O P E R A T I N G I N S T R U C T I O N S
C4000 Select Ex
Safety light curtain

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the C4000 Select Ex and is the answer not in the manual?

Questions and answers

Related Manuals for SICK C4000 Select Ex

Summary of Contents for SICK C4000 Select Ex

  • Page 1 O P E R A T I N G I N S T R U C T I O N S C4000 Select Ex Safety light curtain...
  • Page 2 Original document This document is an original document of SICK AG. O P E R A T I N G I N S T R U C T I O N S | C4000 Select Ex 8017025/1DVD/2023-04-28 | SICK Subject to change without notice...

  • Page 3: Table Of Contents

    List of figures..................33 List of tables..................34 8017025/1DVD/2023-04-28 | SICK O P E R A T I N G I N S T R U C T I O N S | C4000 Select Ex Subject to change without notice...

  • Page 4: About This Document

    This document is included with the following SICK part numbers (this document in all available language versions): 8017106/1DVD O P E R A T I N G I N S T R U C T I O N S | C4000 Select Ex 8017025/1DVD/2023-04-28 | SICK Subject to change without notice...

  • Page 5: Safety Information

    In areas where there may be flying sparks 8017025/1DVD/2023-04-28 | SICK O P E R A T I N G I N S T R U C T I O N S | C4000 Select Ex Subject to change without notice...

  • Page 6: General Safety Notes

    Follow all safety notes in this document. ► O P E R A T I N G I N S T R U C T I O N S | C4000 Select Ex 8017025/1DVD/2023-04-28 | SICK Subject to change without notice...
  • Page 7 • Joint between cover and explosion-proof enclosure 8017025/1DVD/2023-04-28 | SICK O P E R A T I N G I N S T R U C T I O N S | C4000 Select Ex Subject to change without notice...

  • Page 8: Mounting

    ► during mounting, electrical installation, and commissioning. O P E R A T I N G I N S T R U C T I O N S | C4000 Select Ex 8017025/1DVD/2023-04-28 | SICK Subject to change without notice...

  • Page 9: Unpacking

    8017025/1DVD/2023-04-28 | SICK O P E R A T I N G I N S T R U C T I O N S | C4000 Select Ex Subject to change without notice...

  • Page 10: Mount The Safety Light Curtain In The Explosion-Proof Enclosure

    Nm. Too high a torque could damage the swivel mount brackets while too low a torque does not provide sufficient protection against vibration. O P E R A T I N G I N S T R U C T I O N S | C4000 Select Ex 8017025/1DVD/2023-04-28 | SICK...
  • Page 11 Measure the distance from the end of the cover to the first rib. Detailed view 8017025/1DVD/2023-04-28 | SICK O P E R A T I N G I N S T R U C T I O N S | C4000 Select Ex Subject to change without notice...

  • Page 12: Mounting The Optional Cable Gland

    Tighten the screws with a torque of 4.5 to 5 Nm. O P E R A T I N G I N S T R U C T I O N S | C4000 Select Ex 8017025/1DVD/2023-04-28 | SICK...

  • Page 13: Mounting The Safety Light Curtain

    Figure 4: The sender and receiver are mounted incorrectly 8017025/1DVD/2023-04-28 | SICK O P E R A T I N G I N S T R U C T I O N S | C4000 Select Ex Subject to change without notice...

  • Page 14: Mounting The Safety Light Curtain Without The Alignment Bracket

    O P E R A T I N G I N S T R U C T I O N S | C4000 Select Ex 8017025/1DVD/2023-04-28 | SICK...
  • Page 15 M8 screws. Tighten the two lower M8 screws. 8017025/1DVD/2023-04-28 | SICK O P E R A T I N G I N S T R U C T I O N S | C4000 Select Ex Subject to change without notice...

  • Page 16: Mounting The Safety Light Curtain Using The Alignment Brackets

    Figure 9: Mounting the safety light curtain using the alignment brackets Figure 10: Assembling the alignment brackets O P E R A T I N G I N S T R U C T I O N S | C4000 Select Ex 8017025/1DVD/2023-04-28 | SICK...
  • Page 17 8017025/1DVD/2023-04-28 | SICK O P E R A T I N G I N S T R U C T I O N S | C4000 Select Ex Subject to change without notice...
  • Page 18 11. Turn the safety light curtains so that they face one another and so that the receiver receives the strongest signal possible. O P E R A T I N G I N S T R U C T I O N S | C4000 Select Ex 8017025/1DVD/2023-04-28 | SICK...
  • Page 19 28.5 Nm in order to secure the safety light curtain in this position. 8017025/1DVD/2023-04-28 | SICK O P E R A T I N G I N S T R U C T I O N S | C4000 Select Ex Subject to change without notice...

