Environmental And Physical - Racelogic VIPS User Manual

Beacon
Unit Power
Input voltage range
Power consumption
Rover IMU Specifications
Dynamic range
Nonlinearity
Resolution
Bandwidth
Noise density
Bias stability
Bias repeatability (1 year)

Environmental and Physical

IP rating
Operating temperature
Storage temperature
Size (of each beacon/rover)
Weight (of each beacon/rover)
https://en.racelogic.support//VBOX_Indoor_Positioning_System_(VIPS)/VIPS_User_Guide/06_-_VIPS_Technical_Properties/VIPS_-
6.5 – 30 V DC
2 W
Gyroscopes (Angular rate
sensors)
±450°/s
0.01 % of full scale
16-bit ADC (0.014°/s)
50 Hz
0.01°/s/√Hz
0.003°/s
0.2°/s
IP 67
-30°C to +60°C
-40°C to +85°C
124 x 124 x 74.5 mm (l x w x h)
350 g
Accelerometers
± 20 g
0.1 % of full scale
16-bit ADC (0.15 mg)
50 Hz
60 µg/√Hz
15 µg
0.005 g
_Technical_Specification
