Page 1 Safety Light Curtain F3SG-□RR Series User's Manual Cat. No. Z383-E1-04 http://www.ia.omron.com/f3sg-r...
Page 2 Original instructions Introduction Thank you for purchasing the F3SG-RR Series Safety Light Curtain (hereinafter referred to as the "F3SG-RR" ). This is the instruction Manual describing the use of F3SG-RR. Always heed the following points when using the F3SG-RR: Be sure to have F3SG-RR be handled by a "Responsible Person" who is well aware of and familiar with the machine to be installed. The term "Responsible Person"...
Page 3 Legislation and Standards 1. The F3SG-RR does not receive type approval provided by Article 44-2 of the Industrial Safety and Health Act of Japan. When using the F3SG-RR in Japan as a "safety system for pressing or shearing machines" prescribed in Article 42 of that law, the machine control system must receive type approval. 2.
Page 4 6. Other Standards The F3SG-RR is designed according to the standards listed below. To make sure that the final system complies with the following standards and regulations, you are asked to design and use it in accordance with all other related standards, laws, and regulations. If you have any questions, consult with specialized organizations such as the body responsible for prescribing and/or enforcing machinery safety regulations in the location where the equipment is to be used.
Page 5: Terms And Conditions Agreement
Terms and Conditions Agreement Warranties. (a) Exclusive Warranty. Omron's exclusive warranty is that the Products will be free from defects in materials and workmanship for a period of twelve months from the date of sale by Omron (or such other period expressed in writing by Omron).
Page 6 Programmable Products. Omron Companies shall not be responsible for the user's programming of a programmable Product, or any consequence thereof. Performance Data. Data presented in Omron Company websites, catalogs and other materials is provided as a guide for the user in determining suitability and does not constitute a warranty.
Page 7: Safety Precautions
Safety Precautions Indications and Meanings for Safe Use The precautions listed in this document indicated by alert symbols and statements must be followed for the safe use of the F3SG-RR. Failure to follow all precautions and alerts may result in an unsafe use or operation. The following word and symbols are used in this document.
Page 8 For machines Do not use this sensor for machines that cannot be stopped by electrical control. For example, do not use it for a pressing machine that uses full-rotation clutch. Otherwise, the machine may not stop before a person reaches the hazardous part, resulting in serious injury. To use F3SG-RR in PSDI mode (initiation of cycle operations by a presence sensing device), you must configure an appropriate circuit between F3SG-RR and the machine.For details about PSDI, refer to OSHA1910.217, IEC61496-1, and other relevant standards and regulations.
Page 9 Detection capability gets larger when fixed/floating blanking or reduced resolution function is used. When these functions are used, the safety distance calculation must be based on the increased detection capability for these functions. Otherwise the machine may not stop before a person reaches to the hazardous part, resulting in serious injury.
Page 10 Make sure to connect an override cancel switch to the Reset line when using the override function. Otherwise the override state may not be released by the override cancel switch, resulting in serious injury. When muting error occurs with workpiece blocking the F3SG-RR, there are two methods to forcibly remove the workpiece.
Page 11 For wiring When using the PNP output, connect the load between the output and 0 V line. When using the NPN output, connect the load between the output and +24 VDC line. Connecting the load between the output and a different power supply line from the above will result in a dangerous condition because the operation mode of safety output is reversed to "Dark-ON".
Page 12 Settings Some settings of functions or the setting recovery function configurable with the configuration software, SD Manager 2 (hereinafter referred to as "Configuration Tool") may increase risks. Make sure the Responsible Person conduct a thorough risk assessment analysis before managing and changing the settings. Unintended changes to the settings may cause a person go to undetected, resulting in serious injury.
Page 13: Precautions For Safe Use
Precautions for Safe Use Make sure to observe the following precautions that are necessary for ensuring safe use of the product. Do not install, use, or store the F3SG-RR in the following types of environments: - Areas exposed to intense interference light, such as direct sunlight - Areas with high humidity where condensation is likely to occur - Areas where corrosive gases are present - Areas exposed to vibration or shock levels higher than in the specification provisions...
Page 14: Precautions For Correct Use
Precautions for Correct Use Observe the precautions described below to prevent operation failure, malfunctions, or undesirable effects on product performance.  Storage conditions and installation environment • Do not install, use, or store the F3SG-RR in the following types of environments: - For a long time at a temperature or humidity out of the specified range - Areas submerged in water or subject to rain water •...
Page 15  Oil resistance The F3SG-RR passed the testing for the resistance to the oils listed in the table below. Refer to the table for selection of lubricant or cutting oils to be used. Test Oil Type JIS Type Product Name Manufacturer Yushiroken EC50T3 Yushiroken FGE366...
Page 16: Visual Aids
Visual Aids The following symbols appear in this document to help you locate different types of information. Indicates important information or advice on a function or operation of the product. Indicates page numbers or chapter title of related information. F3SG-RR User’s Manual...
Page 17: Table Of Contents
Table of Contents Legislation and Standards Terms and Conditions Agreement Safety Precautions Precautions for Safe Use Precautions for Correct Use Visual Aids Chapter1 Overview and Specifications 1-1. What is Included 1-2. System Components 1-2-1. Basic Components 1-3. List of Features 1-3-1.
Page 18 2-5-3. Setting with Configuration Tool 2-6. Self-Test 2-6-1. Overview 2-6-1-1. Self-Test details 2-6-1-2. Waveform of safety outputs 2-7. External Test 2-7-1. Overview 2-7-2. Factory Default Setting 2-7-3. Setting 2-7-4. Setting with Configuration Tool 2-8. Lockout Reset 2-8-1. Overview 2-9. Interlock 2-9-1.
Page 19 2-15-1.Overview 2-15-2.Factory Default Setting 2-15-3.Setting with Configuration Tool 2-16. Reduced Resolution 2-16-1.Overview 2-16-2.Factory Default Setting 2-16-3.Setting with Configuration Tool 2-17. Warning Zone 2-17-1.Overview 2-17-2.Factory Default Setting 2-17-3.Setting with Configuration Tool 2-18. Setting Zone Adjacency Conditions 2-19. Response Time Adjustment 2-19-1.Overview 2-19-2.Factory Default Setting 2-19-3.Setting with Configuration Tool 2-20.
Page 20 2-25-1.Overview Chapter3 Setting with Rotary Switch and End Cap 3-1. List of Features Configurable by Rotary Switch 3-2. Rotary Switch 3-3. List of Features Configurable by End Cap 3-4. End Cap Chapter4 Wiring/Installation 4-1. Installation Considerations 4-1-1. Detection Zone and Approach 4-1-2.
Page 21 4-3-5-2. Connected with Bluetooth Communication Unit (F39-BT) ® 4-3-5-3. Connected with Lamp (F39-LP) or Lamp and Bluetooth Communication Unit (F39-BTLP) ® 4-4. Mounting 4-4-1. Mounting Method 4-4-2. Number of Brackets Required 4-4-3. Mounting Procedure 4-4-3-1. Mounting with Free-Location Brackets (F39-LGRA) 4-4-3-2.
Page 22 5-2-3-1. Auto Reset Mode, EDM enabled and NPN Outputs 5-2-3-2. Manual Reset Mode, EDM disabled and NPN Outputs 5-2-3-3. Replacing the F3SJ-B Safety Light Curtain with F3SG-RR 5-2-3-4. F3SG-RR with Reduced Wiring Connector and NPN Outputs 5-2-3-5. Pre-Reset Mode using NPN Output 5-2-4.
Page 23: Chapter1 Overview And Specifications
Chapter 1 Overview and Specifications 1-1. What is Included 1-2. System Components 1-2-1. Basic Components 1-3. List of Features 1-3-1. Model Overview 1-3-2. List of Features 1-4. LED Indicators 1-4-1. LED Indicator Status 1-5. Ratings/Specifications 1-6. List of Models 1-6-1. List of Models/Response Time/Current Consumption/Weight 1-6-2.
Page 24: What Is Included
Overview and Specifications 1-1. What is Included Before use, confirm that the items below are included with the product. If you find that an item is missing, please contact your local branch office or distributor. Product Quantity F3SG-RR main unit Emitter x 1, Receiver x 1 Warning Zone Label Troubleshooting Guide Sticker...
Page 25: System Components
Overview and Specifications 1-2. System Components This section describes the system components and part names of the F3SG-RR system. Beam center-line mark End cap Beam End cap Emitter Receiver Rotary Switch Indicator Functional earth terminal Functional earth terminal Rotary Switch Power Cable (Gray) Power Cable...
Page 26: Basic Components
Overview and Specifications 1-2-1. Basic Components Component Model name Description Emitter, receiver F3SG-RR-- Select a model name based on the required protective height. The model name can be understood as follows: F3SG- RR 1: ESPE type (4: Type 4) 2: Protective height (mm) 3: Object resolution (mm) 4: L: Emitter, D: Receiver, blank: Emitter and receiver.
Page 27: List Of Features
Overview and Specifications 1-3. List of Features 1-3-1. Model Overview The F3SG-RR series is an advance model, allowing you to configure the safety light curtain to fit your application. Refer to the List of Features below for available features. 1-3-2. List of Features The F3SG-RR safety light curtain family has the following features.
Page 28: Led Indicators
Overview and Specifications 1-4. LED Indicators <Emitter> <Receiver> 1. Top-beam-state indicator (Blue) 2. PNP/NPN mode indicator (Green) 3. Response time indicator (Green) 4. Sequence error indicator (Yellow) 5. Blanking indicator (Green) 6. Configuration indicator (Green) 7. Interlock indicator (Yellow) 1. Test indicator (Green) 8.
Page 29: Led Indicator Status
Overview and Specifications 1-4-1. LED Indicator Status Shown below are the of factory default indication statuses of F3SG-RR LED indicators. Emitter Location Name of Indicator Color Illuminated Blinking Test TEST Green External Test is being performed Lockout state due to Scan code Operating range LONG Green Always illuminated...
Page 30: Ratings/Specifications
Overview and Specifications 1-5. Ratings/Specifications □□□□ in the model names indicate the protective heights in millimeters. F3SG-4RR-14 F3SG-4RR-25 Performance Object Resolution Opaque objects (Detection Capability) 14-mm dia. 25-mm dia. Beam Gap 10 mm 20 mm Number of Beams 23 to 191 12 to 96 Lens Size 5.2 ×...
