Summary of Contents for Segway FUGLEMAN SGW1000F-U2

  • Page 3 WELCOME...
  • Page 4 IMPORTANT NOTICE powersports.segway.com http://...

  • Page 5: Table Of Contents

    TABLE OF CONTENTS SAFETY INTRODUCTION VEHICLE DEVICE OPERATION MAINTENANCE, STORAGE AND TRANSPORTATION SPECIFICATIONS TROUBLESHOOTING EMISSION CONTROL SYSTEM WARRANTY...
  • Page 6 INTRODUCTION BEFORE YOU RIDE WARNING ADULT VEHICLE ONLY MUST...
  • Page 8 The meaning of these signs： WARNING CAUTION NOTICE IMPORTANT...

  • Page 9: Safety Introduction

    SAFETY INTRODUCTION WARNING LABELS ............. 3 SEVERE INJURY OR DEATH ........8 IMPORTANT SAFETY INFORMATION ....... 11...
  • Page 10 SAFETY INTRODUCTION...
  • Page 11 SAFETY INTRODUCTION WARNING LABELS...
  • Page 12 SAFETY INTRODUCTION...
  • Page 13 SAFETY INTRODUCTION...
  • Page 14 SAFETY INTRODUCTION...
  • Page 15 SAFETY INTRODUCTION...
  • Page 16 SAFETY INTRODUCTION SEVERE INJURY OR DEATH Can result if you do not follow these instructions:...
  • Page 17 SAFETY INTRODUCTION...
  • Page 18 SAFETY INTRODUCTION...
  • Page 19 SAFETY INTRODUCTION IMPORTANT SAFETY INFORMATION Reading the manual WARNING...
  • Page 20 SAFETY INTRODUCTION Safe driving age WARNING...
  • Page 21 SAFETY INTRODUCTION Riding equipment WARNING Helmet Additional Riding Gear...
  • Page 22 SAFETY INTRODUCTION WARNING...
  • Page 23 SAFETY INTRODUCTION Using alcohol or drugs WARNING...
  • Page 24 SAFETY INTRODUCTION Vehicle modification WARNING...
  • Page 25 SAFETY INTRODUCTION Passengers WARNING...
  • Page 26 SAFETY INTRODUCTION Contact with exhaust WARNING...
  • Page 27 SAFETY INTRODUCTION Seat Belts...
  • Page 28 SAFETY INTRODUCTION Loading on the vehicle Always follow the following guidelines:...
  • Page 29 SAFETY INTRODUCTION No Passengers in the cargo box Operating on Pavement Operating on Public Roads...
  • Page 30 SAFETY INTRODUCTION Operating at Excessive Speed Turning Improperly Jumps and Stunts ， ， Improper Hill Climbing...
  • Page 31 SAFETY INTRODUCTION Descending Hills Improperly Crossing Hillsides Fuel safety Gasoline is very flammable under certain conditions...

