- Page 1 O P E R A T I N G I N S T R U C T I O N S C4000 Advanced Ex Safety light curtain...
- Page 2 Original document This document is an original document of SICK AG. O P E R A T I N G I N S T R U C T I O N S | C4000 Advanced Ex 8017027/1DVD/2023-04-28 | SICK Subject to change without notice...
-
Page 3: Table Of Contents
List of figures..................34 List of tables..................35 8017027/1DVD/2023-04-28 | SICK O P E R A T I N G I N S T R U C T I O N S | C4000 Advanced Ex Subject to change without notice... -
Page 4: About This Document
This document is included with the following SICK part numbers (this document in all available language versions): 8017105/1DVD O P E R A T I N G I N S T R U C T I O N S | C4000 Advanced Ex 8017027/1DVD/2023-04-28 | SICK Subject to change without notice... -
Page 5: Safety Information
In areas where there may be flying sparks 8017027/1DVD/2023-04-28 | SICK O P E R A T I N G I N S T R U C T I O N S | C4000 Advanced Ex Subject to change without notice... -
Page 6: General Safety Notes
Follow all safety notes in this document. ► O P E R A T I N G I N S T R U C T I O N S | C4000 Advanced Ex 8017027/1DVD/2023-04-28 | SICK Subject to change without notice... - Page 7 • Joint between cover and explosion-proof enclosure 8017027/1DVD/2023-04-28 | SICK O P E R A T I N G I N S T R U C T I O N S | C4000 Advanced Ex Subject to change without notice...
-
Page 8: Mounting
► during mounting, electrical installation, and commissioning. O P E R A T I N G I N S T R U C T I O N S | C4000 Advanced Ex 8017027/1DVD/2023-04-28 | SICK Subject to change without notice... -
Page 9: Unpacking
Recommended tool: curved box wrench. Install the cable glands if necessary. 8017027/1DVD/2023-04-28 | SICK O P E R A T I N G I N S T R U C T I O N S | C4000 Advanced Ex Subject to change without notice... -
Page 10: Mount The Safety Light Curtain In The Explosion-Proof Enclosure
Nm. Too high a torque could damage the swivel mount brackets while too low a torque does not provide sufficient protection against vibration. O P E R A T I N G I N S T R U C T I O N S | C4000 Advanced Ex 8017027/1DVD/2023-04-28 | SICK... - Page 11 Measure the distance from the end of the cover to the first rib. Detailed view 8017027/1DVD/2023-04-28 | SICK O P E R A T I N G I N S T R U C T I O N S | C4000 Advanced Ex Subject to change without notice...
-
Page 12: Mounting The Optional Cable Gland
Tighten the screws with a torque of 4.5 to 5 Nm. O P E R A T I N G I N S T R U C T I O N S | C4000 Advanced Ex 8017027/1DVD/2023-04-28 | SICK... -
Page 13: Mounting The Safety Light Curtain
Figure 4: The sender and receiver are mounted incorrectly 8017027/1DVD/2023-04-28 | SICK O P E R A T I N G I N S T R U C T I O N S | C4000 Advanced Ex Subject to change without notice... -
Page 14: Mounting The Safety Light Curtain Without The Alignment Bracket
O P E R A T I N G I N S T R U C T I O N S | C4000 Advanced Ex 8017027/1DVD/2023-04-28 | SICK... - Page 15 M8 screws. Tighten the two lower M8 screws. 8017027/1DVD/2023-04-28 | SICK O P E R A T I N G I N S T R U C T I O N S | C4000 Advanced Ex Subject to change without notice...
-
Page 16: Mounting The Safety Light Curtain Using The Alignment Brackets
Figure 9: Mounting the safety light curtain using the alignment brackets Figure 10: Assembling the alignment brackets O P E R A T I N G I N S T R U C T I O N S | C4000 Advanced Ex 8017027/1DVD/2023-04-28 | SICK... - Page 17 8017027/1DVD/2023-04-28 | SICK O P E R A T I N G I N S T R U C T I O N S | C4000 Advanced Ex Subject to change without notice...
- Page 18 11. Turn the safety light curtains so that they face one another and so that the receiver receives the strongest signal possible. O P E R A T I N G I N S T R U C T I O N S | C4000 Advanced Ex 8017027/1DVD/2023-04-28 | SICK...
- Page 19 28.5 Nm in order to secure the safety light curtain in this position. 8017027/1DVD/2023-04-28 | SICK O P E R A T I N G I N S T R U C T I O N S | C4000 Advanced Ex Subject to change without notice...
