Phytec phyCORE-PXAG49 Quick Start Instructions

Hide thumbs

Table Of Contents

Table of Contents

Quick Links

Download this manual

phyCORE-PXAG49

QuickStart Instructions

Using PHYTEC FlashToolsOCF for on-chip Flash and the

Tasking XA Embedded Development Environment (EDE)

Evaluation Version

Note: The PHYTEC Spectrum CD includes the electronic version of

the phyCORE-PXAGx English Hardware Manual

Hinweis: Die PHYTEC Spectrum CD beinhaltet die elektronische

Version des deutschen phyCORE-PXAGx Hardware Manuals

Edition: July 2002

A product of a PHYTEC Technology Holding company

Table of Contents

Need help?

Do you have a question about the phyCORE-PXAG49 and is the answer not in the manual?

Questions and answers

Summary of Contents for Phytec phyCORE-PXAG49

Page 1 Using PHYTEC FlashToolsOCF for on-chip Flash and the Tasking XA Embedded Development Environment (EDE) Evaluation Version Note: The PHYTEC Spectrum CD includes the electronic version of the phyCORE-PXAGx English Hardware Manual Hinweis: Die PHYTEC Spectrum CD beinhaltet die elektronische Version des deutschen phyCORE-PXAGx Hardware Manuals...
Page 2 PHYTEC Meßtechnik GmbH neither gives any guarantee nor accepts any liability whatsoever for consequential damages resulting from the use of this manual or its associated product. PHYTEC Meßtechnik GmbH reserves the right to alter the information contained herein without prior notification and accepts no responsibility for any damages which might result.
Page 3: Table Of Contents
1.5 The Tasking XA Embedded Development Environment (EDE) ..............7 2 Getting Started ..................11 2.1 Installing Rapid Development Kit Software.......11 2.2 Interfacing the phyCORE-PXAG49 to a Host-PC .....18 2.3 Starting PHYTEC FlashToolsOCF for Windows.......20 2.4 Downloading Example Code with FlashTools ......21 2.4.1 "Blinky"...
Page 4 5.2 Start.src..................82 5.3 Linking and Locating ..............83 Index of Figures Figure 1: Mounting the phyCORE-PXAG49 onto the phyCORE Development Board LD 5V ........18 Figure 2: Important Connectors, Buttons and Suitable Jumper Settings on the phyCORE Development Board LD 5V ......19 Figure 3: Power Connector ................
Page 5: Introduction To The Rapid Development Kit
User's Manuals and Data Sheets • this QuickStart Instruction with general “Rapid Development Kit” description, software installation hints and three example programs enabling quick out-of-the box start-up of the phyCORE-PXAG49 in conjunction with the Tasking software development tools © PHYTEC Meßtechnik GmbH 2002...
Page 6: Overview Of This Quickstart Instruction
Tasking XA software development tools. It is structured as follows: The “Getting Started” section uses two example programs: • "Blinky" and "Hello" to demonstrate the download of user code to the Flash device using PHYTEC FlashTools for on-chip Flash (OCF).
Page 7: System Requirements
Introduction 1.3 System Requirements Use of this “Rapid Development Kit” requires: • the phyCORE-PXAG49 SBC module • the phyCORE Development Board LD 5V with the included DB-9 serial cable and AC adapter supplying 5 VDC/min. 500 mA • the PHYTEC Spectrum CD •...
Page 8: The Phytec Phycore-Pxag49
All applicable data/address lines and applicable signals extend from the underlying logic devices to standard-width (2.54 mm / 0.10 in.) pin headers lining the circuit board edges. This enables the phyCORE-PXAG49 to be plugged like a “big chip” into target hardware. The standard memory configuration of the phyCORE-PXAG49 features 64 kByte on-chip Flash, 256 kByte external SRAM and 256 kByte external Flash for additional code storage.
Page 9 • three I/O Chip Select signals for connection to external peripherals • requires only a +5 V / 220 mA power source • operates temperature range 0... 70°C (optional -40... 85°C temperature range available) © PHYTEC Meßtechnik GmbH 2002 L-481e_4...
Page 10 • simple jumper configuration allowing phyCORE Development Board LD 5V with various PHYTEC phyCORE SBC’s • one control LED D3 for quick testing of user software • 2 x 160-pin Molex connector (X2) enabling easy connectivity to expansion boards (e.g. PHYTEC GPIO Expansion Board) ©...