  • Page 32: Vehicle Device

    VEHICLE DEVICE VEHICLE ACTIVATION ..........26 PARTS AND CONTROL ..........29 FRONT PANEL ............. 31 （ ）...
  • Page 33 VEHICLE DEVICE INSTRUMENT PANEL ..........54...
  • Page 34 VEHICLE DEVICE VEHICLE ACTIVATION NOTICE The new vehicle must be activated on the APP for the first time if equipped with vehicle DTS, otherwise the engine will not start. Segway powersports” ， Segway powersports” CONFIRM START...
  • Page 35 VEHICLE DEVICE Vehicle Unlocked Mechanical key (preferred) 2. APP remote unlock vehicle 3. APP Bluetooth unlock vehicle NOTICE...
  • Page 36 VEHICLE DEVICE APP Function...
  • Page 37 VEHICLE DEVICE PARTS AND CONTROL Front Bumper Handrails ROPS Cargo Box Muffler Tailgate Rear Bumper Cargo Box Flip Handle Fuel Cap...
  • Page 38 VEHICLE DEVICE Light Switch AWD Switch Instrument Cluster Gear Shifter/Selector Storage Box Storage Box DC Socket Switch Ignition Parking Brake Start Button 12 Volt Socket...
  • Page 39 VEHICLE DEVICE FRONT PANEL Ignition Lock/Start Button MODE 1 MODE 2 MODE 1: Ignition Lock Start Switch ， MODE 2:...
  • Page 40 VEHICLE DEVICE Switchs Emergency shutdown Switch Emergency Switch Mode Switch Override Switch Four-Wheel Drive Switch（if equipped） Emergency shutdown Switch ： ： Vehicle launch (mode 1) ，...
  • Page 41 VEHICLE DEVICE Vehicle launch (mode 2) The vehicle stop Emergency Switch ● ： ● ： Use this switch when the vehicle is in an emergency Mode Switch “ S ”：Sport mode “ E ”：Economic mode...
  • Page 42 VEHICLE DEVICE Override Switch ： Four-Wheel Drive Switch（if equipped） “ ”: “ ”: Toggle switch for Two-wheel drive or Four-wheel drive Handle switch Red button pops up：2WD mode Red button pressed and Yellow button pressed：4WD mode Yellow button pops up：4WD locking mode...
  • Page 43 VEHICLE DEVICE 2WD mode 4WD mode 4WD locking mode CAUTION when switching to 4WD locking mode,more force is required to manipulate the direction during steering.
  • Page 44 VEHICLE DEVICE Combination Switch...
  • Page 45 VEHICLE DEVICE Headlight Switch ： ： ： ： ：...
  • Page 46 VEHICLE DEVICE Electronic Power Steering（EPS） NOTICE When the key is turned to the on position, the EPS warning indicator lights up briefly. Please refer to P59.
  • Page 47 VEHICLE DEVICE 12V Socket Output power: 120W Top: USB interface　　　　Bottom: DC interface Open the lid...
  • Page 48 VEHICLE DEVICE SEAT Driver seat adjustment Seat adjusting handle...
  • Page 49 VEHICLE DEVICE Driver seat removal/installation Driver seat removal seat lock pin Driver seat installation...
  • Page 50 VEHICLE DEVICE Passenger Seat removal Passenger seat Passenger seat cover...
  • Page 51 Steering Wheel Adjustment Steering wheel angle adjustment : WARNING Do not adjust the steering wheel while driving. Otherwise, it may cause the driver to control errors and cause an accident, which may result in serious injury or death.
  • Page 52 Seat Belt ◆ ◆ ◆ ◆...
