  • Page 1 SWEEPER SR 1100 P/B SR 1200 P/B SR 5110 P/B SR 5120 P/B Manual for use and maintenance FORM No. S31NUK5120(3)2001-04...
  • Page 2: Table Of Contents

    INDEX Prod. No.: Model: Serial No.: Max axel rear: Power: Max axel front: Tot weight: Noise level: Tot weight: Voltage: (w/o battery) Type G&E Floor cleaning machine. MADE IN ITALY Nilfisk-Advance Italia Località Novella terza 26862 Guardamiglio (Italia) INTRODUCTION / GENERAL INFORMATION ... 1 UNPACKING ...
  • Page 3: Introduction / General Information

    INTRODUCTION / GENERAL INFORMATION This manual will help you get the most from your Nilfisk SR1100 - SR1200. Read it thoroughly before operating the machine. Specifications and details are subject to change without prior notice. SPARE PARTS AND MAINTENANCE Repairs, when required, should be performed by Nilfisk-Advance service personnel using Nilfisk-Advance original replacement parts and accessories.
  • Page 4: Unpacking

    UNPACKING S31NUK5120(3)2001-04 Please check that the following items are supplied with the machine: 1 - envelope with cables for batteries and connector for battery-charger. 2 - technical documents (Spare Parts Catalogue, Manual for Use and Maintenance and - for the petrol version only - Use and Maintenance Manual of the engine).
  • Page 5: Technical Data

    TECHNICAL DATA VERSION SR 1100B - SR 5110B SR 1100P - SR 5110P SR 1200B - SR 5120B SR 1200P - SR 5120P Voltage Engine model Nominal Power at 3600 Power at 3200 RPM setting Start Drive electric motor 450W - 120 RPM Main brush electrical 500W - 1600 RPM motor...
  • Page 6: Description Of Commands And Control Panel

    DESCRIPTION OF COMMANDS AND CONTROL PANEL 1 - Voltmeter/hourmeter push button 2 - Display 3 - Button for selection/indicator of working program P1 4 - Button for selection/indicator of working program P2 5 - ON/OFF button and indicator of suction motor 6 - Knob for the speed adjustment of the side brushes...
  • Page 7: Preliminary Operations

    PRELIMINARY OPERATIONS Both versions of the machine, petrol and battery, require a 24 V battery set. Depending on the country where the machine is sold three possibilities can occur: 1 - the battery is supplied with the machine and it is set, complete with acid solution 2 - the battery is supplied with the machine and it is set, but not complete with acid solution...
  • Page 8 PRELIMINARY OPERATIONS 2 - If the batteries are installed but not filled with acid solution they must be filled with a solution of sulphuric acid (density between 1,270 Kg and 1,290 Kg at 25°C temperature) according to the instructions specified below and in the Battery User Manual.
  • Page 9: Preliminary Operations

    PRELIMINARY OPERATIONS Connect the battery connector to the machine. 3 - If the machine is not equipped with batteries they must be procured and mounted. It is recommended to get the assistance of qualified personnel to choose and set the batteries.
  • Page 10: Use

    Insert the ignition key into the panel and turn it clockwise: the display will show all zeros and after about three seconds the battery voltage will appear. Note : the temporary lighting of the two side brush indicators and the short sound from the reverse speed acoustic indicator are to be considered a normal behaviour.
  • Page 11: Use Of The Working Programs

    USE OF THE WORKING PROGRAMS Once the machine has been turned on and eventually after starting the petrol engine, choose one of the two working programs P1 and P2 according to your cleaning need and press the relevant button: P1 is the “light cleaning program” (for internal environment, i.e.
  • Page 12 It is possible to adjust the side brush/es turning speed by means of the dedicated knob. Select the forward speed by means of the command lever. Press the accelerator pedal to start the job. Note : by releasing the accelerator pedal (or setting the command lever to the neutral position) the automatic switch off of all functions will occur within 8 seconds (Auto...
  • Page 13 S31NUK5120(3)2001-04 To collect light and bulky debris lift the front flap using the left pedal (do not press the pedal down for a long time, not to reduce the suction capability of the machine). The machine gets an automatic breaking function when the accelerator pedal is released;...
  • Page 14 S31NUK5120(3)2001-04 At the end of the job turn off the selected working program (P1 or P2) and switch the petrol engine off by pressing the button shown in the figure. Before leaving the machine make sure that the side brushes are lifted, the parking brake engaged and the master key in the OFF position.
  • Page 15: Further Performances Of The Machine With Petrol Engine

    S31NUK5120(3)2001-04 FURTHER PERFORMANCES OF THE MACHINE WITH PETROL ENGINE The machine equipped with the petrol engine is able to work with full performance even if the petrol engine is turned Off; this could occur just because the machine run out of the fuel or when it is necessary to work in a closed environment.
  • Page 16: Side Brushes Adjustment And Replacement

    SIDE BRUSHES ADJUSTMENT AND REPLACEMENT Warning: the following operations must be done with the machine in Off condition and master key out, on a flat floor. When the side brush is worn its height must be adjusted. Loosen the knob. Turn the adjusting disk and move its position of one hole.
  • Page 17: Main Brush Replacement

