- Page 1 SWEEPER SR 1100 P/B SR 5110 P/B MANUAL FOR USE AND MAINTENANCE 146 1709 000(1) 2004-03 GB...
-
Page 2: Table Of Contents
Tot weight: Noise level: Tot weight: Voltage: (w/o battery) TypeG&E Floor cleaning machine. MADE IN ITALY Nilfisk-Advance Italia Località Novella terza 26862 Guardamiglio (Italia) INTRODUCTION/GENERAL INFORMATION ........................1 SPARE PARTS AND MAINTENANCE ..............................1 CHANGES AND IMPROVEMENTS ................................1 NAME PLATE......................................1 GENERAL SAFETY RULES ..................................1 SAFETY- ACCIDENT PREVENTION ...............................1... -
Page 3: Introduction/General Information
Any “left” or “right” indication are always defined with reference to the machine forward movement direction. When calling Nilfisk-Advance for repair parts or service, please specify the Model and the Serial Number when discussing your machine. -
Page 4: Unpacking
USE AND MAINTENANCE MANUAL UNPACKING When the machine is delivered, carefully check that the packing and the machine were not damaged. If damage is evident, keep the packing for future checks and contact the Service Centre immediately. Please check that the following items are supplied with the machine: 1 - Envelope with cables for batteries and connector for battery-charger. - Page 5 USE AND MAINTENANCE MANUAL TECHNICAL DATA VERSION SR 1100B - SR 5110B SR 1100P - SR 5110P Voltage Engine model — Vanguard OHV Power at 3600 RPM — 4 Hp - 2,97 kW Displacement — 126 cc - (7,69 cu.in) Start —...
-
Page 6: Description Of Commands And Control Panel
USE AND MAINTENANCE MANUAL DESCRIPTION OF COMMANDS AND CONTROL PANEL 1 - Voltmeter/hourmeter push button 12 - Selection of forward/reverse speed, light ON/OFF, horn 2 - Display 13 - Steering wheel 3 - Button for selection/indicator of working program P1 14 - Pedal for flap lifting 4 - Button for selection/indicator of working program P2 15 - Brake pedal... -
Page 7: Preliminary Operations (Battery Version)
USE AND MAINTENANCE MANUAL PRELIMINARY OPERATIONS (battery version) The battery version needs a 24V battery assembly. The machine can be equipped: 1 - The battery is supplied with the machine and it is set, complete with acid solution. 2 - The battery is supplied with the machine and it is set, but not complete with acid solution. -
Page 8: Battery Filling Up With Acid Solution
USE AND MAINTENANCE MANUAL 2 - If the batteries are installed but not filled with acid solution they must be filled with a solution of sulphuric acid (density between 1,270 Kg and 1,290 Kg at 25°C temperature) according to the instructions specified below and in the Battery User Manual. - Page 9 USE AND MAINTENANCE MANUAL Connect the battery connector to the machine. Remove the cover from the battery 3 - If the machine is not equipped with batteries they must be procured and mounted. It is recommended to get the assistance of qualified personnel to choose and set the batteries.
-
Page 10: Preliminary Operations (Petrol Engine Version)
USE AND MAINTENANCE MANUAL PRELIMINARY OPERATIONS (petrol engine version) The petrol engine version needs two 12V batteries. The machine can be equipped: 1 - The battery is supplied with the machine and it is set, complete with acid solution. 2 - The battery is supplied with the machine and it is set, but not complete with acid solution. -
Page 11: Battery Filling Up With Acid Solution
USE AND MAINTENANCE MANUAL 2 - If the batteries are installed but not filled with acid solution they must be filled with a solution of sulphuric acid (density between 1,270 Kg and 1,290 Kg at 25°C temperature) according to the instructions specified below and in the Battery User Manual. - Page 12 USE AND MAINTENANCE MANUAL Connect the battery connector to the machine. Remove the cover from the battery 3 - If the machine is not equipped with batteries they must be procured and mounted. It is recommended to get the assistance of qualified personnel to choose and set the batteries.