  • Page 20: Electrical Installation

    Do not reconnect the power supply until you have completed the electrical installa‐ ► tion. O P E R A T I N G I N S T R U C T I O N S | C4000 Select Ex 8017025/1DVD/2023-04-28 | SICK Subject to change without notice...

  • Page 21: Minimum Wire Cross-Section For Protection Earth (Pe)

    S S ≤ 16 mm 16 mm  < S ≤ 35 mm 16 mm S > 35 mm 0.5 S 8017025/1DVD/2023-04-28 | SICK O P E R A T I N G I N S T R U C T I O N S | C4000 Select Ex Subject to change without notice...

  • Page 22: Aligning The Sender And Receiver

    Rotate the receiver to align the receiver to the sender. ► O P E R A T I N G I N S T R U C T I O N S | C4000 Select Ex 8017025/1DVD/2023-04-28 | SICK Subject to change without notice...
  • Page 23 8017025/1DVD/2023-04-28 | SICK O P E R A T I N G I N S T R U C T I O N S | C4000 Select Ex Subject to change without notice...

  • Page 24: Maintenance

    Check the effectiveness of the protective device. You will find information on how to check the effectiveness in the underlying operating instructions. O P E R A T I N G I N S T R U C T I O N S | C4000 Select Ex 8017025/1DVD/2023-04-28 | SICK...

  • Page 25: Technical Data

    1200 46.20 46.16 Tolerance: ± 50 g. 8017025/1DVD/2023-04-28 | SICK O P E R A T I N G I N S T R U C T I O N S | C4000 Select Ex Subject to change without notice...

  • Page 26: Dimensional Drawings

    142,1 Figure 17: Dimensional drawing, sender and receiver, protective field height 600 mm O P E R A T I N G I N S T R U C T I O N S | C4000 Select Ex 8017025/1DVD/2023-04-28 | SICK...
  • Page 27 Figure 18: Dimensional drawing, sender and receiver, protective field height 900 mm 8017025/1DVD/2023-04-28 | SICK O P E R A T I N G I N S T R U C T I O N S | C4000 Select Ex Subject to change without notice...
  • Page 28 142,1 Figure 19: Dimensional drawing, sender and receiver, protective field height 1,200 mm O P E R A T I N G I N S T R U C T I O N S | C4000 Select Ex 8017025/1DVD/2023-04-28 | SICK...

  • Page 29: Ordering Information

    1200 1068395 EXS-12B6603B020 1068394 EXE-12B6603B020 1068393 EXP-12B6603B020 8017025/1DVD/2023-04-28 | SICK O P E R A T I N G I N S T R U C T I O N S | C4000 Select Ex Subject to change without notice...

  • Page 30: Accessories

    Part number Connecting cable M12, 5-pin (0.34 mm O P E R A T I N G I N S T R U C T I O N S | C4000 Select Ex 8017025/1DVD/2023-04-28 | SICK Subject to change without notice...

  • Page 31: Alignment Aid

    Laser alignment aid AR60 1015741 Adapter 2074849 8017025/1DVD/2023-04-28 | SICK O P E R A T I N G I N S T R U C T I O N S | C4000 Select Ex Subject to change without notice...

  • Page 32: Annex

    MACHINERY DIRECTIVE 2006/42/EC • ATEX DIRECTIVE 2014/34/EU O P E R A T I N G I N S T R U C T I O N S | C4000 Select Ex 8017025/1DVD/2023-04-28 | SICK Subject to change without notice...

  • Page 33: List Of Figures

    20. Dimensional drawing, swivel mount bracket (2074530).........30 21. Dimensional drawing, alignment bracket (2072525)..........30 8017025/1DVD/2023-04-28 | SICK O P E R A T I N G I N S T R U C T I O N S | C4000 Select Ex Subject to change without notice...

  • Page 34: List Of Tables

    Cable gland ordering information................31 Ordering information for power supply..............31 O P E R A T I N G I N S T R U C T I O N S | C4000 Select Ex 8017025/1DVD/2023-04-28 | SICK Subject to change without notice...
  • Page 35 LIST OF TABLES 8017025/1DVD/2023-04-28 | SICK O P E R A T I N G I N S T R U C T I O N S | C4000 Select Ex Subject to change without notice...