    MAIN BRUSH REPLACEMENT S31NUK5120(3)2001-04 Warning: the following operations must be done with the machine in Off condition and master key out. This machine is equipped with an automatic control of the main brush pressure; this also means that the position of the main brush is automatically adjusted (no need of manual adjustment).
  • Page 18 MAIN BRUSH REPLACEMENT S31NUK5120(3)2001-04 Remove the worn out brush. Fit the new brush in its compartment, paying attention to the engagement of the plastic adapter with the hub on the opposite side of the compartment. Fit the lid of the main brush compartment using the three knobs previously removed.
  • Page 19: Filter Cleaning And Replacement

    FILTER CLEANING AND REPLACEMENT S31NUK5120(3)2001-04 The panel filter requires a regular cleaning. Lift the lid. Remove the lid of the filter compartment. Disconnect the electric cable of the filter-shaker motor (the machine must first be switched off and the key out). Loosen the two screws with butterfly head on the two sides of the metal frame fixing the panel filter;...
  • Page 20: Filter Cleaning And Replacement

    FILTER CLEANING AND REPLACEMENT S31NUK5120(3)2001-04 After cleaning, fit the filter and the relevant fixing frame. Tighten the two screws with butterfly head and reconnect the filter shaker electric cable. If the filter is damaged or can not be properly cleaned replace it with a new one. Ask to your supplier for the new spare parts list.
  • Page 21: Maintenance

    MAINTENANCE BATTERIES: CONTROL AND RECHARGE Make a frequent check of the electrolyte level inside every battery cell. The battery compartment is under the operator seat; lift the lid and open the caps of all the battery cells: when necessary fill up the cells with distilled water.
  • Page 22: Brakes Adjustment

    MAINTENANCE BRAKES ADJUSTMENT When the pedal brake and/or the parking brake reach a low efficiency operation some adjustments can be done on the front wheel (models SR 1100 e SR 5110): - loosen the locking nut A - turn adjuster B - tighten locking nut A.
  • Page 23: Maintenace Of The Petrol Engine

    MAINTENANCE OF THE PETROL ENGINE (HONDA) MAINTENANCE OF THE PETROL ENGINE (HONDA) First: read thoroughly the Use and Maintenance Manual of the engine. Here below some recommendations are pointed out. Check the engine oil level at each working session; for possible fill up read the oil type specified on the engine Manual Warning: the engine oil must be replaced the first time after 20 working hours or, in...
  • Page 24: Maintenance

    MAINTENANCE Remove the cap from the engine oil emptying hose and let the oil come out. Note: it is suggested to remove the oil when the engine is warm. Dispose of the used oil in proper special containers. Note: keep the emptying hose lifted and open during filling.
  • Page 25: Summary Of Maintenance Controls (Battery Version)

    SUMMARY OF MAINTENANCE CONTROLS (battery version) Warning: the following interventions must be done with machine in Off condition and master key out. All the periodic maintenance operations must be performed by skilled personnel or by an authorized service centre. Note: the battery life will depend on a good periodic maintenance (check of the level of the electrolyte and of battery voltage).
  • Page 26: Summary Of Maintenance Controls (Petrol Version)

    SUMMARY OF MAINTENANCE CONTROLS (petrol version) Warning: the following interventions must be done with machine in Off condition and master key out. All the periodic maintenance operations must be performed by skilled personnel or by an authorized service centre. Every maintenance intervention on the petrol engine must be performed in agreement with the engine User Manual.
  • Page 27: Optional Items

    OPTIONAL ITEMS S31NUK5120(3)2001-04 High capacity batteries both for the petrol version and for the battery version. Battery charger Different types of main bushes and side brushes Polyester panel filter (it can be washed) -Mini containers -Flashing beacon on support -Rollbar -Flashing beacon on rollbar -Front rollers and side bumpers -Non marking wheels...
  • Page 28: Safety Functions And Trouble-Shooting

    SAFETY FUNCTIONS AND TROUBLE- SHOOTING The machine is equipped with many safety devices and functions which have been described in the USE paragraphs (both for petrol and electrical versions). For instance the automatic stop of all functions to avoid the deep discharge of the battery has been mentioned;...
  • Page 29: Service Addresses

    SERVICE ADDRESS AUSTRALIA Nilfisk-Advance Pty. Ltd. ACN 003 762 623 Head office: 17 Leeds Street, Rhodes, N. S. W. 2138 Tel.(02) 9736 1244 - Fax (02) 9736 3910 Customer Responce Centre: Tel.1 800 011 013 BELGIQUE/BELGIË/LUXEMBOURG Nilfisk-Advance s.a./n.v. Doornveld/Sphere Business Park Industrie Asse 3, nr 11- bus 41 1731 Zellik-Asse Tel.(02) 467.60.50 Fax (02) 463.44.16...
  • Page 30 Nilfisk-Advance Italia S.p.A Località Novella Terza 26862 Guardamiglio (Lodi) Italia www.nilfisk-advance.com Phone: +39 0377 451124 Fax: +39 0377 51443 Printed in Italy...
