AURIX DAP 10-pin 1.27mm Galvanic Isolation Adapter

Galvanic isolation is used where two electric circuits must communicate, but their grounds
may be at different potentials. It is an effective method of breaking ground loops between the
two circuits. Galvanic isolation is also used for safety, preventing accidental current from
reaching ground through a person's body.
iSYSTEM Galvanic Isolation Adapters provide a basic isolation that withstands high voltages.
To prevent injury to personnel when dealing with potentially hazardous voltages it is
mandatory to have a second protection measure in place, in case the first insulation barrier
fails. This is termed double or, reinforced isolation. How should a double isolation be
implemented depends on the use-case or application setup.
It is your responsibility to check the local safety directives applicable to your company
and country to ensure that all requirements are met.
AURIX DAP 10-pin 1.27 mm Galvanic Isolation Adapter is used to electrically isolate:
·
iSYSTEM iC5700 BlueBox in conjunction with:
10-pin 1.27 mm Infineon DAP2 Wide Debug Adapter
o
o Infineon DAP/DAPE Active Probe (Ordering code IC57163) or
o Infineon AGBT Active Probe (Ordering code IC57164) + 10-pin 1.27 mm DAP Adapter
(Ordering code IASAM22TRICOREPIN10-1)
from the embedded target.
The adapter is supported only in winIDEA version 9.21.29 or higher. It is not supported
by iSYSTEM iC5000 BlueBox.
Find more information on
for technical support, please visit www.isystem.com/support.
www.isystem.com or contact sales@isystem.com. To reach
(Ordering code IC50163-2) or