Page 11: The Tasking Xa Embedded Development Environment (Ede)
The LCXA locator generates an Intel hexfile that is suitable for programming into an EPROM device or downloading into on-chip Flash on the PHYTEC phyCORE-PXAG49 target board. The Tasking tool chain consists of the following executables: • C Compiler ccxa.exe...
Page 12 XA controllers. All common derivatives from Philips can be selected from a list in the EDE Processor Options menu. The Tasking XA compiler provides the fastest and smallest code using industry benchmarks. © PHYTEC Meßtechnik GmbH 2002 L-481e_4...
Page 13 This allows you to fully evaluate the features of Tasking products in conjunction with the PHYTEC Single Board Computer module. The full version has no restrictions and is fully ANSI compliant. © PHYTEC Meßtechnik GmbH 2002...
Page 15: Getting Started
• downloading example user code in Intel hexfile format from a host-PC to the on-chip Flash memory using FlashToolsOCF 2.1 Installing Rapid Development Kit Software • Insert the PHYTEC Spectrum CD into the CD-ROM drive of your host-PC The PHYTEC Spectrum CD should automatically launch a setup program that installs the software required for the Rapid Development Kit as specified by the user.
Page 16 If you decide to individually choose different paths and/or drives you must consider this for all further file and path statements. We recommend that you accept the default destination location. © PHYTEC Meßtechnik GmbH 2002 L-481e_4...
Page 17 All Kit-specific content will be installed to a Kit-specific subfolder of the Rapid Development Kit root folder that you have specified at the beginning of the installation process. © PHYTEC Meßtechnik GmbH 2002 L-481e_4...
Page 18 QuickStart Instructions All software and tools for this phyCORE-PXAG49 RDK will be installed to the \PHYBasic folder on your hard drive. • In the next dialog you must choose whether to copy the selected documentation as *.pdf files to your hard drive or to install a link to the file on the Spectrum CD.
Page 19 Tasking for XA demo tool chain. The default location is C:\Dcxa. If installing a different Software Development tool chain, please refer to the applicable version of the QuickStart manual. © PHYTEC Meßtechnik GmbH 2002 L-481e_4...
Page 20 Finish to exit this installation step. Additional software, such as Adobe Acrobat Reader, will also be offered for installation. In the following windows you can decide to install FlashToolsOCF software and the Acrobat Reader. © PHYTEC Meßtechnik GmbH 2002 L-481e_4...
Page 21 • Decide if you want to begin the QuickStart Instruction immediately by selecting the appropriate checkbox and press Finish to complete the installation. © PHYTEC Meßtechnik GmbH 2002 L-481e_4...
Page 22: Interfacing The Phycore-Pxag49 To A Host-Pc
QuickStart Instructions 2.2 Interfacing the phyCORE-PXAG49 to a Host-PC Connecting the phyCORE-PXAG49, mounted on the phyCORE Development Board LD 5V, to your computer is simple: • As shown in the figure below, if the phyCORE module is not already preinstalled, mount it pins-down onto the Development Board’s receptacle footprint (X6).
Page 23: Figure 2: Important Connectors, Buttons And Suitable Jumper Settings On The Phycore Development Board Ld 5V
Power Connector • Simultaneously press the Reset (S2) and Boot (S1) buttons on the phyCORE Development Board LD 5V, first releasing the Reset and then, two or three seconds later, release the Boot button. © PHYTEC Meßtechnik GmbH 2002 L-481e_4...
Page 24: Starting Phytec Flashtoolsocf For Windows
QuickStart Instructions This sequence of pressing and releasing the Reset (S2) and Boot (S1) button renders the phyCORE-PXAG49 into the Flash programming mode (FPM). Use of FlashToolsOCF always requires the phyCORE-PXAG49 to be in FPM. See section 2.4,“Downloading Example Code with FlashTools” for more details.
Page 25: Downloading Example Code With Flashtools
FlashToolsOCF from within Programs|Phytec program group. • The Communication Setup tab of the FlashTools for on-chip Flash tabsheet window will now appear. • Select the target hardware (PHILIPS-16BIT) and the controller type (XAG49). © PHYTEC Meßtechnik GmbH 2002 L-481e_4...
