DEMO MANUAL EVAL-LT8356-1-AZ
PARTS LIST
ITEM QTY REFERENCE
34 0 C2
35 0 C4
36 0 C10, C17
37 0 CL1-CL6
38 0 SH1
Optional Electrical Components
39 0 C1, C23-C25
40 0 C4, C14, C20-C22
41 0 C15
42 0 D2, D3
43 0 R3, R11, R13, R14, R18,
R21, R23, R24, R26
44 0 R9
Hardware: For Demo Board Only
45 7 E1-E7
46 4 E8-E11
47 2 J1, J2
48 4 MH1-MH4
10
PART DESCRIPTION
CAP ., OPTION, 1206
CAP ., OPTION, 1210
CAP ., OPTION, 0603
OPTION, WE-SHC CABINET CLIP 6.5mm × 0.8mm × 1.27mm
OPTION, WE-SHC CABINET SHIELD 44.37mm × 44.37mm
CAP ., OPTION, 0402
CAP ., OPTION, 1210
CAP ., OPTION, ALUM. ELECT., SMD
DIODE, OPTION, SOD-323F
RES., OPTION, 0402
RES., OPTION, 0603
TEST POINT, TURRET, 0.094" MTG. HOLE, PCB 0.062" THK
TEST POINT, TURRET, 0.064" MTG. HOLE, PCB 0.062" THK
CONN., BANANA JACK, FEMALE, THT, NON-INSULATED,
SWAGE, 0.218
STANDOFF , NYLON, SNAP-ON, 0.50"
MANUFACTURER/PART NUMBER
WURTH, 369 000 00
WURTH, 369 074 06S
MILL-MAX, 2501-2-00-80-00-00-07-0
MILL-MAX, 2308-2-00-80-00-00-07-0
KEYSTONE, 575-4
KEYSTONE, 8833
Rev. A