  • Page 53 Damage, wear, or stiffness. If any damage is found, please contact a Segway Powersports dealer for replacement. Clean the dirt or debris on the seat belt, wipe the belt with mild soap and water. Never use bleach, dyes or household detergents.
  • Page 54 VEHICLE DEVICE Lifting and supporting the vehicle ：...
  • Page 55 VEHICLE DEVICE Storage Box Front storage box Middle storage box Passenger backrest storage box Middle lower storage box WARNING Keep the storage box closed if you do not use it. Or, you will be possible to be hurt by the goods kept in the storage box or while you open it in emergency brake or turning, resulting in accident.
  • Page 56 VEHICLE DEVICE Fuel Tank Cap WARNING Always gas up fuel type as per requirement. Do not smoke while refueling or it may ignite the fuel and cause fire hazard. Do not touch other people or stuff with static electricity or it may cause static electricity accumulation and ignite fuel.
  • Page 57 VEHICLE DEVICE Gear Shift Selector Low speed High speed Neutral Reverse Parking CAUTION The transmission will be damaged when you change shift gear if the engine is running over the idle speed or in the driving process. Put shift gear in P position and lock parking brake when the driver is out of the vehicle.
  • Page 58 VEHICLE DEVICE Brake Pedal and Accelerator Pedal Brake pedal Accelerator pedal Brake pedal...
  • Page 59 VEHICLE DEVICE Accelerator pedal CAUTION If the accelerator pedal and the brake pedal are applied at the same time, the engine power may be affected limit...
  • Page 60 VEHICLE DEVICE Parking brake Parking handle Parking button Turn on the parking brake: Release the parking brake: CAUTION When the driver leaves the vehicle, the parking brake of the vehicle must be turned on...
  • Page 61 VEHICLE DEVICE Roll-Overprotective Structures(ROPS) WARNING Vehicle rollover could cause severe injury or death. Always avoid operating in a manner that could result in vehicle rollover.
  • Page 62 VEHICLE DEVICE INSTRUMENT PANEL NOTICE The combination meter may be damaged by using a high-pressure cleaner. Do not clean the instrument with alcohol or corrosive detergent. Corrosive liquid will corrode the surface of the instrument and cause damage to the instrument.
  • Page 63 VEHICLE DEVICE Instrument Indicator Light/Warning Light ， Engine Tachometer shows → → → → → Speedometer Gage ： ：...
  • Page 64 VEHICLE DEVICE Engine Water Temperature C： H： Time Display Subtotal Mileage Engine Running Time Dynamic Residual Mileage Fault Code Display Battery Voltage Total Mileage Four-Wheel Drive Full DifferentialLock...
  • Page 65 VEHICLE DEVICE Indicator light/warning indication...
  • Page 66 VEHICLE DEVICE...
  • Page 67 VEHICLE DEVICE Diagnostic displays code definitions Fault Code Display Area Failure System Failure Description Code...
  • Page 68 VEHICLE DEVICE...
  • Page 69 VEHICLE DEVICE...
  • Page 70 VEHICLE DEVICE...
  • Page 71 VEHICLE DEVICE...
  • Page 72 VEHICLE DEVICE T-BOX...

