USER MANUAL
PTM 210 / PTM 215 / PTM 215U / PTM 215J
DC Step code and later
PTM 210 / PTM 215
PTM 215U
PTM 215J
Pushbutton transmitter modules
DC Step code and later
The product is protected by the following granted Patents:
US7710227, DE10315765B4
US9614553, EP1312171B1, CN100508406C
EP1389358B1, JP4225792B2
US7019241, EP1550202B1, DE50303733D1, CN1689218B
US7391135, EP1611663B1, DE10315764B4,
US8502470, JP5617103B2
EP2524572B1
And also by pending or not yet published Patents and Designs.
© 2020 EnOcean | www.enocean.com
PTM 210 / PTM 215 / PTM 215U / PTM 215J / User Manual Page 1/48