Page 26 QuickStart Instructions Note: Always ensure that the phyCORE-PXAG49 is in Flash programming mode before pressing the Connect button (refer to section 2.2). • Click on the Connect button. • At the Communication Setup window of the FlashToolsOFC tabsheet, choose the correct serial port for your host-PC and a 9,600 baud rate.
Page 27 Getting Started Returning to the FlashToolsOCF tabsheet window, you will see tabs for the following: Sector Utilities allows blank check and erasure of individual sectors of Flash memory: © PHYTEC Meßtechnik GmbH 2002 L-481e_4...
Page 28 QuickStart Instructions File Download downloads specified hexfiles to the target hardware: Flash Information shows Flash type, sector and address ranges in Flash memory: © PHYTEC Meßtechnik GmbH 2002 L-481e_4...
Page 29 Getting Started Communication Setup allows connection to and disconnection from the board (this is the same window that was used when you first entered FlashToolsOCF): Protected Areas Information shows protected areas of Flash memory: © PHYTEC Meßtechnik GmbH 2002 L-481e_4...
Page 30 Security Bit #2: inhibits Flash verification Security Bit #3: disables external memory The Restore Factory Defaults button erases all Flash sectors, resets the security bits and sets status and boot vector to default values. © PHYTEC Meßtechnik GmbH 2002 L-481e_4...
Page 31: Blinky
• Next choose the File Download tab and click on the File Open button. The hexfile has already been installed to your hard drive during the installation procedure. • Browse to the correct drive and path for the phyCORE-PXAG49 Demo folder (default location C:\PHYBasic\pC-PXAG49\Demos\Tasking\Blinky\Blinky.hex) and click Open.
Page 32 • Press the Reset button (S2) on the phyCORE Development Board LD 5V to reset the target hardware and to start execution of the downloaded software. • Successful execution of the program will flash the LED D3 with equal on and off durations. © PHYTEC Meßtechnik GmbH 2002 L-481e_4...
Page 33: Hello
• Next choose the File Download tab and click on the File Open button. The demo hexfile has already been installed to your hard drive during the installation procedure. © PHYTEC Meßtechnik GmbH 2002 L-481e_4...
Page 34 QuickStart Instructions • Browse to the correct drive and path for the phyCORE-PXAG49 Demo folder (default location C:\PHYBasic\pC-PXAG49\Demos\Tasking\Hello\Hello.hex) and click Open. • Click on the Download button. You can watch the status of the download of the Hello.hex into the on-chip Flash memory in the Download window.
Page 35 • Next click on OK. This creates a new HyperTerminal session named “COM Direct” and advances you to the next HyperTerminal window. The HyperTerminal window has a different appearance for different versions of Windows. © PHYTEC Meßtechnik GmbH 2002 L-481e_4...
Page 36 (COM1/COM2 Properties). • Set the following COM parameters: Bits per second = 9600; Data bits = 8; Parity = None; Stop Bits = 1; Flow Control = None. © PHYTEC Meßtechnik GmbH 2002 L-481e_4...
Page 37 COM parameters and the RS-232 connection. • Click the disconnect icon in HyperTerminal toolbar and exit HyperTerminal. You have now successfully downloaded and executed two pre-existing example programs in Intel *.hex file format. © PHYTEC Meßtechnik GmbH 2002 L-481e_4...
Page 39: Getting More Involved
2.1. You can also manually install the tool chain by executing setup.exe from within the \Software\Tasking\Dcxa folder of your PHYTEC Spectrum CD. Note: It is necessary to use the Tasking tool chain provided on the accompanying Spectrum CD in order to complete these QuickStart Instructions successfully.
Page 40 Other 3 party tools such as emulators can also be started from here. • You can close the Tip of the Day window. © PHYTEC Meßtechnik GmbH 2002 L-481e_4...
Page 41: Creating A New Project And Adding An Existing Source File
EDE XA, close it by selecting the Project menu and Project Space\Close the project. • To create a new project file select from the EDE XA menu Project|Project Space\New..© PHYTEC Meßtechnik GmbH 2002 L-481e_4...
