Rover (VIPS-R-V2) Installation
• The VIPS Rover looks similar to the Beacon, however the rover contains an internal IMU and so care should be
taken to ensure that the Rover is mounted to an area that has the least vibration. If being installed on a vehicle, this
is usually towards the rear, just in front of the rear windshield.
• The rover should be mounted in a way such that it has a clear view to the beacons and away from any objects that
may block that view (roof bars, radio antennas, etc).
• Make sure there is no metal close to the receiver, even a metal clamp close to the bottom of the receiver, or a
monitor in the line of sight to beacons can cause significant issues.
https://en.racelogic.support//VBOX_Indoor_Positioning_System_(VIPS)/VIPS_User_Guide/02_-_VIPS_Hardware_Installation
Base to base
Side to base
Side by side with large height
difference, tops away from each
other
