MOV instruction (Please refer to allocation of special registers D9900 ~ D9999). EN DVP06XA-E2 is an OPEN-TYPE device. It should be installed in a control cabinet free of airborne dust, humidity, electric shock and vibration. To prevent...
Attrib. Register name Explanation Set up by the system: Model name DVP06XA-E2 model code = H’00C4 Firmware version Display the current firmware version in hex. Input mode: Default = H’0000. Take CH1 for O R/W CH1 Input mode setting example: Mode 0 (H’0000):Voltage input (±10V)
Page 6
Attrib. Register name Explanation Note 1: When using Mode 6 for input or Mode 2 for output, the channel do NOT provide setups for adjusted Offset or Gain value. Note 2: When input mode changes, the adjusted Offset or Gain value returns to defaults. Prohibit set value changing in CH1 ~ CH4 #40 O R/W Set value changing prohibited Default= H’0000.
Page 7
When DVP-ES2 MPU is connected with modules, registers D9900~D9999 will be reserved for storing values from modules. You can apply MOV instruction to operate values in D9900~D9999. When DVP-ES2 MPU is connected with DVP06XA-E2, the configuration of special registers is as below: Module...
Page 8
Mode 2: Mode 3: +32384 +32384 +32000 +32000 Digital Digital output output +16000 +16000 Gain Gain 2.5V -384 -384 Offset Offset Voltage input Voltage input Mode 2 of CR#2 ~ CR#5 0 ~ +10V, Gain = 5V (16,000), Offset = 0V (0) Mode 3 of CR#2 ~ CR#5 0 ~ +5V, Gain = 2.5V (16,000), Offset = 0V (0) Range of digital conversion (Max./Min.)
Page 9
Equation for current output Mode1: 0.625μA = 20mA/32,000 Gain Offset Offset 16000 32000 Y=Current output, X=Digital input Equation for current output Mode2: 0.5μA = 16mA/32,000 Adopt the equation of current output Mode 1, substitute Gain for 19,200(12mA) and Offset for 6,400(4mA) ...