Page 42 QuickStart Instructions • The following window will appear: • Click on the Browse button in the Create a New Project Space window. • This opens the New Project Space Filename window as shown below: © PHYTEC Meßtechnik GmbH 2002 L-481e_4...
Page 43 • In the text field ‘File name’, enter the file name of the project space you are creating. For this example, enter the name phyCORE-PXAG49 and click on Open. • Click on OK in the Create a New Project Space window.
Page 44 QuickStart Instructions • The Project Properties window will now appear: • Click on the Add a new Project icon. The Add New Project to Project Space window will now appear: © PHYTEC Meßtechnik GmbH 2002 L-481e_4...
Page 45 Space window, enter the file name of the project you are creating. For this example, enter the name Blinky2 and click on OK. • The Project Properties window will now look like this: • Click on the Scan existing files into project icon. © PHYTEC Meßtechnik GmbH 2002 L-481e_4...
Page 46 • Click on OK in the Scan Existing Files into Project window. • Click on the Scan existing files into project icon again. • In the pull-down menu Pattern, select Assembly Files as shown below: © PHYTEC Meßtechnik GmbH 2002 L-481e_4...
Page 47 Getting More Involved • The Scan Existing Files into Project window should now look like this: • The Project Properties window will now appear as follows: • Click on OK in the Project Properties window. © PHYTEC Meßtechnik GmbH 2002 L-481e_4...
Page 48 Blinky2 and added an existing C source file called Blinky2.c and an assembler file Start.src that contains specific startup code. The next step is to modify the C source before building your project.
Page 49: Modifying The Source Code
/* bit 1 of port PD = LED D3 = ON for (i=0; i< 30000 ; i++) /* delay for 30000 counts wait(); /* call wait function This will change the LED on/off ratio. © PHYTEC Meßtechnik GmbH 2002 L-481e_4...
Page 50: Saving The Modifications
• Click on the EDE pull-down menu and click on the line Expert Mode. You should see a check mark in front of the words Expert Mode the next time you click on the EDE pull-down menu. © PHYTEC Meßtechnik GmbH 2002 L-481e_4...
Page 51 To configure the CPU: • Open the EDE\Processor Selection menu from the EDE menu bar. • Choose the Philips XA-G49 in the CPU pull-down menu as shown below: • Click on OK to save this setting. © PHYTEC Meßtechnik GmbH 2002 L-481e_4...
Page 52 Separate external code and data bus (Harvard architecture) within the Memory tab. • Leave all other tabs within the CPU Options window at their default values. • Click on OK to save these settings. © PHYTEC Meßtechnik GmbH 2002 L-481e_4...
Page 53 • Select the option Large within the Memory Model Selection in the Memory Model tab. • Leave all other tabs within the XA C Compiler Options window at their default values. • Click on OK to save these settings. © PHYTEC Meßtechnik GmbH 2002 L-481e_4...
Page 54 (see the Philips PXAG49 Data Sheet for details on port configuration). • Leave all other tabs within the XA Assembler Options window at their default values. • Click on OK to save these settings. © PHYTEC Meßtechnik GmbH 2002 L-481e_4...
Page 55 Getting More Involved To configure the XA Linker/Locator: • Open the EDE\Linker/Locator Options menu from the EDE menu bar. • Activate the Intel HEX records for EPROM programmers checkbox in the Format tab. © PHYTEC Meßtechnik GmbH 2002 L-481e_4...
Page 56 • Enable the Memory tab and type in the address values in the External Code ROM area(s) and External Data RAM area(s) text fields as shown below: • Click on OK to save these settings. © PHYTEC Meßtechnik GmbH 2002 L-481e_4...
Page 57: Building The Project
Go to Windows\Command.com, right-click on the file and open the properties window. In the memory tab you must change the initial environment to 4096. © PHYTEC Meßtechnik GmbH 2002 L-481e_4...
Page 58: Downloading The Output File
• Next choose the File Download tab and click on the File Open button. • Browse to the correct drive and path for the phyCORE-PXAG49 Demo folder (default location C:\PHYBasic\pC-PXAG49\Demos\Tasking\Blinky2\Blinky2.hex and click Open.