Page 31 Overview and Specifications F3SG-4RR-14 F3SG-4RR-25 Overvoltage Category (IEC 60664-1) Indicators 1-4-1. LED Indicator Status Protective Circuit Output short protection, Power supply reverse polarity protection Insulation Resistance 20 M or higher (500 VDC megger) Dielectric Strength 1,000 VAC, 50/60 Hz (1 min) Functional Mutual Interference Prevention This function prevents mutual interference in up to two F3SG-RR systems.
Page 32 Overview and Specifications F3SG-4RR-14 F3SG-4RR-25 Type of M12 connectors: 8-pin emitter and receiver. IP67 rated when mated. Connection Number of Emitter: 5, Receiver: 8 Wires Cable 0.3 m Cascading cable Length Cable 6 mm Diameter Minimum Bending R5 mm Radius Type of M12 connectors: 8-pin emitter and receiver.
Page 33: List Of Models
Overview and Specifications 1-6. List of Models 1-6-1. List of Models/Response Time/Current Consumption/Weight □□□□  F3SG-4RR Current Response Time[ms] *1 Consumption Weight [kg] Protective Height [mA] Number Model [mm] of Beams OFF (Not (Overall Gross length) ON→OFF *2 (Synchronized) synchronized) Emitter Receiver →ON *3 →ON *3...
Page 34 Overview and Specifications Current Response Time[ms] *1 Consumption Weight [kg] Protective Height [mA] Number Model [mm] of Beams OFF (Not (Overall Gross length) ON→OFF *2 (Synchronized) synchronized) Emitter Receiver →ON *3 →ON *3 F3SG-4RR1120-25 1120 F3SG-4RR1200-25 1200 F3SG-4RR1280-25 1280 F3SG-4RR1360-25 1360 F3SG-4RR1440-25 1440...
Page 35: Calculation Of Response Time Of Cascaded Segments
Overview and Specifications 1-6-2. Calculation of Response Time of Cascaded Segments The F3SG-RR can be used in cascade connection. In case of a cascade connection, a response time is determined by the total number of beams. If the total number of beams of all F3SG-RR in a cascade connection is 140 or less, its response time is 12 ms (Code A)/13 ms (Code B).
Page 36 Overview and Specifications F3SG-RR User’s Manual...
Page 37: Chapter2 System Operation And Functions
Chapter 2 System Operation and Functions 2-1. Combination of Functions 2-2. Operating States 2-3. Optical Synchronization 2-4. Scan Code Selection 2-5. PNP/NPN Selection 2-6. Self-Test 2-7. External Test 2-8. Lockout Reset 2-9. Interlock 2-10. External Device Monitoring (EDM) 2-11. Auxiliary Output 2-12.
Page 38: Combination Of Functions
System Operation and Functions 2-1. Combination of Functions Possible combinations of the F3SG-RR functions are shown in the table below. The combinations in the table are available under certain conditions. The other functions can be combined without any limitations. Refer to 2-18. Setting Zone Adjacency Conditions for further information. YES: Combination available NO: Combination unavailable Fixed...
Page 39 System Operation and Functions  Considerations for enabling and disabling Muting function Setting parameters of the following functions can be saved according to the state where the Muting function is enabled and disabled, respectively. After changing the Muting function from Enable to Disable or from Disable to Enable, check the settings of these functions again.
Page 40: Operating States
System Operation and Functions 2-2. Operating States The operating condition of a F3SG-RR system is described in terms of states. The following operating states exist for a F3SG-RR system. 2-2-1. Machine Run State The two receiver safety outputs are in the ON state, the green ON/OFF indicator is illuminated. The protected machine is allowed to operate.
Page 41: Optical Synchronization
System Operation and Functions 2-3. Optical Synchronization 2-3-1. Overview Synchronization is required between an emitter and a receiver for normal operation of F3SG-RR. F3SG-RR uses a specific beam for Synchronization. The beam is hereinafter called synchronization beam. Depending on sensor configuration, the synchronization beam is either of the followings: •...
Page 42: Scan Code Selection
System Operation and Functions 2-4. Scan Code Selection 2-4-1. Overview The F3SG-RR has two scan codes (Code A and Code B). These scan codes have different internal processing time. The use of different scan codes allows for placement of systems in close proximity and in line with each other and minimize mutual interference.
Page 43: Pnp/Npn Selection
System Operation and Functions 2-5. PNP/NPN Selection 2-5-1. Overview The F3SG-RR offers PNP/NPN selection for the user to select the polarity of the inputs and outputs of the receiver between PNP and NPN. When the system is set to the NPN type, the “NPN” indicator is illuminated. 2-5-2.
Page 44: Self-Test
System Operation and Functions 2-6. Self-Test 2-6-1. Overview The F3SG-RR performs the Self-Test when power is turned ON (within 2 seconds) to check for errors. Also, it regularly performs the Self-Test (within a response time) while operating. This function cannot be cancelled. ...
Page 45: Waveform Of Safety Outputs
System Operation and Functions 2-6-1-2. Waveform of safety outputs When the safety outputs are in the ON state, they are cyclically turned OFF as shown below to test the output circuit. When this OFF signal is fed back, the output circuit is diagnosed as normal. If the output signal does not include an OFF pulse signal due to short-circuit, etc, the receiver diagnoses a failure in the output circuit or wiring, and it enters the Lockout state.
Page 46: External Test
System Operation and Functions 2-7. External Test 2-7-1. Overview This function stops the emission using an external signal. It can be used to verify that a safety system should properly stop (safety output turns OFF) when F3SG-RR is blocked. To stop the emission, apply the following voltage to the emitter's TEST input line according to the End Cap settings of the emitter.
Page 47: Setting
System Operation and Functions 2-7-3. Setting The user can select the setting from 24 V Active or 0 V Active by switching the End Cap. Refer to Chapter 3 Setting with Rotary Switch and End Cap for more information on setting this function by the Rotary Switch.
Page 48: Lockout Reset
System Operation and Functions 2-8. Lockout Reset 2-8-1. Overview When the cause of the Lockout is removed, you can release the Lockout state of the F3SG-RR by using either of the following methods. • Cycle the power back ON • Reset input The resetting method by the Reset input depends on the setting of PNP/NPN Selection as follows.
Page 49: Interlock
System Operation and Functions 2-9. Interlock Install the reset switch in a location that provides a clear view of the entire hazardous zone and where it cannot be activated from within the hazardous zone. Install the pre-reset switch always in the hazardous zone and where it cannot be activated from outside the hazardous zone.
Page 50 System Operation and Functions Shown below is overview of restarting the machine using the Pre-Reset. 1.Press the Pre-Reset switch (Input PRE-RESET signal) 2.Pass and interrupt F3SG-RR 3.Press the Reset switch to restart the system (Input RESET signal) Hazardous area Operator F3SG-RR Reset Switch Pre-reset Switch...
Page 51 System Operation and Functions • Manual Reset mode PNP output NPN output F39-JD††A-D F39-JD††A-D +24 VDC +24 VDC Power supply Power supply 0 VDC 0 VDC S1: Lockout/Interlock Reset Switch S1: Lockout/Interlock Reset Switch The table below shows the relation between the ON/OFF states and external lines. External Connection Input Vs-3 V to Vs...
Page 52: Factory Default Setting
System Operation and Functions  Basic wiring diagram • Pre-Reset mode PNP output NPN output □□ □□ F39-JD F39-JD +24 VDC +24 VDC Power supply Power supply 0 VDC 0 VDC S1: Lockout/Interlock Reset Switch S1: Lockout/Interlock Reset Switch S2: Pre-reset Switch S2: Pre-reset Switch The table below shows the relation between the ON/OFF states and external lines.
Page 53: Setting With Configuration Tool
System Operation and Functions 2-9-3. Setting with Configuration Tool Some settings of functions configurable with the Configuration Tool may increase risks. Make sure the Responsible Person conduct a thorough risk assessment analysis before managing and changing the settings. Unintended changes to the settings may cause a person to go undetected, resulting in serious injury.
Page 54: External Device Monitoring (Edm)
System Operation and Functions 2-10. External Device Monitoring (EDM) 2-10-1. Overview This function monitors if external relays (or contactors) operate normally to detect malfunctions, such as welding, in the external relays. When the NC contact of the external relays is open before the safety outputs switch from OFF to ON, the safety outputs remain in the OFF state.
Page 55: 2-10-2.Factory Default Setting
System Operation and Functions • In Manual Reset mode PNP output NPN output F39-JD††A-D F39-JD††A-D +24 VDC +24 VDC Power supply Power supply 0 VDC 0 VDC S1: Lockout/Interlock Reset Switch KM1, KM2: External device *Also used as EDM input line. ...
Page 56 System Operation and Functions *Setting parameters of this function can be saved according to the states where the Muting function is enabled and disabled, respectively. After changing the Muting function from Enable to Disable or from Disable to Enable, also check the settings of this function again. ...
Page 57: Auxiliary Output
System Operation and Functions 2-11. Auxiliary Output Do not use the auxiliary output for safety applications. Failure to do so may result in serious injury when the F3SG-RR fails. 2-11-1. Overview The auxiliary output is used to monitor the status of F3SG-RR. This output can be connected to a device such as an indication lamp, programmable controller, etc.
Page 58: 2-11-3.Setting With Configuration Tool
System Operation and Functions 2-11-3. Setting with Configuration Tool Some settings of functions configurable with the Configuration Tool may increase risks. Make sure the Responsible Person conduct a thorough risk assessment analysis before managing and changing the settings. Unintended changes to the settings may cause a person to go undetected, resulting in serious injury.
Page 59 System Operation and Functions  Output pattern chart ON 1 time Solid-ON Information (Output operation mode) assigned to auxiliary output Description Information Name (Auxiliary output is turned ON under the following condition) Safety output information When Safety output is in the ON state Interlock information Under Interlock state Lockout information...
Page 60: Muting
System Operation and Functions 2-12. Muting 2-12-1. Overview Muting function temporarily disables safety function of the F3SG-RR, keeping safety output ON even if beams are blocked. This makes it possible to install safety light curtains for AGV passage, enabling both safety and productivity. When the Muting is active, the top-beam-state indicator (TOP) and bottom-beam-state indicator (BTM) blink to notify people in the surrounding zone that the safety functions are disabled.