-
Page 13: Machine Use (Battery Version)
USE AND MAINTENANCE MANUAL MACHINE USE (battery version) Insert the ignition key into the panel and turn it clockwise: the display will show all zeros and after about three seconds the battery voltage will appear. Note: The temporary lighting of the two side brush indicators and the short sound from the reverse speed acoustic indicator are to be considered a normal behaviour. -
Page 14: Use Of The Working Programs
USE AND MAINTENANCE MANUAL USE OF THE WORKING PROGRAMS It is possible to choose one of the two working programs P1 and P2 by pressing the related key. P1 is the “light cleaning program” (for internal environment, i.e. smooth floor, moquette, small debris etc.) P2 is the “hard cleaning program”... - Page 15 USE AND MAINTENANCE MANUAL It is possible to adjust the side brush/es turning speed by means of the dedicated knob. Select the forward speed by means of the command lever. Press the accelerator pedal to start the job. Note: By releasing the accelerator pedal (or setting the command lever to the neutral position) the automatic switch off of all functions will occur within 8 seconds (Auto Power Off);...
- Page 16 USE AND MAINTENANCE MANUAL During the filter-shaker operation, the suction fan continues to work (the automatic stop is not provided). To stop the suction fan during the filter-shaking, it is possible to operate in two ways: 1. Stop the fan by pressing the specific ON/OFF key. 2.
- Page 17 USE AND MAINTENANCE MANUAL Deselect the used working program (P1 and P2) after each working period. Before leaving the machine make sure that the side brushes are lifted, the parking brake engaged and the master key in the OFF position (counter clockwise). At the end of the job or whenever it is necessary empty the rear dirt container.
-
Page 18: Machine Use (Petrol Engine Version)
USE AND MAINTENANCE MANUAL MACHINE USE (petrol engine version) Insert the ignition key into the panel and turn it clockwise: the display will show all zeros and after about three seconds the battery voltage will appear. Note: The temporary lighting of the two side brush indicators and the short sound from the reverse speed acoustic indicator are to be considered a normal behaviour. -
Page 19: Use Of The Working Programs
USE AND MAINTENANCE MANUAL USE OF THE WORKING PROGRAMS After starting the “ECO” function it is possible to choose one of the two working programs: P1 is the “light cleaning program” (for internal environment, i.e. smooth floor, moquette, small debris etc.) P2 is the “hard cleaning program”... - Page 20 USE AND MAINTENANCE MANUAL It is possible to adjust the side brush/es turning speed by means of the dedicated knob. Select the forward speed by means of the command lever. Press the accelerator pedal to start the job. Note: When the accelerator is released or when the lever is in neutral position, the automatic switch off of all functions (Auto Power OFF) occurs within about 8 seconds, except for the “ECO”...
- Page 21 USE AND MAINTENANCE MANUAL To collect light and bulky debris lift the front flap using the left pedal (do not press the pedal down for a long time, not to reduce the suction capability of the machine). The machine gets an automatic breaking function when the accelerator pedal is released;...
- Page 22 USE AND MAINTENANCE MANUAL At the end of the job turn off the selected working program (P1 or P2) and switch the petrol engine off by pressing the button shown in the figure. Before leaving the machine make sure that the side brushes are lifted, the parking brake engaged and the master key in the OFF position (counter clockwise).