Page 59: Hello2
• Start the Tasking EDE environment and close all projects that might be open. • Open the Project menu and create a new project space called phyCORE-PXAG49 and a new project called Hello2 within the existing project folder C:\PHYBasic\pC-PXAG49\Tasking\Demos\Hello2 (default location) on your hard-drive.
Page 60: Modifying The Example Source
• Double-click on the file Hello2.c from within the project window. • Use the editor to modify the printf command: printf ("\x1AHello World\n") printf ("\x1APHYTEC... Stick It In!\n") • Save the modified file under the same name Hello2.c. © PHYTEC Meßtechnik GmbH 2002 L-481e_4...
Page 61: Setting Tool Chain Options
Define user macros text field: This define allows the printf function to be used by direct executable applications for communication with a terminal program. Otherwise the functions for serial communication would need a simulator/debugger. © PHYTEC Meßtechnik GmbH 2002 L-481e_4...
Page 62: Building The New Project
(re-)build the project. If there are no errors, the code is assembled and linked and the executable code is ready to be downloaded to the board. © PHYTEC Meßtechnik GmbH 2002 L-481e_4...
Page 63: Downloading The Output File
• Next choose the File Download tab and click on the File Open button. • Browse to the correct drive and path for the phyCORE-PXAG49 Demo folder (default location C:\PHYBasic\pC-PXAG49\Demos\Tasking\Hello2\Hello2.hex and click Open.
Page 64: Starting The Terminal Emulation Program
• Resetting the phyCORE Development Board LD 5V (at S2) will execute the Hello2.hex file loaded into the Flash. • Successful execution will send the modified character string "PHYTEC... Stick It In!" to the HyperTerminal window. • Click the Disconnect icon . . • Close the Hyper Terminal program.
Page 65: Debugging
Debugging on the target hardware also enables testing peripheral components of the application. The following examples utilize the CrossView Pro Simulator debugger environment. © PHYTEC Meßtechnik GmbH 2002 L-481e_4...
Page 66: Creating A Debug Project And Preparing The Debugger
• Start the Tasking EDE for XA environment and close all projects that might be open. • Open the Project menu and create a new project space called phyCORE-PXAG49 and a new project called Debug within the existing project directory C:\PHYBasic\pC-PXAG49\Demos\Tasking\Debug (default location) on your hard drive.
Page 67: Setting Options For Target
4.2 Setting Options for Target To configure the CPU: • Open the EDE\Processor Selection menu from the EDE menu bar. • Choose the Philips XA-G49 in the CPU pull-down menu. • Click on OK to save this setting. © PHYTEC Meßtechnik GmbH 2002 L-481e_4...
Page 68 • Configure the CPU memory as shown below. Select the radio button External memory within the Memory tab. • Leave all other tabs within the CPU Options window at their default values. • Click on OK to save these settings. © PHYTEC Meßtechnik GmbH 2002 L-481e_4...
Page 69 • Select the option Large within the Memory Model Selection in the Memory Model tab. • Leave all other tabs within the XA C Compiler Options window at their default values. • Click on OK to save these settings. © PHYTEC Meßtechnik GmbH 2002 L-481e_4...
Page 70 (see the Philips PXAG49 Data Sheet for details on port configuration). • Leave all other tabs within the XA Assembler Options window at their default values. • Click on OK to save these settings. © PHYTEC Meßtechnik GmbH 2002 L-481e_4...
Page 71 Debugging To configure the XA Linker/Locator: • Open the EDE\Linker/Locator Options menu from the EDE menu bar. • Activate the IEEE-695 Tasking CrossView Pro Debugger (.abs) checkbox. © PHYTEC Meßtechnik GmbH 2002 L-481e_4...
Page 72 (re-)build the project. If there are no errors, the code is assembled and linked and the code can now be debugged using the CrossView Pro debug environment. © PHYTEC Meßtechnik GmbH 2002 L-481e_4...
Page 73: Preparing The Debugger