Page 61 System Operation and Functions Muting related time must be properly configured for its application by a sufficiently trained and qualified person, and the person must have responsibility for settings, especially when setting the muting time limit to infinite. You must install F3SG-RR, muting sensor, and physical barrier, and configure time settings for muting so that an operator should not enter hazardous zone.
Page 62: 2-12-2.Standard Muting Mode
System Operation and Functions <Muting range> You can specify a detection zone to be muted within the detection zone of the F3SG-RR. Muting Range Description Full Zone Muted State Full area of the detection zone is muted. (factory default This disables the full detection zone and is used typically. setting) Partial Zone Muted A specified area in the detection zone configured by the Configuration Tool is muted.
Page 63 System Operation and Functions  Timing chart T3 max. Muting input A T1min to T1max T3 max. Muting input B T2 max. 80 ms max. Enabled Muting state Disabled Unblocked Beam state Blocked OSSD T1min: Muting input time limit value (minimum) T1max: Muting input time limit value (maximum) T2: Muting time limit T3: Maximum allowable muting signal interruption...
Page 64 System Operation and Functions  Installation standard for muting sensors • Set the muting sensors so that they can detect all of the passing detection (palettes, automobiles, etc.). Do not install the muting sensor in a position so that only the front or rear end of the objects is detected.
Page 65 System Operation and Functions  Installation example 1 of standard muting mode (Using two muting sensors) This is an example of two retro-reflective type photoelectric sensors used as muting sensors installed in a cross pattern. Use two sensors when the length L of the workpieces are not constant or are insufficient. Before a workpiece passes through Hazardous zone Reflector...
Page 66 System Operation and Functions Muting state is maintained Hazardous zone Reflector F3SG-RR Workpiece Reflector The F3SG-RR is blocked but the safety function is disabled due to the muting state, and safety outputs 1 and 2 are turned ON. The muting state is released Hazardous zone Reflector F3SG-RR...
Page 67 System Operation and Functions This distance must prevent the muting state from being enabled by a person passing through the muting sensors. Also, install the F3SG-RR and muting sensors so that each workpiece passes through all muting sensors before the next workpiece arrives at the first muting sensor (PNP mode). <Wiring diagram (PNP setting)>...
Page 68 System Operation and Functions  Installation example 2 of standard muting mode (Using four muting sensors) This installation example uses four through-beam type photoelectric sensors as muting sensors. The use of four muting sensors is useful when the length of the workpieces is constant or longer, and the entrance and exit have enough space.
Page 69 System Operation and Functions The muting sensor is blocked and the safety function of the F3SG-RR is disabled Hazardous zone F3SG-RR A2 Workpiece Muting sensors A1 and B1 are turned OFF but A2 and B2 are ON, so the muting state is still maintained.
Page 70 System Operation and Functions To enable the muting state, D3 and d2 must satisfy formulas (3) and (4), respectively. This distance must prevent the muting state from being enabled by a person passing through the muting sensors. Also, install the F3SG-RR and muting sensors so that each workpiece passes through all muting sensors before the next workpiece arrives at the first muting sensor.
Page 71 System Operation and Functions <Timing chart> T3 (0.1 s) max. Muting sensor A1 T1min to T1max T3 (0.1 s) max. Muting sensor B1 T3 (0.1 s) max. Muting sensor B2 T3 (0.1 s) max. Muting sensor A2 T2 max. 80 ms max. Enabled Muting state Disabled...
Page 72: 2-12-3.Exit-Only Muting Mode
System Operation and Functions (2) Interference to a muting sensor from F3SG-RR • Take distance (D) from a sensor causing the interference • Displace beams for each other to prevent interference (change installation height or place them crosswise) • Install a physical barrier •...
Page 73 System Operation and Functions  End conditions If any of the following condition is satisfied, the muting state is released. • When a workpiece passes a muting sensor A or B and the exit-only muting delay time (4 s) passes. •...
Page 74 System Operation and Functions  Basic wiring diagram PNP output NPN output F39-JD F39-JD +24 VDC +24 VDC Power supply Power supply 0 VDC 0 VDC S1, S2: Muting sensor S1, S2: Muting sensor  Installation example of Exit-Only Muting Mode This is an installation example of exit-only muting mode.
Page 75 System Operation and Functions The muting sensor is blocked and the safety function of the F3SG-RR is disabled Hazardous zone A1 B1 F3SG-RR Workpiece When muting sensors A1 and B1 are turned ON in this order, and the muting state is enabled. In this state, the safety function of F3SG-RR is disabled.
Page 76 System Operation and Functions The workpiece passed F3SG-RR’s detection zone Hazardous zone A1 B1 F3SG-RR Workpiece A workpiece has passed F3SG-RR’s detection zone. When the muting end wait time: T4 (1 s: configurable) passes after the F3SG-RR is unblocked, the muting state is released. <Installation Distance>...
Page 77 System Operation and Functions Also, muting sensors and F3SG-RR must be installed so that muting state caused by a workpiece should be ended before the next workpiece arrives at the first muting sensor. Hazardous zone Hazardous zone A1 B1 F3SG-RR A1 B1 F3SG-RR Workpiece...
Page 78: 2-12-4.Position Detection Muting Mode
System Operation and Functions 2-12-4. Position Detection Muting Mode Muting state is enabled when muting input A turns ON from the OFF state and muting input B turns OFF from the ON state within the muting input time limit value T1max, measured by a limit switch, etc. Muting inputs must be heterogeneous redundant inputs such as the combination of NO contact and NC contact types.
Page 79 System Operation and Functions  Timing chart T3 (0.1 s) max. Muting input A (Limit switch1) T3 (0.1 s) max. T1max Muting input B (Limit switch2) T2 max. 80 ms max. Enabled Muting state Disabled T2 max. Unblocked Beam state Blocked OSSD T1max: Muting input time limit value (maximum)
Page 80 System Operation and Functions  Installation example of Position Detection Muting Mode Shown below is an installation example of position detection muting mode. This is an application that places a workpiece on a machine’s turntable surrounded by guard fence. When hazardous part of the machine is on the opposite side of a human body, safety function of F3SG-RR can be disabled so that an operator should be able to place a workpiece on the turntable.
Page 81 System Operation and Functions Guard fence F3SG-RR During muting Limit switch1 Limit switch 2 (NO Contact) (NC Contact) ON: To muting input A 24 V Input time difference between muting inputs A and B must be T1max or less (initial setting is 4 s) ON ->...
Page 82: 2-12-5.Dynamic Muting
System Operation and Functions 2-12-5. Dynamic Muting The Dynamic Muting function can configure a new muting zone while the muting state is enabled, based on a result measuring a workpiece height for a certain period of time. This materializes safer muting function with a limited muting zone adjusted according to a workpiece height.
Page 83: 2-12-6.Factory Default Setting
System Operation and Functions  Dynamic muting allowable beam The dynamic muting allowable beam allows the muting zone measured by the Zone Measurement to be expanded by the number of additional beam(s) specified as allowable beam.  Timing chart Muting Input A Muting Input B Enabled Muting State...
Page 84 System Operation and Functions Standard Muting Mode Function Factory Default Setting Available Parameters Muting zone Bottom beam All beams any beam in 1-beam increments Top beam : Muting input time limit value (minimum) 0.1 s 0.1 to 3.9 s in 0.1-s increments : Muting input time limit value (maximum) 0.2 to 60 s in 0.1-s increments, or infinite T2: Muting time limit...
Page 85: Override
System Operation and Functions 2-13. Override 2-13-1. Overview The override function turns the safety outputs ON when the muting start condition is not satisfied. If a workpiece stops while passing through the F3SG-RR, as shown below, causing a muting error, the normal state cannot be recovered unless the workpiece is removed from the muting sensors and the detection field of the F3SG-RR.
Page 86: 2-13-2.Override At Normal Operation
System Operation and Functions When muting error occurs with workpiece blocking the F3SG-RR, there are 2 methods to forcibly remove the workpiece. 1) Manual operation (with additional safety measure); or 2) Override function (Override at Normal Operation / Override upon Start up) Only one of the methods, either 1) or 2) must be used.
Page 87 System Operation and Functions  Under exit-only muting mode 1. Muting sequence error occurred 2. The F3SG-RR is blocked and the output is OFF. 3. Under the state of 1 and 2, a special sequence is entered to the reset input three (3) times. The signal must be entered within a range from 0.1 s to the override input time limit T1 (1 s)(can be changed).
Page 88 System Operation and Functions  Timing chart Under standard muting mode Muting input A Muting input B 1 s max. RESET T1 T1 T1 T1 T1 T1 T2 max. 1 s max. Enabled Override state Disabled Unblocked Beam state Blocked OSSD Note.
Page 89 System Operation and Functions  Factory default setting In the factory default setting, the Override function is set to Disable.  Basic wiring diagram • External Device Monitoring used and in Manual Reset mode PNP output NPN output F39-JD††A-D F39-JD††A-D +24 VDC +24 VDC Power supply...
Page 90: 2-13-3.Override Upon Startup
System Operation and Functions • External Device Monitoring not used and in Manual Reset mode PNP output NPN output F39-JD††A-D F39-JD††A-D +24 VDC +24 VDC Power supply Power supply 0 VDC 0 VDC S1: Lockout/Interlock Reset Switch, Override Switch or Override Cancel Switch S3, S4: Muting sensor *1.
Page 91: 2-13-4.Setting With Configuration Tool
System Operation and Functions  Timing chart 2 to 5 s Power 1 s max. RESET T1 T1 T1 T1 T1 T1 1 s max. T2 max. Enabled OVERRIDE state Disabled Unblocked Beam state Blocked OSSD Note. In this timing chart, the F3SG-RR being unblocked ends the OVERRIDE state. 2-13-4.
Page 92: Fixed Blanking
System Operation and Functions 2-14. Fixed Blanking Install protective structure for all zones of disabled zone so that a worker should not be able to approach hazardous zone of a machine without passing through zones disabled by the fixed blanking function. Otherwise it may result in serious injury.
Page 93 System Operation and Functions  Fixed blanking monitoring function For safety reasons, F3SG-RR transitions to the Lockout state* if part of a fixed blanking zone is unblocked. (Factory default setting.) When the F3SG-RR is set to Blanking Zone Cancelled, the fixed blanking function is cancelled if part of a fixed blanking zone is unblocked.
