About KD-X611ProK
KD-X411ProK/KD-X411POHK HDBaseT/HDMI (Tx & Rx) Extenders are an HDCP
2.2 compliant product that extend 4K/UHD 24/25/30 (4:4:4) and 4K/UHD 60 (4:2:0)
signals up to 300 ft. using Key Digital
®
or up to 250 ft. using a single third-party CAT5e/6 cable. 1080p/60, 1920x1200, 3D
signals are extended up to 600 ft. with Long Range Mode via single Key Digital
CAT6STP1X Super CAT6A shielded cable, or up to 500 ft. using a single third-party
CAT5e/6 cable. In addition to HDMI video and audio signals, KD-X611ProK carries
Ethernet, IR and RS-232 for controlling remotely located equipment or the RS-232 port
can be used to control the KD-X611ProK. Ethernet ports allow 10/100 LAN Network
extension. Audio de-embed ports on the Tx unit enable external audio connectivity
with audio distribution systems and amplifiers.
Key Features
HDBaseT via Single CAT5e/6 UTP/STP Extension: With fully automatic
➔
adjustment of feedback, equalization, and amplification depending on
cabling length
Signal Extension:
➔
» Standard Mode (HDBaseT Class A). Supports resolutions up to 4K/UHD.
» Up to 350 ft. @ 4K/24/25/30/60 using KD-CAT6STP1X cabling
» Up to 230 ft. @ 4K/24/25/30/60 using third-party CAT5e/6
UTP/STP cabling
» Up to 400 ft. @ 1080p / 1920x1200 using KD-CAT6STP1X cabling
» Up to 330 ft. @ 1080p / 1920x1200 using third-party CAT5e/6
UTP/STP cabling
» Long Range Mode (4K resolutions not supported):
» Up to 600 ft. @ 1080p / 1920x1200 using KD-CAT6STP1X cabling
» Up to 500 ft. @ 1080p / 1920x1200 using third-party CAT5e/6
UTP/STP cabling
4K/Ultra HD Resolution: Support for 4096x2160 or 3840x2160 24/25/30Hz at
➔
4:4:4/8 Bit or 60Hz at 4:2:0/8 Bit
KD-CAT6STP1X Super CAT6A Shielded cable,
1