-
Page 20: Electrical Installation
Do not reconnect the power supply until you have completed the electrical installa‐ ► tion. O P E R A T I N G I N S T R U C T I O N S | C4000 Advanced Ex 8017027/1DVD/2023-04-28 | SICK Subject to change without notice... -
Page 21: Minimum Wire Cross-Section For Protection Earth (Pe)
S S ≤ 16 mm 16 mm < S ≤ 35 mm 16 mm S > 35 mm 0.5 S 8017027/1DVD/2023-04-28 | SICK O P E R A T I N G I N S T R U C T I O N S | C4000 Advanced Ex Subject to change without notice... -
Page 22: Aligning The Sender And Receiver
Rotate the receiver to align the receiver to the sender. ► O P E R A T I N G I N S T R U C T I O N S | C4000 Advanced Ex 8017027/1DVD/2023-04-28 | SICK Subject to change without notice... - Page 23 8017027/1DVD/2023-04-28 | SICK O P E R A T I N G I N S T R U C T I O N S | C4000 Advanced Ex Subject to change without notice...
-
Page 24: Maintenance
Check the effectiveness of the protective device. You will find information on how to check the effectiveness in the underlying operating instructions. O P E R A T I N G I N S T R U C T I O N S | C4000 Advanced Ex 8017027/1DVD/2023-04-28 | SICK... -
Page 25: Technical Data
1200 44.55 44.58 Tolerance: ± 50 g. 8017027/1DVD/2023-04-28 | SICK O P E R A T I N G I N S T R U C T I O N S | C4000 Advanced Ex Subject to change without notice... -
Page 26: Dimensional Drawings
142,1 Figure 17: Dimensional drawing, sender and receiver, protective field height 600 mm O P E R A T I N G I N S T R U C T I O N S | C4000 Advanced Ex 8017027/1DVD/2023-04-28 | SICK... - Page 27 Figure 18: Dimensional drawing, sender and receiver, protective field height 900 mm 8017027/1DVD/2023-04-28 | SICK O P E R A T I N G I N S T R U C T I O N S | C4000 Advanced Ex Subject to change without notice...
- Page 28 142,1 Figure 19: Dimensional drawing, sender and receiver, protective field height 1,200 mm O P E R A T I N G I N S T R U C T I O N S | C4000 Advanced Ex 8017027/1DVD/2023-04-28 | SICK...
-
Page 29: Ordering Information
1200 1068404 EXS-12C6603B020 1068403 EXE-12C6603B020 1068402 EXP-12C6603B020 8017027/1DVD/2023-04-28 | SICK O P E R A T I N G I N S T R U C T I O N S | C4000 Advanced Ex Subject to change without notice... -
Page 30: Accessories
90,5 Figure 21: Dimensional drawing, mounting bracket with riser (2074626) O P E R A T I N G I N S T R U C T I O N S | C4000 Advanced Ex 8017027/1DVD/2023-04-28 | SICK Subject to change without notice... -
Page 31: Connectivity
NEC Class 2, SELV, PELV, input 100 V AC … 120 V / 220 V AC … 240 V AC 8017027/1DVD/2023-04-28 | SICK O P E R A T I N G I N S T R U C T I O N S | C4000 Advanced Ex Subject to change without notice... -
Page 32: Alignment Aid
Laser alignment aid AR60 1015741 Adapter 2074849 O P E R A T I N G I N S T R U C T I O N S | C4000 Advanced Ex 8017027/1DVD/2023-04-28 | SICK Subject to change without notice... -
Page 33: Annex
MACHINERY DIRECTIVE 2006/42/EC • ATEX DIRECTIVE 2014/34/EU 8017027/1DVD/2023-04-28 | SICK O P E R A T I N G I N S T R U C T I O N S | C4000 Advanced Ex Subject to change without notice... -
Page 34: List Of Figures
21. Dimensional drawing, mounting bracket with riser (2074626)......30 22. Dimensional drawing, alignment bracket (2072525)..........31 O P E R A T I N G I N S T R U C T I O N S | C4000 Advanced Ex 8017027/1DVD/2023-04-28 | SICK... -
Page 35: List Of Tables
Order information for cable (ready to assemble)............31 Ordering information for power supply..............31 8017027/1DVD/2023-04-28 | SICK O P E R A T I N G I N S T R U C T I O N S | C4000 Advanced Ex Subject to change without notice... - Page 36 Phone +65 6744 3732 Phone +30 210 6825100 Phone +65 6744 3732 E-Mail sales.gsg@sick.com E-Mail office@sick.com.gr E-Mail sales.gsg@sick.com Hong Kong Slovakia Phone +852 2153 6300 Phone +421 482 901 201 E-Mail ghk@sick.com.hk E-Mail mail@sick-sk.sk Detailed addresses and further locations at www.sick.com SICK AG | Waldkirch | Germany | www.sick.com...