Page 94 System Operation and Functions Detection capability on the border between the blanking zone and normal detection zone when allowable beam is specified. [mm] Allowable Beam on One End F3SG-4RR-14 F3SG-4RR-25 Disable 14 (same as nominal) 25 (same as nominal) 1 beam 2 beams n beams 14+(10×n)
Page 95: 2-14-2.Factory Default Setting
System Operation and Functions Settings for respective zone have limitations. Refer to 2-18. Setting Zone Adjacency Conditions for more information. 2-14-2. Factory Default Setting The factory default setting is Fixed Blanking Disable. 2-14-3. Setting with Configuration Tool Some settings of functions configurable with the Configuration Tool may increase risks. Make sure the Responsible Person conduct a thorough risk assessment analysis before managing and changing the settings.
Page 96: Floating Blanking
System Operation and Functions 2-15. Floating Blanking Detection capability gets larger when the floating blanking function is used. When this function is used, the safety distance calculation must be based on the increased detection capability for this function. Otherwise the machine may not stop before a person reaches to the hazardous part, resulting in serious injury.
Page 97 System Operation and Functions  Temporalily disable monitoring by external wiring If Temporalily Disable Monitoring by Wiring is configured, the floating blanking monitoring function can be temporarily disabled during operation by hard wiring of muting input A and muting input B of a receiver.
Page 98 System Operation and Functions Case: PNP Setting 24 V Limit Switch 1 (NO contact) MUTE A MUTE B Limit Switch 2 (NC contact) Case: NPN Setting Limit Switch 1 (NO contact) MUTE A MUTE B Limit Switch 2 (NC contact) The muting is not enabled when the Temporalily Disable Monitoring by External Wiring is enabled.
Page 99: 2-15-2.Factory Default Setting
System Operation and Functions 2 or fewer are blocked More than one zone is blocked 30-mm dia. 14-mm dia. max. 30-mm dia. Lockout Safety output OFF Fig. 3 Fig. 4  Detection capability Detection capability for F3SG-RR differs based on the number of floating beams as shown below. Number of blocked beams to turn safety Model Number of beams configured...
Page 100: 2-15-3.Setting With Configuration Tool
System Operation and Functions 2-15-3. Setting with Configuration Tool Some settings of functions configurable with the Configuration Tool may increase risks. Make sure the Responsible Person conduct a thorough risk assessment analysis before managing and changing the settings. Unintended changes to the settings may cause a person to go undetected, resulting in serious injury.
Page 101: Reduced Resolution
System Operation and Functions 2-16. Reduced Resolution 2-16-1. Overview The reduced resolution function prevents the safety output to turn off by an object moving in a detection zone. With this function, an object with a size of 1 to 3 beams can be ignored by changing a detection capability size.
Page 102: 2-16-2.Factory Default Setting
System Operation and Functions Detection capability gets larger when the reduced resolution function is used. When this function is used, the safety distance calculation must be based on the increased detection capability for this function. Otherwise, the machine may not stop before a person reaches the hazardous part, resulting in serious injury.
Page 103: 2-16-3.Setting With Configuration Tool
System Operation and Functions 2-16-3. Setting with Configuration Tool Some settings of functions configurable with the Configuration Tool may increase risks. Make sure the Responsible Person conduct a thorough risk assessment analysis before managing and changing the settings. Unintended changes to the settings may cause a person to go undetected, resulting in serious injury.
Page 104: Warning Zone
System Operation and Functions 2-17. Warning Zone 2-17-1. Overview Part of the detection zone can be set as a warning zone. Example: • When a person enters, indicator or buzzer should notify warning without stopping a machine. When a warning zone is configured, you must attach labels that indicate a border between normal detection zone and warning zone.
Page 105 System Operation and Functions You can specify beams you want to configure for warning zone. (Fig. 4& 5) Configuration cannot be executed for cases shown below. • All beams are configured as a warning zone (Fig. 7). • A warning zone is specified without including any of end beams (Fig. 8) When it is configured for the F3SG-RR in cascade connection to have the detection zone, it is possible for the other F3SG-RR's to have the warning zone for the all beams.
Page 106 System Operation and Functions Warning Zone Warning Zone Detection Zone Detection Zone Upper 6 beams Lower 4 beams Upper Lower Upper Lower Fig. 5 Fig. 4 All beams are warning zone Upper Lower Fig. 7 Upper Detection Zone Warning Zone Detection Zone Channel 2 (secondary sensor)
Page 107: 2-17-2.Factory Default Setting
System Operation and Functions 2-17-2. Factory Default Setting The factory default setting is Warning Zone Disable. 2-17-3. Setting with Configuration Tool Some settings of functions configurable with the Configuration Tool may increase risks. Make sure the Responsible Person conduct a thorough risk assessment analysis before managing and changing the settings.
Page 108: Setting Zone Adjacency Conditions
System Operation and Functions 2-18. Setting Zone Adjacency Conditions If any two functions of muting, fixed blanking or warning zone functions of the F3SG-RR are used at the same time, the setting zones have limitations. This section describes the limitations for following points: 1.
Page 109 System Operation and Functions Warning zone Muting zone Muting zone Fixed blanking zone Figure 1 Figure 2 Even if a muting zone and a fixed blanking zone are configured as overlapped, fixed blanking monitoring function is effective. F3SG-RR User’s Manual...
Page 110: Response Time Adjustment
System Operation and Functions 2-19. Response Time Adjustment 2-19-1. Overview The Response Time Adjustment function allows the user to select the longer response time in order to reduce the chance the safety outputs are turned OFF by an accidental block of the F3SG-RR due to an environmental factor.
Page 111: Lamp
System Operation and Functions 2-20. Lamp 2-20-1. Overview A lamp (F39-LP and F39-BTLP, sold separately) can be connected to a receiver and turned ON based on the operation of F3SG-RR. The lamp can indicate red, orange, and green colors, to which three different states can be assigned.
Page 112 System Operation and Functions The user can make changes to the settings by the Configuration Tool. Factory Default Setting Lamp output Function Muting function *1 Available Parameters Enabled Disabled Output operation mode Safety output information Safety output information *2 (Priority 1) Inverted signal output Enable Enable...
Page 113 System Operation and Functions Description Information Name (Lamp turns ON or blinks under the following condition) Light level diagnosis When the F3SG-RR is unblocked and light intensity is within a range from 100% to 170% of information ON-threshold for 10 s or longer Warning Zone Information When warning zone is blocked Blanking bream unblocked...
Page 114: Designated Beam Output
System Operation and Functions 2-21. Designated Beam Output 2-21-1. Overview This function allows information on unblocked/blocked states of a given beam to be output. Example: • To turn a Lamp ON when a specified beam of F3SG-RR is blocked • To output, from the auxiliary output, a signal of information on a specified beam being unblocked If one or more specified beams are blocked or unblocked, the information on the beam state can be provided as an auxiliary output or indication of Lamp.
Page 115 System Operation and Functions The user can make changes to the settings by the Configuration Tool. Function Factory Default Setting Available Parameters Designated beam output Disable Enable/Disable Designated beam zone Bottom beam Any beam in 1-beam increments Top beam Designated beam state Light-ON Light-ON/Dark-ON If you want to output the light unblocked/blocked states of a designated beam, configure any one of the...
Page 116: Light Level Monitoring
System Operation and Functions 2-22. Light Level Monitoring 2-22-1. Incident Light Level Information 2-22-1-1. Overview The user can use the Configuration Tool to read incident light level of the F3SG-RR and view on a PC screen. This function allows beam adjustment while checking receiving incident light level. 2-22-1-2.
Page 117: Maintenance Information
System Operation and Functions 2-23. Maintenance Information Some settings of functions configurable with the Configuration Tool may increase risks. Make sure the Responsible Person conduct a thorough risk assessment analysis before managing and changing the settings. Unintended changes to the settings may cause a person to go undetected, resulting in serious injury.
Page 118: 2-23-5.Load Switching Frequency
System Operation and Functions The user can make changes to the settings by the Configuration Tool for the F3SG-RR. Function Factory Default Setting Available Parameters Power-on time threshold 30,000 h 30,000 to 1,000,000 h in 1-h increments/Disable 2-23-5. Load Switching Frequency The user can view the number of switching operations of the load connected to F3SG-RR.
Page 119: Operating Status Monitoring
System Operation and Functions 2-24. Operating Status Monitoring 2-24-1. Overview I/O information and the state of F3SG-RR can be read out with the Configuration Tool. This function is only for F3SG-RR Configuration Tool. Refer to Safety Light Curtain Configuration Tool for Model F3SG (SD Manager 2) User’s Manual for more information on setting this function by the Configuration Tool.
Page 120: Setting Recovery
System Operation and Functions 2-25. Setting Recovery The Setting Recovery function configurable with the Configuration Tool may increase risks. Make sure the Responsible Person conduct a thorough risk assessment analysis before managing and changing the settings. Unintended changes to the settings may cause a person to go undetected, resulting in serious injury.
Page 121: Chapter3 Setting With Rotary Switch And End Cap
Chapter 3 Setting with Rotary Switch and End Cap 3-1. List of Features Configurable by Rotary Switch 3-2. Rotary Switch 3-3. List of Features Configurable by End Cap 3-4. End Cap F3SG-RR User’s Manual...
Page 122: List Of Features Configurable By Rotary Switch
Setting with Rotary Switch and End Cap 3-1. List of Features Configurable by Rotary Switch For the F3SG-RR, the following function is configurable by the Rotary Switch. Feature Page Scan Code Selection p.20 F3SG-RR User’s Manual...
Page 123: Rotary Switch
Setting with Rotary Switch and End Cap 3-2. Rotary Switch Make sure to test the operation of the F3SG-RR after setting with Rotary Switch to verify that the F3SG-RR operates as intended. Make sure to stop the machine until the test is complete. Unintended settings may cause a person to go undetected, resulting in serious injury or death.
Page 124: List Of Features Configurable By End Cap
Setting with Rotary Switch and End Cap 3-3. List of Features Configurable by End Cap For F3SG-RR series, the following functional setting is available by replacing the End Cap on the emitter with the supplied white End Cap. Function Page External Test Input Selection p.24 F3SG-RR...
