITTER MODULE Product history Table 4 below outlines the product history of PTM 535 and indicates key changes made be- tween different revisions. Revision Introduction Key features / changes...