  • Page 73: Operation

    OPERATION BASIC DRVING GUIDE ..........67 PRE-RIDE INSPECTION ..........78 HAULING CARGO ............80...
  • Page 74 OPERATION WINCH OPERATION ........... 86...
  • Page 75 OPERATION WARNING Failure to inspect and verify that the vehicle is in safe operating condition before operating increases the risk of an accident. Always perform the Pre -Ride Inspection outlined in the Operation chapter before each use of your vehicle to make sure it's in safe operating condition. Always follow the inspection and maintenance procedures and schedules described in this owner's manual.
  • Page 76 OPERATION Know your riding area/tread lightly Vehicle Break-In Period Brake System Break-In Period Belt Break-In Period...
  • Page 77 OPERATION New Operator Driving Procedures...
  • Page 78 OPERATION Avoid sharp turns • Don’t turn when stepping on the accelerator. • Don’t swerve when driving the vehicle. • Operate according to your skills conditions and terrain. • Do not jump the vehicle or perform any other driving stunts. Driving with Passengers...
  • Page 79 OPERATION Starting the Vehicle ， Park the Vehicle Braking NOTICE When the throttle pedal is released completely and engine speed slows to near idle, the vehicle has no engine braking.
  • Page 80 OPERATION Parking the vehicle Driving on Slippery Surfaces NOTICE Severe damage to drive train may occur if the 4X4 is engaged while the wheels are spinning. Allow the rear wheels to stop spinning before engaging 4X4, or engage 4X4 before wheels begin to lose traction.
  • Page 81 OPERATION Driving through water NOTICE Major engine damage can result if the vehicle is not thoroughly inspected after operating in water. Perform the services outlined in the Periodic Maintenance Chart. The following areas need special attention: engine oil, transmission oil, demand drive fluid and all grease fittings.
  • Page 82 OPERATION Driving in reverse Driving over obstacles Driving uphill...
  • Page 83 OPERATION Driving downhill...
  • Page 84 OPERATION Driving on a sidehill (sidehilling) If crossing a sidehill is unavoidable, follow these precautions: Parking on an incline Avoid parking on an incline if possible. If it's unavoidable, follow these precautions: Parking the vehicle...
  • Page 85 OPERATION Engine Break-In Guidelines NOTICE During this period, avoid full-throttle running, rapid acceleration, and constant rpm operation.
  • Page 86 OPERATION PRE-RIDE INSPECTION Item Note Page Brake system/pedal Ensure proper operation travel Brake fluid Ensure appropriate level P127 Check and lubricate if Front suspension P134 necessary Check and lubricate if Rear suspension P134 necessary Tire Check status and pressure p129 Check to ensure the tightness Wheel/fastener p132...
  • Page 87 OPERATION Check the length of the seat belt for damage and check Seat belt whether the latch is in normal operation...
  • Page 88 OPERATION HAULING CARGO WARNING...
  • Page 89 OPERATION WARNING SECURE ALL LOADS BEFORE OPERATING. OPERATE ONLY WITH STABLE AND SAFELY ARRANGED LOADS. HEAVY LOADS CAN CAUSE BRAKING AND CONTROL PROBLEMS. USE EXTREME CAUTION DO NOT TRAVEL FASTER THAN THE RECOMMENDED SPEEDS...
  • Page 90 OPERATION Belt life Towing loads WARNING Towing improperly can alter vehicle handling and may cause loss of control or brake instability.
  • Page 91 OPERATION Maximum loading capacity ： Vehicle Model SGW1000F Maximum weight capacity 680 kg Maximum cargo load 350 kg Maximum unbraked towing mass 400 kg Maximum unbraked tongue mass 110 kg Maximum inertiabraked towing mass 700 kg Maximum inertiabraked tongue mass 110 kg Dumping the cargo box WARNING...
  • Page 92 OPERATION WARNING Operating the vehicle while the cargo box is raised could result in severe injury. The box could close unexpectedly and cause injury to the driver or passenger. The rear tires will also catch the rear of a raised box, damaging the vehicle and creating hazardous driving conditions.
  • Page 93 OPERATION Trailer Where a designated attachment point is provided on the towbar:...
  • Page 94 OPERATION WINCH OPERATION WARNING The user must read and understand the operating instructions and warnings of this owner's manual. If the instructions or warnings are not followed, serious property damage or personal injury may occur.
  • Page 95 OPERATION...
  • Page 96 OPERATION...
  • Page 97 OPERATION WARNING When releasing or retrieving the winch rope, both ends of the rope must be left with sufficient length to prevent the rope from being over-rolled in or out. When the rope is retrieving, please maintain a certain tension so that the wire can be retracted smoothly and can be wound tightly during retrieving.
  • Page 98 OPERATION Winch Operation Manual Release switch of Winch Manual release switch of Winch Operation of control Switch OUT：Release the winch cable IN：Recoil the winch cable...
  • Page 99 OPERATION Remote control operation Release the winch cable Reclaim the winch cable NOTICE When the remote control doesn’t work, it may be that the battery in the remote control is exhausted. Replace the battery with a new one.
  • Page 100 PERIODIC MAINTENANCE ........95 LUBRICATING OIL ............100 ENGINE OIL MAINTENANCE PROGRAM ....104 FRONT/REAR GEARBOX (DEMAND DRIVE)FLUID . 114 SPARK PLUG ............... 120 COOLANT ..............123 BRAKE SYSTEM ............126...
  • Page 101 TIRE ................129 SHOCK ABSORBER ADJUSTMENT ......133 LUBRICATION ............. 134 AIR FILTER ..............136 LAMP ................139 SPARK ARRESTER ............. 145 BATTERY ..............147 FUSE ................152...
  • Page 102 APPEARANCE CARE ..........157...