Page 125: End Cap
Setting with Rotary Switch and End Cap 3-4. End Cap Make sure to test the operation of the F3SG-RR after setting with End Cap to verify that the F3SG-RR operates as intended. Make sure to stop the machine until the test is complete. Unintended settings may cause a person to go undetected, resulting in serious injury or death.
Page 126 Setting with Rotary Switch and End Cap F3SG-RR User’s Manual...
Page 127: Chapter4 Wiring/Installation
Chapter 4 Wiring/Installation 4-1. Installation Considerations 4-1-1. Detection Zone and Approach 4-1-2. Safety Distance 4-1-3. Distance from Reflective Surfaces 4-1-4. Mutual Interference Prevention 4-2. Cascade Connection 4-2-1. Overview 4-2-2. Connection Procedure 4-3. Dimensions 4-3-1. Mounted with Free-Location Brackets (F39-LGRA) 4-3-1-1. Backside Mounting 4-3-1-2.
Page 128 Wiring/Installation 4-3-4-3. Top/Bottom Bracket (F39-LGRTB-3) 4-3-5. Mounted with Top/Bottom Brackets (F39-LGRTB-□) and Accessories 4-3-5-1. Connected with Cascading Cable (F39-JGR2WTS) 4-3-5-2. Connected with Bluetooth® Communication Unit (F39- 4-3-5-3. Connected with Lamp (F39-LP) or Lamp and Bluetooth® Communication Unit (F39-BTLP) 4-4. Mounting 4-4-1.
Page 129: Installation Considerations
Wiring/Installation 4-1. Installation Considerations 4-1-1. Detection Zone and Approach Install a protective structure so that the hazardous part of a machine can only be reached by passing through the sensor's detection zone. If access to the hazardous part by reaching over the detection zone of a vertically mounted F3SG-RR cannot be excluded, the height of the detection zone and the safety distance shall be determined in consideration of such a risk.
Page 130: Safety Distance
Wiring/Installation 4-1-2. Safety Distance The safety distance is the distance that must be set between the F3SG-RR and a machine's hazardous part to stop the hazardous part before a person or object reaches it. The safety distance varies according to the standards of each country and the individual specifications of each machine. Always refer to the relevant standards.
Page 131 Wiring/Installation Calculation Example for Systems with Larger Detection Capability than 40 mm Use K = 1,600 mm/s and C = 850 mm in formula (1) for calculation. S = 1,600 mm/s x (Tm + Ts) + 850 . . . Formula (4) •S = Safety distance (mm) •Tm = Machine's response time (s) •Ts = Response time of the F3SG-RR from ON to OFF (s)
Page 132 Wiring/Installation Height of upper edge of detection zone, b Height of hazardou 1000 1100 1200 1300 1400 1600 1800 2000 2200 2400 2600 s zone, a Additional distance to hazardous zone, Cro 2600 2500 2400 2200 2000 1800 1100 1100 1600 1150 1150...
Page 133 Wiring/Installation Detection Zone Parallel to Direction of Approach Use K = 1,600 mm/s and C = (1200 - 0.4 x H) in formula (1) for calculation. Note that C must not be less than 850 mm. Safety distance (S) S = 1,600 mm/s x (Tm + Ts) + 1200 - 0.4 x H Hazard •...
Page 134: Safety Distance Formulas According To Ansi B11.19
Wiring/Installation 4-1-2-2. Safety Distance Formulas according to ANSI B11.19 If a person approaches the detection zone of the F3SG-RR orthogonally, calculate the safety distance as shown below. S = K x (Ts + Tc + Tr + Tbm) + Dpf •...
Page 135: Distance From Reflective Surfaces
Wiring/Installation 4-1-3. Distance from Reflective Surfaces Install the sensor system so that it is not affected by reflective surfaces. Failure to do so may hinder detection, resulting in serious injury. 4-1-3-1. F3SG-4RR (Type 4 ESPE) Install the sensor system at distance D or further from highly reflective surfaces such as metallic walls, floors, ceilings, or workpieces, as shown below.
Page 136: Mutual Interference Prevention
Wiring/Installation 4-1-4. Mutual Interference Prevention Do not use the sensor system with mirrors in a retro-reflective configuration. Doing so may hinder detection. It is possible to use mirrors to alter the detection zone to a 90- degree angle. When using more than 1 set of F3SG-RR in adjacent areas, the emitter of one F3SG-RR may interfere with the receiver of the other, causing the safety functions to stop working properly.
Page 137 Wiring/Installation Refer to 2-4. Scan Code Selection for more information on the scan code feature. Refer to 3-2. Rotary Switch for more information on setting the scan code by the Rotary Switch. F3SG-RR User’s Manual...
Page 138: Cascade Connection
Wiring/Installation 4-2. Cascade Connection 4-2-1. Overview Up to 3 sets of F3SG-RR can be series-connected. Cascade connection allows them to be used as a a safety light curtain, requiring only 1 set to be wired to a controller and preventing mutual interference. If any 1 set of series-connected F3SG-RR is blocked, both of the safety outputs turn OFF.
Page 139 Wiring/Installation Properly connect an emitter to another emitter, and a receiver to another receiver, as shown below. Do not series-connect an emitter and receiver. Do not face different models of emitters and They will enter lockout state. receivers toward each other. They will enter lockout state or will be unable to detect objects.
Page 140: Connection Procedure
Wiring/Installation 4-2-2. Connection Procedure Remove the caps from the primary sensor. Loosen the screw (M2.5 cross-shaped) to remove the cap. Connect the the the primary sensor and the secondary sensor with the F39-JGR2WTS Cascading Cable (sold separately). If the length of the Cascading Cable is insufficient, connect the F39-JDB- Double-Ended Cable (sold separately) between the Cascading Cable and the power cable of the secondary sensor, as required.
Page 141: Dimensions
Wiring/Installation 4-3. Dimensions 4-3-1. Mounted with Free-Location Brackets (F39-LGRA) 4-3-1-1. Backside Mounting 46.35 31.4 Free-Location Bracket (F39-LGRA) 2-M5 or M6 2-M4 Free-Location Bracket (F39-LGRA) 26.3 3.95 2-M5 or M6 2-M4 3.95 <Screw: M5 or M6> [ Unit : mm ] Dimension C 4-digit number of the type name (Protective height) Dimension D...
Page 142: Side Mounting
Wiring/Installation 4-3-1-2. Side Mounting 31.4 Free-Location Bracket (F39-LGRA) 2-M5 or M6 2-M4 Free-Location Bracket (F39-LGRA) 23.5 2-M5 or M6 16.3 2-M4 <Screw: M5 or M6> [ Unit : mm ] Dimension C 4-digit number of the type name (Protective height) Dimension D C-20 □□□□...
Page 143: Free-Location Bracket / Intermediate Bracket (F39-Lgra)
Wiring/Installation 4-3-1-3. Free-Location Bracket / Intermediate Bracket (F39-LGRA) 2-M4 56.5 [ Unit : mm ] Material : ZDC2 56.5 F3SG-RR User’s Manual...
Page 144: Mounted With Top/Bottom Brackets (F39-Lgrtb) And Intermediate Bracket (F39-Lgra)
Wiring/Installation 4-3-2. Mounted with Top/Bottom Brackets (F39-LGRTB) and Intermediate Bracket (F39-LGRA) 4-3-2-1. Backside Mounting 31.4 φ9 2-M8 4-M5 Top/Bottom Bracket (F39-LGRTB) Backside:2-M4 Intermediate Bracket (F39-LGRA) 26.3 2-M5 or M6 2-M5 or M6 3.95 2-M4 3.95 3.95 Top/Bottom Bracket (F39-LGRTB) 46.35 <Screw for Top/Bottom <Screw for Top/Bottom Bracket: M5>...
Page 145: Side Mounting
Wiring/Installation 4-3-2-2. Side Mounting 19.35 31.4 Φ9 2-M8 4-M5 Top/Bottom Bracket (F39-LGRTB) Backside:2-M4 31.4 16.3 2-M5 or M6 2-M5 or M6 4.15 2-M4 4.15 4.15 Intermediate Bracket (F39-LGRA) Top/Bottom Bracket (F39-LGRTB) <Screw for Top/Bottom <Screw for Top/Bottom Bracket: M5> Bracket: M8> 2-M4 [ Unit : mm ] 4-digit number of the type name (Protective height)
Page 146: Top/Bottom Bracket (F39-Lgrtb)
Wiring/Installation 4-3-2-3. Top/Bottom Bracket (F39-LGRTB) 15.3 10.8 Top/Bottom Bracket (1) Top/Bottom 2-M4 Bracket (2) Top/Bottom Bracket (3) Φ9 46.65 31.4 2-M4 [ Unit : mm ] Material: SUS304 F3SG-RR User’s Manual...
Page 147: Backside Mounting
Wiring/Installation 4-3-3. Mounted with Top/Bottom Brackets (F39-LGRTB-2) and Intermediate Bracket (F39-LGRA) 4-3-3-1. Backside Mounting Φ9 2-M8 4-M5 2-M6 Top/Bottom Bracket (F39-LGRTB-2) Backside:2-M4 31.4 Intermediate Bracket (F39-LGRA) 26.3 2-M5 or M6 2-M5 or M6 3.95 2-M4 3.95 3.95 46.35 Top/Bottom Bracket (F39-LGRTB-2) <Screw for Top/Bottom <Screw for Top/Bottom...
Page 148: Side Mounting
Wiring/Installation 4-3-3-2. Side Mounting 19.35 2-M8 Φ9 4-M5 2-M6 Top/Bottom Bracket F39-LGRTB-2 Backside:2-M4 31.4 16.3 2-M5 or M6 2-M5 or M6 4.15 2-M4 4.15 4.15 Intermediate Bracket (F39-LGRA) Top/Bottom Bracket (F39-LGRTB-2) <Screw for Top/Bottom <Screw for Top/Bottom Bracket: M5> Bracket: M6 or M8> 2-M4 [ Unit : mm ] 4-digit number of the type name (Protective height)
Page 149: Top/Bottom Bracket (F39-Lgrtb-2)
Wiring/Installation 4-3-3-3. Top/Bottom Bracket (F39-LGRTB-2) 15.3 10.8 Top/Bottom Bracket (1) 2-M4 Top/Bottom Bracket (2) Top/Bottom Bracket (4) 46.65 φ9 2-M4 [ Unit : mm ] Material : SUS304 F3SG-RR User’s Manual...
