table of Contents Safety Precautions..........................2 A. Product information........................4 (1) Model parameter........................4 (2) Packing List..........................5 (3) Nozzle module exploded view....................6 (4) Machine assembly......................... 7 B． Machine operation........................13 （1）Machine control interface description................13 （2）Home interface........................18 （3）Move interface........................ 18 （4）Tune interface........................20 （5）Utilities interface......................21 C. -
Page 3: Safety Precautions
Safety Precautions 1) The temperature of the nozzle parts can reach 250 °C during the operation of the machine. To ensure your safety, it is forbidden to touch the model and nozzle directly with your hand while the printer is printing or cooling. - Page 4 The front end of the consumable should be fixed on the tray to avoid consumables and affect the next print. To use this printer, it is recommended to use the supplies provided by the company. At present, the quality of consumables sold in the retail market is uneven, and printing is prone to breakage.
-
Page 5: Product Information
A.Product information (1) Model parameter model LK5 Pro Machine size 580*540*663 MM frame Classic aluminum Machine weight 11KG frame Molding FDM (hot melt Package 622*588*193mm production) dimensions Number of nozzles Consumable color Multi-color optional Molding size 300*300*400mm Output 24V Power requirement Layer thickness 0.1-0.4mm operating system... -
Page 6: Packing List
(2) Packing List www.longer3d.com info@longer3d.com... -
Page 7: Nozzle Module Exploded View
(3) Nozzle module exploded view 4010 fan Air guide Quick pneumatic joint 3010 fan Sheet metal protective case Heat sink Heating block nozzle Thermistor Heater www.longer3d.com info@longer3d.com... -
Page 8: Machine Assembly
(4) Machine assembly www.longer3d.com info@longer3d.com... - Page 9 www.longer3d.com info@longer3d.com...
- Page 10 www.longer3d.com info@longer3d.com...
- Page 11 www.longer3d.com info@longer3d.com...
- Page 12 www.longer3d.com info@longer3d.com...
- Page 13 www.longer3d.com info@longer3d.com...
-
Page 14: B． Machine Operation
B． Machine operation （1）Machine control interface description Primary Secondary Explain interface interface Nozzle temp Display nozzle temperature Heatbed temp Display the temperature of the hot bed File The name of the file Time Print time HOME Progress Print process Height Print height Pause time out... - Page 15 size Increase\lower Fan speed control stop fan The fan stops rotating Fan speed Step speed of the fan step speed Print speed Increase\lower magnification Feed rate Restore Restore default (100%) step Print speed step size Increase\lower Nozzle flow control Nozzle flow rate Restore Restore default (100%) step...
-
Page 16: 2）Home Interface
（2）Home interface Print file parameter information Pause Cancel （3）Move interface Distance adjustment XY zero XY mobile interface Motor Z zero unlocked\locked mobile interface E-axis feed and discharge www.longer3d.com 18 18 info@longer3d.com... -
Page 17: 4）Tune Interface
（4）Tune interface Nozzle temperature Feed rate override temperature Fan speed Nozzle flow rate www.longer3d.com info@longer3d.com... -
Page 18: 5）Utilities Interface
（5）Utilities interface Consumable setting control Automatic leveling control Temperature parameter Nozzle temperature return to zero Consumable heating option temperature return to zero Feed Nozzle temperature adjustment Return material www.longer3d.com info@longer3d.com... -
Page 19: 6）Print Interface
Five-point leveling page Click the five points in turn to move the nozzle and then perform leveling operation. （6）Print interface File selection and display scroll www.longer3d.com info@longer3d.com... -
Page 20: Software Installation
C. Installation and use of Changlang 3D slicing software (1) Software installation Double-click the LONGER 3D Slicer 1.3 to enter the installation guide page Click to enter the next step, select the default C drive for installation, otherwise the software will not... -
Page 21: Model Selection
(2) Model selection Open the software and choose the language you want According to the model of the machine purchased, select the corresponding model. Incorrect selection will cause the machine parameters to be incorrect and the printer will not work properly. If it is a machine of another brand, you can also choose other models for related settings or use it. -
Page 22: Software Usage Introduction
(3) Software usage introduction 3D printer supports gcode format files, so you need to import the STL format model into Changlang 3D slicing software for slicing operation. To print a fine model, you need to have a deep understanding of the slicing software that controls the print path. -
Page 23: Export Gcode Format For Printing
Nozzle aperture: 0.4mm. Retraction speed: the speed of retraction when printing the model. Retracted length: The length of the material withdrawn, generally 4.5 ~ 8mm. Initial layer thickness: Print the thickness of the first layer, which is the default. Initial layer line width: 100% will be thicker and denser, just default. Bottom Cut: The length of the bottom cut of the model. -
Page 24: Instructions For Printing Online
D. Instructions for printing online Changlang 3D printers support online printing operations, but because the computer sends instructions continuously for a long time, there are many different settings on the personal computer (some computers will set the energy-saving mode or the screen mode, etc.) and the computer will freeze if it runs. -
Page 25: Online Printing
Open the Changlang 3D slicing software. The first step is to turn on the model. The second step is to open the model settings. The third step is to select the serial port number displayed by each computer. Generally, the larger serial port is selected. Normally select "AUTO" for the special rate. -
Page 26: Professional Settings
(4) Professional settings If you want to print a more professional page online, you can set it by the following steps. Select file in the first step, select parameter settings in the second step, and change the print window settings in the third step to professional. Then start printing the page online and it will become a professional page, you can send G codes, you can control the movement of each axis. -
Page 27: E． Resume Printing And Filament Run-Out Detection Function
E ． Resume printing and filament run-out detection function （1）Power failure When printing, the power is suddenly turned off. If the height of the printed model exceeds 0.1mm, the icon will be displayed when the power is turned on. Only the icon will be displayed once. -
Page 28: 2）Broken Material Detection
（2）Broken material detection At this point, pull the Teflon tube out of the extruder end, take out the material, refill the consumables to the nozzle, click YES, after replacing the material, click Utilities, and finally click Print to start, the model will print. www.longer3d.com info@longer3d.com... -
Page 29: Guide To Common Problems In Machine Use
F. Guide to common problems in machine Question 1: How to update the firmware? Sometimes individual DIY users want to add some special functions to their 3D printers, or there are unknown bugs in the original firmware, then the firmware needs to be updated, and each machine will be sent to the user after strict and detailed factory inspection and burn-in. -
Page 30: Question 2:What If The Filament Does Not Discharge From The Machine
First connect the serial cable to the 3D printer, the first step is the model, the second step is the model setting, the third step is to select the port, the fourth step is to confirm whether the baud rate is AUTO, and the fifth step is to choose to burn the specified firmware (will be The file selection box pops up, then select the firmware corresponding to the .hex format) Question 2:What if the filament does not discharge from the... -
Page 31: Question 3
Question 3: When the machine returns the filament, it can't be returned. What should I do when stuck in the pneumatic joint? 1. Before returning the material, please heat the nozzle first, and then withdraw the consumables as soon as possible. If you can't pump it, you can re-feed the material with the advanced material, and melt the extruded block formed at... -
Page 32: Question 5
Question 4: What should I do if I cannot resume printing after power shutdown? If the power is suddenly turned off when the part is first printed, the machine will not save the print data. Unless the height of the print exceeds 0.5mm, the power failure will be supported. - Page 33 Question 6: After the machine heats up, the filament is discharged normally. However, when the printing is performed for the first time, the curling occurs on the platform. After printing several layers, the filaments get 1. After the user gets the 3D printer, if the leveling is found to be curled on the first layer of silk, it feels like it is gently falling on the platform.
