Page 1: Operating Instructions
Touchpad Operating Instructions ekey home OpErAtInG InStructIOnS www.rkdoorsystems.co.uk... -
Page 2: Table Of Contents
Table of contents General Implementation Note Implementing devices and establishing normal mode Product liability and limitation of liability Entering the admin code Warranty and manufacturer’s warranty Changing the admin code 9 - 10 Notices, symbols and abbreviations Setting the automatic back-illumination Safety information Setting the brightness of the Life-threatening danger resulting... -
Page 3: General
These operating instructions are not subject to updating. Subject to optical and technical modifications, any liability for errors and misprints is excluded. Warranty and Our general terms and conditions apply as valid at the date of purchase. See www.ekey.net. manufacturer’s ekey biometric systems GmbH provides a 24-month warranty for material or processing warranty defects. -
Page 4: Safety Information
Symbols: Step-by-step instructions Reference to sections of this manual Reference to the mounting instructions Reference to the wiring diagram □ Listing without specified order, 1st level ekey home FS OM Product names Buttons Button Abbreviations: Control panel Safety information Safety information... -
Page 5: Product Description
Product description Product description System overview Fig. 1: Overview of the system 1 Code pad 2 Power supply 3 Control panel 4 Distributor 5 Motorised lock 6 Cable transfer 7 Connecting cable Scope of □ Code pad; delivery □ Control panel; □... - Page 6 If the code is entered incorrectly 3 times, there will be a 1-minute lock. If the code is then entered incorrectly a further 3 times, there will be a 15- minute lock. There will be a 15-minute lock each time the code is entered incorrectly after that.
-
Page 7: Control Panels
Press and hold button for 1 sec. Coupling control panel/code pad. Press and hold button for 4 secs. Reset to default settings. Table 4: Button functions of the ekey home CP mini 1 Technical specifications Description Unit Value Page 6... -
Page 8: Technical Specifications
Press and hold button for 1 sec. Coupling control panel/code pad. Press and hold button for 4 secs. Reset to default settings. Table 4: Button functions of the ekey home CP mini 1 Technical specifications Technical specifications Description Unit Value... -
Page 9: Installation
Cable the system in accordance with the supplied wiring diagram. Step Action Display Ensure safe installation of the devices. Close the covers. Connect the power supply to the Only for ekey home CP mains. mini 1 : The upper status LED on the control panel flashes red: Default setting. -
Page 10: Changing The Admin Code
See Changing the admin code, page 9. The system is in normal mode. Step Action Description Display Press to start the The status LED lights up yellow process of entering on the left. the admin code. Enter the admin code on the keypad. - Page 11 Step Action Description Display Press . The status LEDs light up yellow. The status LEDs light up red. The old admin code was not recognised. Enter the admin code from the beginning again. Enter the new admin code on the keypad. Press .
-
Page 12: Setting The Automatic Back-Illumination
The brightness threshold for switching on the automatic back-illumination Setting the automatic can be set using percentage values. By default, the brightness threshold back- is set to 10%. Enter the required percentage value: illumination □ = automatic back-illumination off; □ = brightness threshold settings between highly sensitive and highly insensitive. -
Page 13: Setting The Relay Switching Time
The system is in the admin menu. Step Action Description Display The status LED Press 5, and the lights up green number of the on the left. required mode. Press . The status LEDs light up green. The status LEDs light up red. -
Page 14: Setting The Signalling That Indicates When A Button Has Been Pressed
Step Action Description Display Something has been entered incorrectly. The relay switching time was not changed. Enter the admin code from the beginning again. No action Status LEDs are required. off. The relay switching time was set. The system is in normal mode. 4 predefined modes can be used to set the acoustic and optical signalling Setting the that indicates when a button has been pressed. -
Page 15: Setting An Acoustic Signal For Opening
The optical and acoustic signalling to indicate that a button has been pressed has been set. The system is in normal mode. Setting an The acoustic signal for opening can be switched off and on. By default, the acoustic signal acoustic signal is switched on. -
Page 16: Use
Step Action Description Display The status LED Press 1. lights up green on the left. Press . The status LEDs light up green. Enter the required The status LED lights up green user code on the on the right. keypad. The status LEDs light up red. -
Page 17: Deleting The User Code
There will be another 15-minute lock each time the code is entered incorrectly after that. NOTICE You can also open the door using the digital input (PIN 7, 8) on the ekey home CP mini 1 Deleting the You can delete individual user codes for a user. To do this, you require the user code user code to be deleted. -
Page 18: Resetting The System To Default Settings
Step Action Description Display Enter the user code to be deleted on the keypad. Press . The status LEDs light up green. The status LEDs light up red. The user code is not known. The user code was not deleted. Enter the admin code from the beginning again. -
Page 19: Updating The Software
The code pad has been reset to its default settings. The system is in normal mode. Via the control panel Resetting to the default settings is only possible with the ekey home CP mini 1 and is initiated via the control panel. This can only be undertaken... -
Page 20: Error Displays And Troubleshooting
If these suggestions fail to solve the problem, the system must be returned to ekey biometric systems GmbH to be checked. Please ship the equipment in suitable packaging. Improper packaging can lead to the warranty being voided. -
Page 21: Dismantling And Disposal
Any transmission, party requires the prior written consent of ekey biometric systems GmbH. relinquishment or transfer of this content or parts thereof to any third Translated documentation.