Page 150: Mounted With Top/Bottom Brackets (F39-Lgrtb-3) And Intermediate Bracket (F39-Lgra)
Wiring/Installation 4-3-4. Mounted with Top/Bottom Brackets (F39-LGRTB-3) and Intermediate Bracket (F39-LGRA) 4-3-4-1. Backside Mounting 26.5 23.2 2-M8 2-M5 or M6 Top/Bottom Bracket (F39-LGRTB-3) Backside:2-M4 31.4 Intermediate Bracket (F39-LGRA) 26.3 2-M5 or M6 2-M5 or M6 3.95 2-M4 3.95 3.95 46.35 Top/Bottom Bracket (F39-LGRTB-3) <Screw for Top/Bottom...
Page 151: Side Mounting
Wiring/Installation 4-3-4-2. Side Mounting 19.35 26.5 23.2 2-M8 2-M5 or M6 Top/Bottom Bracket (F39-LGRTB-3) Backside:2-M4 31.4 16.3 2-M5 or M6 2-M5 or M6 4.15 2-M4 4.15 4.15 Intermediate Bracket (F39-LGRA) Top/Bottom Bracket (F39-LGRTB-3) <Screw for Top/Bottom <Screw for Top/Bottom Bracket: M5 or M6> Bracket: M8>...
Page 152: Top/Bottom Bracket (F39-Lgrtb-3)
Wiring/Installation 4-3-4-3. Top/Bottom Bracket (F39-LGRTB-3) 15.3 10.8 Top/Bottom Bracket (1) Top/Bottom 2-M4 Bracket (2) Top/Bottom Bracket (5) 23.2 48.25 26.5 2-M4 [ Unit : mm ] Material : SUS304 F3SG-RR User’s Manual...
Page 153: Mounted With Top/Bottom Brackets (F39-Lgrtb-□) And Accessories
Wiring/Installation □ 4-3-5. Mounted with Top/Bottom Brackets (F39-LGRTB- ) and Accessories 4-3-5-1. Connected with Cascading Cable (F39-JGR2WTS) [Top/Bottom Brackets (F39-LGRTB)] [Top/Bottom Brackets (F39-LGRTB-2)] Cascading Cable Cascading Cable (F39-JGR2WTS) (F39-JGR2WTS) Top/Bottom Bracket 7 to 30 (F39-LGRTB) 7 to 30 Top/Bottom Bracket (F39-LGRTB-2) Cascading Cable Cascading Cable...
Page 154: Connected With Bluetooth ® Communication Unit (F39-Bt)
Wiring/Installation 4-3-5-2. Connected with Bluetooth Communication Unit (F39-BT) ® [Top/Bottom Brackets (F39-LGRTB)] [Top/Bottom Brackets (F39-LGRTB-2)] Receiver Receiver ® ® Bluetooth Communication Unit (F39-BT) Bluetooth Communication Unit (F39-BT) Top/Bottom Bracket Top/Bottom Bracket 1 min. (F39-LGRTB) (F39-LGRTB-2) 1 min. 17.5 to 30 17.5 to 30 Bluetooth ®...
Page 155: Connected With Lamp (F39-Lp) Or Lamp And Bluetooth® Communication Unit (F39-Btlp)
Wiring/Installation 4-3-5-3. Connected with Lamp (F39-LP) or Lamp and Bluetooth ® Communication Unit (F39-BTLP) [Top/Bottom Brackets (F39-LGRTB)] [Top/Bottom Brackets (F39-LGRTB-2)] Receiver Receiver Lamp(F39-LP)/ Lamp (F39-LP) / Lamp and Bluetooth ® Communication Unit (F39-BTLP) Lamp and Bluetooth ® Communication Unit (F39-BTLP) Top/Bottom Bracket Top/Bottom Bracket 1 min.
Page 156: Mounting
Wiring/Installation 4-4. Mounting 4-4-1. Mounting Method You can mount the F3SG-RR with Free-Location Brackets and Top/Bottom Brackets. Any of these mounting methods allows the user to use the same bracket for the backside mounting and side mounting. 4-4-2. Number of Brackets Required The numbers of brackets required according to the protective heights of the sensor are as follows: •...
Page 157: Mounting Procedure
Wiring/Installation 4-4-3. Mounting Procedure  Before mounting When it is required to configure the following functions, do so before installing the F3SG-RR in your site, according to the respective procedures. • Scan Code Selection: 2-4. Scan Code Selection • External Test Input Selection: 2-7.
Page 158 Wiring/Installation Securely tighten the Mounting Screws to fix the Free-Location Bracket to the F3SG-RR housing. The recommended torque to tighten the Mounting Screws is 3.0 N•m. Then loosen the Alignment Screws (hexagon socket head cap screws (M4×22)). (Fig. 3) 1. Securely tighten this Mounting Screw Alignment Screw...
Page 159 Wiring/Installation Securely tighten the Alignment Screws to fix the Free-Location Bracket to the F3SG-RR housing. The recommended torque to tighten the Alignment Screws is 3.0 N•m. (Fig. 6) Mounting Screw Alignment Screw Securely tighten this (hexagon socket head cap screw (M4×22)) Mounting Screw Alignment Screw Securely tighten this...
Page 160: Lgra)
Wiring/Installation □ 4-4-3-2. Mounting with Top/Bottom Bracket (F39-LGRTB- Intermediate Bracket (F39-LGRA) The mounting procedure below shows the procedure using the F39-LGRTB, but this procedure is also applicable to the F39-LGRTB-2 and F39-LGRTB-3. Loosen the Alignment Screws (hexagon socket head cap screw (M4×7)) of the Top/Bottom Bracket (3) and change the angle of the Top/Bottom Bracket (3) according to its mounting direction.
Page 161 Wiring/Installation Securely tighten screws to fix the Intermediate Bracket to the mounting position of the wall surface. (Fig. 3) <Backside mounting> <Side mounting> M5/M6 M5/M6 Fig. 3 - Screws to mount the brackets to the wall are not included. - This step is not needed for the F3SG-RR of the protective height of 1040 mm or less. Fully loosen the Mounting Screw (hexagon socket head cap screw (M4×22)) of the Intermediate Bracket.
Page 162 Wiring/Installation Securely tighten the Mounting Screw to fix the Intermediate Bracket to the F3SG-RR housing. The recommended torque to tighten the Mounting Screw is 3.0 N•m. Then loosen the Alignment Screw (hexagon socket head cap screw (M4×22)) of the Intermediate Bracket. (Fig. 6) 1.
Page 163 Wiring/Installation Power the F3SG-RR on to perform beam alignment. Move the emitter and receiver from side to side (Fig. 8) to align them to a center position where the Stable-state indicator (STB, green) of the receiver is illuminated while checking the state of the top and bottom beams with the Top-beam-state indicator (TOP, blue) and Bottom-beam-state indicator (BTM, blue) of the receiver.
Page 164 Wiring/Installation F3SG-RR User’s Manual...
Page 165: Beam Alignment Procedure
Wiring/Installation 4-4-4. Beam Alignment Procedure The Free-Location Bracket and Top/Bottom Bracket allow beam alignment after fixing the bracket to a wall surface. Verify the following points: - The optical surfaces of the emitter and receiver are clean. - There is no interrupting object in the detection zone of the F3SG-RR. Align the beams of the emitter and receiver: Move the emitter and receiver from side to side to align each of these to the center position where the Stable-state indicator (STB, green) of the receiver is illuminated while checking the state of the top and...
Page 166: Wiring
Wiring/Installation 4-5. Wiring 4-5-1. Wiring Precautions Double or reinforced insulation from hazardous voltage must be applied to all input and output lines. Failure to do so may result in electric shock. When using PNP output, connect the load between the output and 0 V line. When using NPN output, connect the load between the output and +24 VDC line.
Page 167: Power Supply Unit
Wiring/Installation 4-5-2. Power Supply Unit For the F3SG-RR to comply with IEC 61496-1 and UL 508, the DC power supply unit must satisfy all of the following conditions: ± • Must be within the rated power voltage (24 V DC 20%) •...
Page 168: Cable Connections
Wiring/Installation 4-5-3. Cable Connections Extension of the cable must be within a specified length. If it isn't, safety function may not work properly, resulting in danger. Perform wiring according to the following procedure. □□□ Connect an emitter cable (F39-JD -L, gray, sold separately) to the emitter-side power cable (gray).
Page 169: Single-Ended Cable
Wiring/Installation <Internal wiring diagram> Connected to Power Cable or Double-Ended Cable White OSSD 2 Brown +24 VDC Black OSSD 1 Yellow Gray MUTE A/PC COM (+) MUTE B/PC COM (-) Pink Female Blue 0 VDC RESET/EDM Emitter cable (Gray) Receiver cable (Black) L (m) F39-JD3RA-L F39-JD3RA-D...
Page 170: Double-Ended Cable
Wiring/Installation □  Single-Ended Cable for Receiver (F39-JD A-D, sold separately) [Unit: mm] 39.5 Insulated vinyl round cable dia. 6.6, shielded 8-wire (4-pair) (Cross section of conductor: 0.3mm (AWG22) / insulator diameter: dia. 1.15mm) M12 IP67 connector <Internal wiring diagram> Connected to Power Cable or Double-Ended Cable White OSSD 2...
Page 171 Wiring/Installation <Internal wiring diagram> Connected to Power Cable Connected to Single-Ended Cable, or or Double-Ended Cable Double-Ended Cable Brown Brown Blue Blue Gray Gray Pink Pink White White Female Male Black Black Yellow Yellow Shield Shield Twisted pair wires are brown and blue, gray and pink, white and red, and black and yellow. □...
Page 172: Cascading Cable
Wiring/Installation □□ □ If the length of the F39-JD A Single-Ended Cable is insufficient, use 1 or more F39-JD B Double- Ended Cables to extend the length, as required. The total cable extension length of the power cable must be 100 m max. <Connection example>...
Page 173: Reduced Wiring Connector System
Wiring/Installation If the length of the Cascading Cable is insufficient, connect the F39-JDB Double-Ended Cable between the power cable of the F3SG-RR and the F39-JGR2WTS Cascading Cable, as required. (Cable length between sensors: 10 m max. (not including cascading cable (F39-JGR2WTS) and power cable)) Remove the cap Cable is gray...