  • Page 103: Periodic Maintenance

    PERIODIC MAINTENANCE Severe use is defined as: • Frequent immersion in mud, water, or sand. • Frequent or prolonged operation in dusty environments. • Short trip cold weather operation. • Racing or racing-style high RPM use. • Prolonged low speed, heavy load operation. •...
  • Page 104 Maintenance Chart Key WARNING Improperly performing the procedures marked with a D could result in component failure and lead to serious injury or death. Have an authorized Segway Powersports dealer or other qualified person perform these services.
  • Page 105 （ ）...
  • Page 106 （ ）...
  • Page 107 （ ） （ ）...

  • Page 108: Lubricating Oil

    LUBRICATING OIL...
  • Page 109 Front service lid...
  • Page 110 Cargo Box WARNING Do not carry passengers on cargo container.Whenloading the goods, do not exceed the maximum load of the container. Cargo box tailgate...
  • Page 111 Lift cargo bed CAUTION Before lifting the container for unloading, Open the tailgate of the cargo box first.

  • Page 112: Engine Oil Maintenance Program

    ENGINE OIL MAINTENANCE PROGRAM WARNING Vehicle operation with insufficient, degraded or contaminated engine oil will cause accelerated wear and tear, and may result in engine failures, accidents and / or injuries. Always perform the maintenance procedures listed in the periodic maintenance chart.
  • Page 113 Oil Recommendation CAUTION Mixing brands or using non-recommended oils may cause engine damage.
  • Page 114 Engine Oil Level Check NOTICE Running the engine with an improper oil level can cause serious engine damage. Daily Oil Level Check Upper Line Lower Line Oil Filler cap...
  • Page 115 Oil Level Check After Oil Change NOTICE Note: This procedure is only for the new vehicle first oil level check or after an oil change in engine.
  • Page 116 Do not dispose used oil and filters in domestic garbage, sewers or on the ground. For information on oil recycling or scrapping, please consult your Segway Powersports Powersports dealer. Do not put used engine oil in a place where children can reach.
  • Page 117 Drain the Engine Oil Oil drain position 2 Oil drain position 1 Oil Drain Plug O-ring Oil Filter Strainer O-ring Oil Drain Plug Oil drain position 1...
  • Page 118 Oil drain position 2 WARNING Hot oil can cause skin burns. Don't let hot oil touch the skin Torque Drain Plug: 11.8-14.8ft·lb. (16~20N.m)
  • Page 119 Replace Oil Filter/Oil Strainer IMPORTANT Change the oil filter and clean the oil strainer with each oil change Change the Oil filter...
  • Page 120 Oil Strainer Cleaning Oil drain plug O-ring Oil filter Torque Oil drain plug: 16~20N.m...
  • Page 121 Add Engine Oil...

  • Page 122: Front/Rear Gearbox (Demand Drive)Fluid

    FRONT/REAR GEARBOX (DEMAND DRIVE) FLUID NOTICE If the front gearbox makes too much noise during 4WD operation, change the demand drive fluid. If the noise continues, see your Segway Powersports dealer.
  • Page 123 Check the Rear Gear Box Oil Level...
  • Page 124 Front/Rear Gearbox Oil change Torque Plug: 16-20N.m Drain...
  • Page 125 Add gear oil Filling Plug o-ring Oil Dipstick o-ring Torque Filling Plug: 16-20N.m...
  • Page 126 CVT belt WARNING Failure to remove all debris when the belt is replaced can result in vehicle damage, loss of control and serious injury or death CVT cover bolt CVT cover 　　 CVT cover seal CVT belt replacement tool...
  • Page 127 Install the drive belt CVT cover bolt Torque : 6 N.m Drying the CVT...