-
Page 23: Further Performances Of The Machine With Petrol Engine
USE AND MAINTENANCE MANUAL FURTHER PERFORMANCES OF THE MACHINE WITH PETROL ENGINE The machine equipped with the petrol engine is able to work with full performance even if the petrol engine is turned Off; this could occur just because the machine run out of the fuel or when it is necessary to work in a closed environment. -
Page 24: Side Brushes Adjustment And Replacement
USE AND MAINTENANCE MANUAL SIDE BRUSHES ADJUSTMENT AND REPLACEMENT Warning: the following operations must be done with the machine in Off condition and master key out, on a flat floor. When the side brush is worn its height must be adjusted. Loosen the knob. -
Page 25: Main Brush Replacement
USE AND MAINTENANCE MANUAL MAIN BRUSH REPLACEMENT Warning: the following operations must be done with the machine in Off condition and master key out. This machine is equipped with an automatic control of the main brush pressure; this also means that the position of the main brush is automatically adjusted (no need of manual adjustment). - Page 26 USE AND MAINTENANCE MANUAL Remove the worn out brush. With a screwdriver, remove the plastic adapter from the worn brush. Secure the plastic adapter to the new brush being careful to the proper bristles orientation (see in figure). Reinstall the brush by checking the proper coupling between the plastic adapter and the hub on the opposite side of the compartment.
-
Page 27: Filter Cleaning And Replacement
USE AND MAINTENANCE MANUAL FILTER CLEANING AND REPLACEMENT The panel filter requires a regular cleaning. Lift the lid. Remove the lid of the filter compartment. Disconnect the filter-shaker motor harness (the machine must be turned off and the key taken out). Loosen the two screws with butterfly head on the two sides of the metal frame fixing the panel filter;... - Page 28 USE AND MAINTENANCE MANUAL After cleaning, fit the filter and the relevant fixing frame. Tighten the two screws with butterfly head and reconnect the filter shaker electric cable. If the filter is damaged or can not be properly cleaned replace it with a new one. Ask to your supplier for the new spare parts list.
-
Page 29: Maintenance
USE AND MAINTENANCE MANUAL MAINTENANCE BATTERIES: CONTROL AND RECHARGE Make a frequent check of the electrolyte level inside every battery cell. The battery compartment is under the operator seat; lift the lid and open the caps of all the battery cells: when necessary fill up the cells with distilled water. -
Page 30: Brakes Adjustment
USE AND MAINTENANCE MANUAL BRAKES ADJUSTMENT When the pedal brake or the parking brake reach a low efficiency operation some adjustments can be done on the front wheel (models SR 1100 e SR 5110) by loosening the locking nut A, turning the adjuster B and tightening the locking nut A. -
Page 31: Maintenance Of The Petrol Engine
USE AND MAINTENANCE MANUAL MAINTENANCE OF THE PETROL ENGINE It is necessary to read the engine Use and Maintenance Manual carefully and to follow some practical advices: Check the engine oil level at each working session; for possible fill up read the oil type specified on the engine Manual. - Page 32 USE AND MAINTENANCE MANUAL Make a periodic check of the engine air filter. Clean or replace the air filter according to the engine Use and Maintenance Manual or when it is necessary. Remove the front panel to reach the air filter. 146 1709 000(1)2004-03 GB...
-
Page 33: Summary Of Maintenance Controls (Battery Version)
USE AND MAINTENANCE MANUAL SUMMARY OF MAINTENANCE CONTROLS (battery version) Warning: the following interventions must be done with machine in Off condition and master key out. All the periodic maintenance operations must be performed by skilled personnel or by an authorized service centre. -
Page 34: Summary Of Maintenance Controls (Petrol Version)
USE AND MAINTENANCE MANUAL SUMMARY OF MAINTENANCE CONTROLS (petrol version) Warning: the following interventions must be done with machine in Off condition and master key out. All the periodic maintenance operations must be performed by skilled personnel or by an authorized service centre. -
Page 35: Optional Items
USE AND MAINTENANCE MANUAL OPTIONAL ITEMS High capacity batteries both for the petrol version and for the battery version. Battery charger. Different types of main bushes and side brushes. Polyester panel filter (it can be washed) For further information about optional devices, please contact the machine supplier. -
Page 36: Safety Functions And Troubleshooting
USE AND MAINTENANCE MANUAL SAFETY FUNCTIONS AND TROUBLESHOOTING The machine is equipped with many safety devices and functions which have been described in the USE paragraphs (both for petrol and electrical versions). For instance the automatic stop of all functions to avoid the deep discharge of the battery has been mentioned;... -