Page 174: Extending Cable Length With Commercially Available Cable
Wiring/Installation  Reduced Wiring Connector (F39-CN5, sold separately) [Unit: mm] (52) 13.6 24.7 13.6 Φ 8 (SPOT FACING 2) Φ 4.5 32.1 17.7 <Internal wiring diagram> Connected to Power Cable or Connected to Power Cable or Double-Ended Cable of F3SG-RR Emitter Double-Ended Cable of F3SG-RR Receiver White White...
Page 175: Functional Earth Connection
Wiring/Installation 4-5-4. Functional Earth Connection The F3SG-RR operates properly without functional earth connection in a general industrial environment. If the F3SG-RR fails due to electrical noise, connecting the F3SG-RR to the functional earth may work to prevent the noise. It is recommended the functional earth terminal of the F3SG-RR be connected to functional earth cables.
Page 176 Wiring/Installation F3SG-RR User’s Manual...
Page 177: Chapter5 Input/Output Circuit And Applications
Chapter 5 Input/Output Circuit and Applications 5-1. Input/Output Circuit 5-1-1. Entire Circuit Diagram 5-1-2. Input Circuit Diagram by Function 5-2. Wiring Examples 5-2-1. Standalone F3SG-RR using PNP Outputs 5-2-1-1. Auto Reset Mode, EDM enabled and PNP Outputs 5-2-1-2. Manual Reset Mode, EDM disabled and PNP Outputs161 5-2-1-3.
Page 178 Input/Output Circuit and Applications 5-2-4-1. Standard Muting Mode/Exit-Only Muting Mode using NPN Outputs 5-2-4-2. Standard Muting Mode/Exit-Only Muting Mode with two Muting Sensors using NPN Outputs 5-2-4-3. Standard Muting Mode with four Muting Sensors using NPN Outputs 5-3. Connectable Safety Control Units F3SG-RR User’s Manual...
Page 179: Input/Output Circuit
Input/Output Circuit and Applications 5-1. Input/Output Circuit 5-1-1. Entire Circuit Diagram The entire circuit diagram of the F3SG-RR is shown below. The numbers in the circles indicate the connector's pin numbers.  PNP Output White Not used Indicator +24 VDC Brown Test Input Black...
Page 180 Input/Output Circuit and Applications  NPN Output White Not used Indicator +24 VDC Brown Test Input Black TEST Circuit Emitter Yellow Not used Main Circuit Gray Not used Pink Not used Blue Red Not used Brown RESET/EDM circuit MUTE B Pink /PC COM (-)* MUTE A...
Page 181: Input Circuit Diagram By Function
Input/Output Circuit and Applications 5-1-2. Input Circuit Diagram by Function The input circuit diagrams of by function are shown below.  TEST <0 V Active> <24 V Active> +24 VDC +24 VDC Short circuit current: Emitter Emitter Approx. 2.5 mA Main Main Circuit...
Page 182: Wiring Examples
Input/Output Circuit and Applications 5-2. Wiring Examples Examples of a motor control system using the F3SG-RR are shown below. This chapter shows examples equivalent to up to PLe, Category 4 (ISO13849-1). 5-2-1. Standalone F3SG-RR using PNP Outputs 5-2-1-1. Auto Reset Mode, EDM enabled and PNP Outputs The following is the example of Muting not used, External Device Monitoring enabled, Auto Reset Mode, PNP outputs and External Test in 24 V Active (not used).
Page 183: Manual Reset Mode, Edm Disabled And Pnp Outputs161
Input/Output Circuit and Applications 5-2-1-2. Manual Reset Mode, EDM disabled and PNP Outputs The following is the example of Muting not used, External Device Monitoring disabled, Manual Reset Mode, PNP outputs and External Test in 24 V Active (used). [Settings] Function EDM Disabled *1 Receiver...
Page 184: Replacing The F3Sj-B Safety Light Curtain With F3Sg-Rr
Input/Output Circuit and Applications 5-2-1-3. Replacing the F3SJ-B Safety Light Curtain with F3SG-RR The following is the example of External Device Monitoring enabled, Manual Reset Mode, PNP outputs and External Test in 24 V Active (used). When replacing the F3SJ-B with F3SG-RR, change the wiring as shown below if using the Interlock/ Lockout Reset function with the RESET line (yellow) of the F3SJ-B emitter.
Page 185: F3Sg-Rr With Reduced Wiring Connector And Pnp Outputs
Input/Output Circuit and Applications 5-2-1-4. F3SG-RR with Reduced Wiring Connector and PNP Outputs The following is the example of Muting not used, Auto Reset Mode, PNP outputs and External Test in 24 V Active (not used). [Settings] Function Auto Reset (factory default setting) *1 Receiver PNP (factory default setting) *1 Emitter...
Page 186: Pre-Reset Mode Using Pnp Output
Input/Output Circuit and Applications 5-2-1-5. Pre-Reset Mode using PNP Output The following is the example of External Device Monitoring disabled, Pre-Reset Mode, PNP outputs and External Test in 24 V Active (used). [Settings] Function EDM Disabled *4 Receiver Pre-Reset *4 PNP Output (factory default setting) *4 Emitter External Test: 24 V Active (End Cap: Black) (factory default setting)
Page 187: Muting Using Pnp Outputs
Input/Output Circuit and Applications 5-2-2. Muting using PNP Outputs 5-2-2-1. Standard Muting Mode/Exit-Only Muting Mode using PNP Outputs The following is the example of External Device Monitoring enabled, Auto Reset Mode, PNP outputs and External Test in 24 V Active (used). [Settings] Function EDM Enabled (factory default setting) *3...
Page 188: Outputs
Input/Output Circuit and Applications 5-2-2-2. Standard Muting Mode/Exit-Only Muting Mode with Reduced Wiring Connector and PNP outputs The following is the example of Auto Reset Mode, PNP outputs and External Test in 24 V Active (not used). [Settings] Function Auto Reset (factory default setting) *3 Receiver PNP Output (factory default setting) *3 Emitter...
Page 189: Puts
Input/Output Circuit and Applications 5-2-2-3. Standard Muting Mode/Exit-Only Muting Mode with two Muting Sensors using PNP Outputs The following is the example of External Device Monitoring disabled, Auto Reset Mode, PNP outputs and External Test in 24 V Active (used). [Settings] Function EDM Disabled *5...
Page 190: Standard Muting Mode With Four Muting Sensors Using Pnp Outputs
Input/Output Circuit and Applications 5-2-2-4. Standard Muting Mode with four Muting Sensors using PNP Outputs The following is the example of External Device Monitoring disabled, Auto Reset Mode, PNP outputs and External Test in 24 V Active (used). [Settings] Function EDM Disabled *5 Receiver Auto Reset (factory default setting) *5...
Page 191: Standalone F3Sg-Rr Using Npn Outputs
Input/Output Circuit and Applications 5-2-3. Standalone F3SG-RR using NPN Outputs 5-2-3-1. Auto Reset Mode, EDM enabled and NPN Outputs The following is the example of Muting not used, External Device Monitoring enabled, Auto Reset Mode, NPN outputs and External Test in 0 V Active (not used). [Settings] Function EDM Enabled (factory default setting) *1...
Page 192: Manual Reset Mode, Edm Disabled And Npn Outputs
Input/Output Circuit and Applications 5-2-3-2. Manual Reset Mode, EDM disabled and NPN Outputs The following is the example of Muting not used, External Device Monitoring disabled, Manual Reset Mode, NPN outputs and External Test in 0 V Active (used). [Settings] Function EDM Disabled *1 Receiver...
Page 193: Replacing The F3Sj-B Safety Light Curtain With F3Sg-Rr
Input/Output Circuit and Applications 5-2-3-3. Replacing the F3SJ-B Safety Light Curtain with F3SG-RR The following is the example of External Device Monitoring enabled, Manual Reset Mode, NPN outputs and External Test in 0 V Active (used). When replacing the F3SJ-B with F3SG-RR, change the wiring as shown below if using the Interlock/ Lockout Reset function with the RESET line (yellow) of the F3SJ-B emitter.
Page 194: F3Sg-Rr With Reduced Wiring Connector And Npn Outputs
Input/Output Circuit and Applications 5-2-3-4. F3SG-RR with Reduced Wiring Connector and NPN Outputs The following is the example of Muting not used, Auto Reset Mode, NPN outputs and External Test in 0 V Active (not used). [Settings] Function Auto Reset (factory default setting) *1 Receiver NPN *1 Emitter...
Page 195: Pre-Reset Mode Using Npn Output
Input/Output Circuit and Applications 5-2-3-5. Pre-Reset Mode using NPN Output The following is the example of External Device Monitoring enabled, Pre-Reset mode, NPN output and External Test in 0 V Active (used). [Settings] Function EDM Enabled (factory default setting) *2 Receiver Pre-Reset *2 NPN *2...
Page 196: Muting Using Npn Outputs
Input/Output Circuit and Applications 5-2-4. Muting using NPN Outputs 5-2-4-1. Standard Muting Mode/Exit-Only Muting Mode using NPN Outputs The following is the example of External Device Monitoring enabled, Auto Reset Mode, NPN outputs and External Test in 0 V Active (used). [Settings] Function EDM Enabled (factory default setting) *3...
Page 197: Puts
Input/Output Circuit and Applications 5-2-4-2. Standard Muting Mode/Exit-Only Muting Mode with two Muting Sensors using NPN Outputs The following is the example of External Device Monitoring enabled, Auto Reset Mode, NPN outputs and External Test in 0 V Active (used). [Settings] Function EDM Enabled (factory default setting) *3...
Page 198: Standard Muting Mode With Four Muting Sensors Using Npn Outputs
Input/Output Circuit and Applications 5-2-4-3. Standard Muting Mode with four Muting Sensors using NPN Outputs The following is the example of External Device Monitoring enabled, Auto Reset Mode, NPN outputs and External Test in 0 V Active (used). [Settings] Function EDM Enabled (factory default setting) *3 Receiver Auto Reset (factory default setting) *3...
Page 199: Connectable Safety Control Units
Input/Output Circuit and Applications 5-3. Connectable Safety Control Units The F3SG-RR with PNP output can be connected to the safety control units listed in the table below. Connectable Safety Control Units (PNP output) G9SA-301 G9SX-AD322-T G9SP-N10S □ G9SA-321-T G9SX-ADA222-T G9SP-N10D G9SA-501 G9SX-BC202 G9SP-N20S...