• Open the EDE\CrossViewPro_Options menu from the EDE menu bar. • In the Settings tabsheet, select the radio button Simulator. Leave all other options set to their default values. • Click on the OK button to save the settings. © PHYTEC Meßtechnik GmbH 2002 L-481e_4...
Page 74: Starting The Debugger
/or move some windows to make your screen look similar to the screen capture. You can open inactive windows by choosing the desired window from the View pull-down menu. © PHYTEC Meßtechnik GmbH 2002 L-481e_4...
Page 75: Tasking Crossview Pro Debug Features
The Run to cursor (same as F7) command executes the program to the current cursor position within the code window. This allows use of the cursor line as a temporary breakpoint. The Halt button interrupts and stops the running program at an undetermined location. © PHYTEC Meßtechnik GmbH 2002 L-481e_4...
Page 76 The Show selected source expression command displays the current value of a variable. The Watch selected source expression command is used to display the value of a variable with its immediate updates. © PHYTEC Meßtechnik GmbH 2002 L-481e_4...
Page 77: Using The Tasking Crossview Pro Debug Features
4.6.1 Single Stepping and Watch Window Run to cursor (F7) • Click in the source code line led(1); of the Debug program and choose Run to Cursor. Your program will be executed until it reaches this line. © PHYTEC Meßtechnik GmbH 2002 L-481e_4...
Page 78 Step (over function calls) • Click on the Step (over function calls) icon to execute the wait(rhythm[blink]); function without entering it. All subroutines are executed immediately and not displayed in the debug window. © PHYTEC Meßtechnik GmbH 2002 L-481e_4...
Page 79 • Click on the Watch selected source expression icon. The current value “Watch blink/n : 0“ is now displayed in the Data window. • Click in a different source code line in order to disable the selection of the variable "Blink". © PHYTEC Meßtechnik GmbH 2002 L-481e_4...
Page 80: Breakpoints
• Now click on the Continue execution icon. The program will run and stop at the breakpoint. © PHYTEC Meßtechnik GmbH 2002 L-481e_4...
Page 81 The value of this variable is updated in the "Watch blink/n : " line while the "Show blink/n : " line only indicates that the value has changed by adding the prefix OLD. No update of the variable value is shown in this line. © PHYTEC Meßtechnik GmbH 2002 L-481e_4...
Page 82: Exiting Crossview Pro
4.6.3 Exiting CrossView Pro • Open the File\Exit menu from the EDE tool bar to close the current CrossView Pro debug session. • Click on the Exit button in the Save Option menu to exit CrossView Pro. © PHYTEC Meßtechnik GmbH 2002 L-481e_4...
Page 83: Changing Target Settings For The "Final Version
After successfully debugging the program, next change the target settings in order to create an Intel hexfile. This can then be downloaded to the on-chip Flash memory of the phyCORE-PXAG49. • Open the EDE\Linker Options menu from the EDE menu bar.
Page 85: Advanced User Information
Additionally, re-programmable Flash memory phyCORE-PXAG49 allows you to easily update your own code and the target application in which the phyCORE-PXAG49 has been implemented. For more information on how to render the phyCORE-PXAG49 into Flash programming mode refer to the applicable section of the phyCORE-PXAG49 Hardware Manual.
Page 86: Start.src
But it needs to be added to the project files. Note: The entry “PXAG49” in EDE|XA Assembler Options\Preprocessing configures controller ports P1, P2 as well as P3.6 and P3.7 as push- pull (see the Philips PXAG49 Data Sheet for details on port configuration). © PHYTEC Meßtechnik GmbH 2002 L-481e_4...
Page 87: Linking And Locating
In addition, the linker must locate several segments of code and data to fixed address locations within the address space in regards to the memory types of the phyCORE-PXAG49. XDAT segments always must be located to Random Access Memory (e.g. RAM), CODE segments should be located to non-volatile memory (e.g.
Page 88 For instance all XDAT segments should end below 0x3FFFF if a 256 kByte RAM device mounted on the phyCORE-PXAG49. We recommend generation of a *.map file for your project and inspection of the memory map information within this file.