  • Page 128: Spark Plug

    SPARK PLUG CAUTION The use of anything but the recommended spark plug can cause serious engine damage. Always use the recommended spark plugs or their equivalents. Spark Plug NGK CPR7EA / Model TORCH B7RTC Spark Plug Gap 0.7-0.9 mm Spark Plug Torque 8.8 ft.
  • Page 129 Spark Plug Inspection CAUTION Allow the engine to cool before attempting to remove the spark plug for inspection. Hot exhaust system and engine will cause burns. Bolt Ignition coil Spark plug Spark plug...

  • Page 131: Coolant

    COOLANT...
  • Page 132 Coolant bottle...
  • Page 133 Radiator coolant CAUTION Steam escaping can cause burns.Do not disassemble pressure relief cap when there is temperature or heat in the engine.The engine must be allowed to cool down before the pressure cap is removed.

  • Page 134: Brake System

    BRAKE SYSTEM WARNING Brake fluid levels must be checked periodically. Overfilling of the brake cylinder may cause brake resistance or brake locking, which may result in serious injury or death. Keep the brake fluid at the recommended level and do not overfill. Must check brake disc brake disc wear condition regularly.
  • Page 135 Brake Fluid Brake Oil DOT4...
  • Page 136 NOTICE Brake fluid can damage plastic and painted surfaces and should be added with caution. If the brake fluid comes into contact with the skin or eyes, flush with plenty of water immediately. If you feel sick, seek medical attention immediately.

  • Page 137: Tire

    TIRE Tire Pressure Recommended Front wheels Rear wheels 15.0 psi ( 103 kPa) 16 psi ( 110 kPa) tire pressures Tread Depth Inspection method 1： △...
  • Page 138 Inspection method 2： When to Replace a tire: Replace the Tires...
  • Page 139 Wheel Removal Torque to Specification： Torque Mounting nuts: 100~120N m...
  • Page 140 CAUTION The loose nut may cause the tire to fall off during operation, which may cause an accident or rollover. Always ensure that all nuts are tightened to the required value 100~120N·m . Do not use lubricating oil or grease on wheel bolts or wheel nuts. Lubricating oil or grease may cause excessive tightening of wheel nuts, resulting in damage to bolt or spoke wheels.

  • Page 141: Shock Absorber Adjustment

    SHOCK ABSORBER ADJUSTMENT Position Position CAUTION When adjusting the shock absorption position, always adjust the left and right shock absorption to the same position. Step up or down one position at a time during adjustment. Do not try to make large adjustments, which may damage the shock absorber.

  • Page 142: Lubrication

    LUBRICATION...
  • Page 143 Front/Rear Drive Axle Dustcover...

  • Page 144: Air Filter

    AIR FILTER Replacing Air Filter element ir filter cover Filter element box Filter element...
  • Page 145 Air filter inlet cap and CVT inlet mesh fabric Air filter inlet cap CVT inlet mesh fabric...
  • Page 146 WARNING When assembling the filter element, please make sure that the buckles of the filter element and the end cover are installed in place, otherwise it will cause the engine to malfunction or reduce the service life When the vehicle is driving in a dusty environment, please shorten the time interval for checking the filter element The air filter is soaked or the filter element is wet, please drain the water and replace the filter element...

  • Page 147: Lamp

    LAMP CAUTION Poor lighting can result in reduced visibility while driving. Please clean the headlamps frequently and replace non-working headlamps promptly. To ensure optimum visibility and saftey, make sure the lights are properly adjusted. Change the headlight LED lights Halogen lamp...
  • Page 148 CAUTION Hot ingredients can cause skin burns. Allow the lights to cool before doing maintenance. DO NOT touch the headlight shade bulb glass. Fingerprints on the glass can to cause premature failure. Execute the following procedure: Expansion screw Headlight guard...
  • Page 149 CAUTION Please replace lamp with the recommended power. Replace taillight/rear turn light Procedures for changing taillights:...
  • Page 150 High beam adjustment CAUTION The following pictures are for reference only. Your model may be slightly different. It is best for a Segway dealer to adjust if conditions permit.
  • Page 152 Adjust the headlight beam upwards and downwards Adjust the headlight beam left and right...