Page 200 Input/Output Circuit and Applications F3SG-RR User’s Manual...
Page 201: Chapter6 Checklists
Chapter 6 Checklists 6-1. Pre-Operation Checklists 6-2. Maintenance Checklists F3SG-RR User’s Manual...
Page 202: Pre-Operation Checklists
Checklists 6-1. Pre-Operation Checklists Make sure Responsible Person tests the operation of the F3SG-RR after installation to verify that the F3SG-RR operates as intended. Make sure to stop the machine until the test is complete. Unintended function settings may cause a person to go undetected, resulting in serious injury. After installation, the highest level administrator must use the following checklist to verify the operation, placing a check mark in each of the boxes.
Page 203: Operation Check While The Machine Is Stopped
Checklists When 2 or more F3SG-RR systems are used, they are in cascade connection or prevented from mutual interference with each other. On a secondary sensor farthest from its power supply, either of the following is attached: - End Cap - Lamp (F39-LP and F39-BTLP, sold separately) - Bluetooth Communication Unit (F39-BT, sold separately)
Page 204: Checking That Hazardous Parts Stop While The Machine Operates
Checklists Under muting state, a signal that indicates muting state must be output from the Auxiliary Output. When override function is used, minimum override time limit required must be set. Under override state, a signal that indicates override state must be output from the Auxiliary Output. 6-1-1-4.
Page 205: Maintenance Checklists
Checklists 6-2. Maintenance Checklists Perform daily and 6-month inspection for the F3SG-RR. Otherwise, the system may fail to work properly, resulting in serious injury. Do not try to disassemble, repair, or modify this product. Doing so may cause the safety functions to stop working properly.
Page 206: Checking That Hazardous Parts Stop While The Machine Operates
Checklists The test rod is detected when it is moved around in the detection zone as shown in the diagram below. In other words, when a test rod is inserted into the detection zone, the Stable-state indicator turns OFF and the ON/OFF indicator turns red. When fixed blanking function is used, you must ensure that all blanked zones in the detection zone are covered by a hard barrier guard and there must be no zone in the detection zone where the test rod goes undetected.
Page 207 Checklists - End Cap - Lamp (F39-LP and F39-BTLP, sold separately) - Bluetooth Communication Unit (F39-BT, sold separately) ® When using PNP output, +24 VDC line of the power supply must not be grounded. When using NPN output, 0 VDC line of the power supply must not be grounded. Wiring must not be bent, cracked, nor damaged.
Page 208 Checklists F3SG-RR User’s Manual...
Page 209: Chapter7 Appendix
Chapter 7 Appendix 7-1. Troubleshooting 7-1-1. Lockout State 7-1-2. Warning 7-2. Optional Accessories(Sold Separately) 7-3. Glossary 7-4. Revision History F3SG-RR User’s Manual...
Page 210: Troubleshooting
Appendix 7-1. Troubleshooting <Emitter> <Receiver> 1. Top-beam-state indicator (Blue) 2. PNP/NPN mode indicator (Green) 3. Response time indicator (Green) 4. Sequence error indicator (Yellow) 5. Blanking indicator (Green) 6. Configuration indicator (Green) 7. Interlock indicator (Yellow) 1. Test indicator (Green) 8.
Page 211: Lockout State
Appendix LED Blinking Pattern: The timing chart below shows the blinking frequency of the LED blinking patterns (blinking once through seven times) described in the following pages. Blinking: Once Blinking: Twice Blinking: Three times Blinking: Four times Blinking: Five times Blinking: Six times Blinking: Seven times 0.2 s...
Page 212: Troubleshooting
Appendix 7-1-1-2. Troubleshooting Identify an error according to the combination of the indicators when the error occurs. See the following troubleshooting tables to take measures. Blink <Indicator status at lockout: Receiver> Combination of Indicators and Error Description [Error Description] Cap error Other sensor error Blanking monitoring error BLANK...
Page 213 Appendix Description Error code Cause and measures Cap error A cap may be detached. Attach the cap properly. Other sensor error Other sensor being cascaded caused an error. Check the indicator of the sensor. Blanking monitoring error An error is detected by the fixed blanking monitoring function or the floating blanking monitoring function.
Page 214 Appendix Description Error code Cause and measures Safety output error due to power The power supply voltage may have dropped temporarily when the F3SG-RR supply voltage or noise is in operation. Check for temporary power supply voltage drop (by about 12 VDC) by the influence of the inductive load, etc.
Page 215: Warning
Appendix 7-1-2. Warning 7-1-2-1. Description If an error is detected that prevents the F3SG-RR to continue normal operation, the STB or SEQ indicator blinks to notify warning information according to the error. The F3SG-RR continues normal operation. In the Auto Reset mode, the F3SG-RR automatically recovers from the warning status when the cause of the error is solved.
Page 216: Muting Sequence Error Indication
Appendix 7-1-2-3. Muting Sequence Error Indication Sequence error indicator Cause and measures Power supply may have been turned ON with muting input A or B being ON. Check the condition of the muting sensors and light curtains. Muting input B may have been turned ON before muting input A was turned ON. Check the condition of the muting sensors.
Page 217: Interlock Sequence Error Indication
Appendix 7-1-2-4. Interlock Sequence Error Indication The following table is applied only when the pre-reset function is being enabled. Sequence error indicator Cause and measures The reset or pre-reset switch may have been pressed before the light curtain receives light. Check the reset input and pre-reset input wiring.
Page 218: Optional Accessories(Sold Separately)
Appendix 7-2. Optional Accessories(Sold Separately) Single-Ended Cable (Oil-Resistant Cable) Appearance Model Cable length Specifications □ F39-JD3RA-L Emitter cable (F39-JD RA-L): M12 connector (8-pin), 5 wires Emitter □ Receiver cable (F39-JD RA-D): M12 connector (8-pin), 8 wires F39-JD7RA-L IP67 and IP67G (JIS C 0920 Annex 1)* rated when mated.
Page 219 Appendix Cable for Reduced Wiring* (2 cables per set, one for emitter and one for receiver) Appearance Model Cable length Remarks F39-JD0303BA Emitter : 3 m Double-Ended Cable : F39-JD3B-L Receiver : 3 m Single-Ended Cable : F39-JD3A-D F39-JD0307BA Emitter : 3 m Double-Ended Cable : F39-JD3B-L Receiver : 7 m Single-Ended Cable : F39-JD7A-D...
Page 220 Appendix Lamp and Bluetooth Communication Unit ® Appearance Model Remarks F39-BTLP Used for the receiver. IP67* rated. Material: PC (Lighting element) PBT (Other body parts) *When the accessory is used, protect it from cutting oil. Lamp Appearance Model Remarks F39-LP Used for the receiver.
Page 221 Appendix Top/Bottom Bracket Appearance Model Application Remarks F39-LGRTB Use this bracket at the top and 4 brackets per set. bottom positions of the F3SG- RR. Beam alignment after When it is necessary to use it mounting possible. The angle with another bracket, only the adjustment range is ±22.5°.
Page 222 Appendix Control Unit Appearance Model Output Remarks G9SA-301-P Safety output (relay): NO • An F39-JDA Single Ended- contact x 3 Cable is required. Auxiliary output (relay): NC • An F3SG-RR with NPN Output contact x 1 can be connected. Control Unit Appearance Model Output...
Page 223 Appendix Control Unit Appearance Model Output Remarks G9SP-N10S Safety output (solid-state): • An F39-JDA Single-Ended source output (PNP) x 4 Cable is required. Test output (solid-state): source • An F3SG-RR with PNP output output (PNP) x 4 can be connected. Standard output (solid-state): source output (PNP) x4 G9SP-N10D...
Page 224: Glossary
Appendix 7-3. Glossary Term Description Accumulated load switching frequency Total number of operations of a load to be connected to the F3SG-RR, from when the F3SG-RR is first energized until the present time. Allowable Beams Dynamic Muting: Area(s) (or beam(s)) to be added in a Dynamic Muting zone, in order to prevent an accidental interruption of the F3SG-RR due to vibration.
Page 225 Appendix Term Description Interlock reset Cancels the Interlock state. Inverted signal output mode In this mode, the logic of the Auxiliary output signal is reversed. Light level diagnosis information Information to be signaled to the Auxiliary output or Lamp when the Safety output is in the ON state and when the incident light level is from 100% to 170% of the ON-threshold value for 10 seconds or more.
Page 226 Appendix Term Description Position detection muting mode Mode that enables the Muting function according to the position of a hazardous source such as a robot arm, using heterogeneous redundant inputs. Power-on time Function to display the period of time when the F3SG-RR is energized, starting from when the power-on time was last reset until the present time.
Page 227 Appendix Term Description Power supply voltage value in your usage environment. Warning zone function Function to configure part of the detection zone, in which the Safety outputs are not affected by the beam state. The blocked state of the Warning zone can be signaled to the Auxiliary output.
Page 228: Revision History
Appendix 7-4. Revision History A manual revision code appears as a suffix to the manual number at the bottom of the front and back covers of this manual. Z383-E1- 04 Revision No. Revision Revision date Revisions symbol June 2017 First edition January 2018 Minor corrections.
Page 229 OMRON Corporation Industrial Automation Company (Manufacturer) Authorized Distributor: Shiokoji Horikawa, Shimogyo-ku, Kyoto, 600-8530 JAPAN Contact: www.ia.omron.com Regional Headquarters OMRON EUROPE B.V. (Importer in EU) OMRON ELECTRONICS LLC Wegalaan 67-69, 2132 JD Hoofddorp 2895 Greenspoint Parkway, Suite 200 The Netherlands Hoffman Estates, IL 60169 U.S.A. Tel: (31)2356-81-300/Fax: (31)2356-81-388 Tel: (1) 847-843-7900/Fax: (1) 847-843-7787 ©...

STI OMRON F3SG RR Series User Manual

Chapter1 Overview And Specifications

Chapter2 System Operation and Functions

Chapter3 Setting With Rotary Switch and End Cap

Chapter4 Wiring/Installation

Chapter5 Input/Output Circuit and Applications

Chapter6 Checklists

Chapter7 Appendix

Quick Links

Troubleshooting

Need help?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for STI OMRON F3SG RR Series

Summary of Contents for STI OMRON F3SG RR Series