  • Page 153: Spark Arrester

    SPARK ARRESTER WARNING Make sure the exhaust pipes are cool. Ensure that there are no combustible materials in the area when maintaining the vehicle. Safety glasses are recommended in this procedure. Pan head screwM6×16 Muffler spark suppressor...
  • Page 154 ，...

  • Page 155: Battery

    BATTERY WARNING 12V batteries contain toxic and corrosive sulfuric acid and may produce flammable explosive hydrogen gas.To reduce the risk of serious injury or death, the following precautions should be observed when handling 12V batteries or working near them: • Do not smoke or light a match near a 12V battery. •...
  • Page 156 Battery Removal NOTICE If the electrolyte overflows, immediately wash it off with a solution of 1 tablespoon baking soda and 1 cup water to prevent damage to the vehicle. Battery pull strap Protective rubber sleeve Positive and negative anchor bolts for cable Positive and negative anchor nuts for cable...
  • Page 157 Battery Charging NOTICE When charging, the hydrogen produced by the 12V battery is combustible explosive gas. Please follow the following precautions before charging: If charging the 12V battery is still installed in the vehicle, be sure to disconnect the ground cable. Make sure the power switch on the charger is off when connecting and disconnecting the charger cable to the 12V battery.
  • Page 158 Battery Installation NOTICE To reduce the chance of sparks, disconnect the black (negative) cable first. When reinstalling the battery, install the black (negative) cable last.

  • Page 160: Fuse

    FUSE NOTICE • Do not use a fuse above the rated ampere value or replace it with anything else. • Please use the same product.Never use wires for fuses, even temporary replacements are not allowed. • Do not modify fuses or fuse boxes.
  • Page 161 Fuse Box NOTICE Pay attention to the direction of installation. The label may be slightly different from the image below.
  • Page 162 Fuse/Relay Distribution and Rated Amperage Rated amperage of fuse/relay and distribution...
  • Page 163 Fuse/Relay Power LOCK FUSE HEAD LIGHT FUSE 12V C P S FUSE FUEL PUMP FUSE 12V-IG FUSE SW-IG FUSE ECU-IG FUSE SIG-IG FUSE EPS-IG FUSE MAIN FUSE ECU FUSE EPS FUSE FAN FUSE REMOTE POWER-ON RELAY 12V 20A AUXILIARY START RELAY 12V 20A IG1 RELAY 12V 20A...
  • Page 164 Fuse Box Replacement Puller Spare fuse NOTICE...
  • Page 165 APPEARANCE CARE Vehicle Washing Vehicle Storage...

  • Page 166: Specifications

    SPECIFICATIONS TECHNICAL PARAMETERS OF VEHICLE ....159 VEHICLE IDENTIFICATION NUMBER ....... 163...
  • Page 167 SPECIFICATIONS TECHNICAL PARAMETERS OF VEHICLE （ ）...
  • Page 168 SPECIFICATIONS ～ ： ： ： ： （ ） （ ） （ ） （ ） （ ）...
  • Page 169 SPECIFICATIONS （ ） ， （ ）...
  • Page 170 SPECIFICATIONS （ ） （ ） （ ）/ （ ） （ ） （ ） （ ）（ ）...
  • Page 171 SPECIFICATIONS VEHICLE IDENTIFICATION NUMBER...
  • Page 172 SPECIFICATIONS...
  • Page 173 SPECIFICATIONS The frame nameplate...

  • Page 174: Troubleshooting

    TROUBLESHOOTING...
  • Page 175 TROUBLESHOOTING Drive belt and cover problems Possible Cause Solution Driving the vehicle onto Shift transmission to low range during a pickup or tall trailer in loading of the vehicle to prevent belt high range burning Starting out going up a When starting out on an incline, use low steep incline range (see page 75)
  • Page 176 TROUBLESHOOTING Possible Cause Solution Shift the transmission to low range, and carefully use fast, aggressive throttle Stuck in mud or application to engage clutch. WARNING: snow Excessive throttle may cause loss of control and vehicle overturn Shift the transmission to low range, C l i m b i n g o v e r l a r g e and carefully use fast, brief, aggressive objects from a...
  • Page 177 TROUBLESHOOTING Engine doesn’t turn over Possible Cause Solution C hec k fo r fo ule d p lugs o r fo rei gn Poor engine material in gas tank, fuel lines, or performance throttle. Contact your dealer for service. Tripped circuit Reset the breaker breaker Low battery voltage...
  • Page 178 TROUBLESHOOTING Engine stops or loses power Possible Cause Solution C le a n rad ia to r s cre en a nd co re i f equipped Overheated engine Clean engine exterior See your dealer Engine turns over, fails to start Possible Cause Solution Out of Fuel...
  • Page 179 TROUBLESHOOTING Clogged fuel injector Clean or replace new fuel injector Low battery voltage Recharge battery to 12.5 VDC Mechanical failure See your dealer Engine backfires Possible Cause Solution Weak spark from spark Inspect, clean and/or replace spark plugs plugs Incorrect spark plug gap Set gap to specs or replace plugs or heat range Old or non-...
  • Page 180 TROUBLESHOOTING Engine runs irregularly, stalls or misfires Possible Cause Solution Fouled or defective spark Inspect, clean and/or replace spark plugs plugs Worn or defective spark See your dealer plug wires Incorrect spark plug gap Set gap to specs or replace plugs or heat range Loose ignition Check all connections and tighten...
  • Page 181 TROUBLESHOOTING Engine runs irregularly, stalls or misfires Possible Cause Solution Kinked or plugged fuel Inspect and replace vent line Incorrect fuel Replace with recommended fuel Clogged air filter Inspect and clean or replace Reverse speed limiter See your dealer malfunction Electronic throttle See your dealer control malfunction...
  • Page 182 TROUBLESHOOTING Engine stops or loses power Possible Cause Solution Out of fuel refuel Kinked or plugged fuel Inspect and replace vent line Water present in fuel Replace with new fuel Inspect, clean and/or replace spark Overuse of choke plugs Fouled or defective spark Inspect, clean and/or replace spark plugs plugs...

  • Page 183: Emission Control System

    EMISSION CONTROL SYSTEM SOURCE OF EXHAUST EMISSIONS ......176 EXHAUST EMISSION CONTROL SYSTEM ....176 CRANKCASE EMISSION CONTROL SYSTEM ..176 NOISE CONTROL SYSTEM ........176...
  • Page 184 EMISSION CONTROL SYSTEM SOURCE OF EXHAUST EMISSIONS EXHAUST EMISSION CONTROL SYSTEM CRANKCASE EMISSION CONTROL SYSTEM NOISE CONTROL SYSTEM...
  • Page 185 EMISSION CONTROL SYSTEM Declaration of Driver’s exposure to noise level ，...
  • Page 186 EMISSION CONTROL SYSTEM Declaration of Vibration declaration ，...

  • Page 187: Warranty

    WARRANTY LIMITED WARRANTY ............180 REGISTRATION ..............180 EXCLUSIONS-ARE NOT WARRANTED ......180 LIMITATIONS OF WARRANTIES AND REMEDIES....181 MAINTENANCE LOG ............184...
  • Page 188 WARRANTY LIMITED WARRANTY SEGWAY TECHNOLOGY CO., LTD REGISTRATION EXCLUSIONS-ARE NOT WARRANTED...
  • Page 189 WARRANTY LIMITATIONS OF WARRANTIES AND REMEDIES...
  • Page 190 WARRANTY...
  • Page 191 WARRANTY...
  • Page 192 WARRANTY MAINTENANCE LOG...

This manual is also suitable for:

Fugleman ut10

Table of Contents
