- Page 1 Operations Manual Model: CS157PHNA 15”x 7” Clamshell Grill formerly DOUGHPRO. New Name. Same Quality. Superior Service. proluxe.com...
-
Page 2: Cleaning Instructions
Operation Instructions Please read carefully before attempting to use this appliance. Step 1. Carefully unpack and clean grill plates with mild soap then sponge clean with cold water. Step. 2. Place in location where it will be used allowing for clearances per the dimensions indicated. -
Page 3: Clean Cycle
Clean Cycle 275°F is the factory default temp for the CLEAN cycle. To change the CLEAN cycle temp, simultaneously hold down the TEMP and CLEAN buttons for 15 seconds. Using the up or down arrows to adjust to the desired temp. To start a clean cycle, push CLEAN button once so the CLEAN LED light is turned on. - Page 4 CS157 Operating Instructions: 1. Press desired time to start the time cycle. After the cycle is finished, press it again to reset the time cycle 2. If for any reason the timer has to be reset in the middle of a cycle, you must press and hold the corresponding timer button for 3 seconds.
- Page 5 Instruction’s for Adjusting the Temperature PRESS and hold the TEMP and ARROW up buttons simultaneously for 15 seconds. Using the ARROW buttons, you may now adjust the temperature to your desired setting. Once you have set your desired temperature simply push the TEMP button.
- Page 6 DOUGHPRO CS157 Clamshell Grill Trouble Shooting Guide Symptom Probable Cause Action to be Taken Parts List Ref. # Power Button on Control face is Power Cord is not plugged in. Plug power cord into wall 's depressed but doesn’t turn on. receptacle and depress power button on controller Circuit Breaker is tripped off in the...
- Page 7 DOUGHPRO CS157 Clamshell Grill Trouble Shooting Guide Symptom Probable Cause Action to be Taken Parts List Ref. # Either Heater Platen is not Heating If the Mechanical Relay (s) on the coil Replace Mechanical Relay. # 15 but the Digital Controller is on and side are receiving 12vdc indicates the appears to be functioning.
- Page 8 MODEL CS157PHN EXPCS157PHN RA 1000 060414 SHEET 1 OF 3...
- Page 9 MODEL CS157PHN EXPCS157PHN RA 1000 060414 SHEET 2 OF 3...
- Page 10 MODEL CS157PHN EXPCS157PHN RA 1000 060414 SHEET 3 OF 3...
- Page 11 PART LIST FOR THE CS157PHN MODEL ITEM # QTY. DESCRIPTION CS157PHNA 120V LOWER WRAP AROUND SHROUD ASSEMBLY 110103901 SPRING, DETENT1/2 LONG 110115555 FUSE HOLDER MPPF708 FUSE BUSS 1 AMP MPPF701R TRANSFORMER 11096975 0969 TERMINAL BLOCK #6 6016 STRAIN FELIEF 11016546468 CORD, POWER 120V 110969174 TUBBING-PAD 110115531...
- Page 12 PART LIST FOR THE CS157PHN MODEL ITEM # QTY. DESCRIPTION CS157PHNA 120V DIGITAL CONTROL 1101029052 PLUNGER ASSEMBLY 110115544 UPPER LEVELING BRACKET 110115510 UPPER LEVELING SHIM 110115557 HANDLE, SPRING ADJUSTING COLLAR G CO 110115528 COLLAR, HOLDER 110115530 BACK COVER 110103907 COUNTER BALANCE SPRING 1101039154 RIGHT SHROUD ASSY 11016546457 RTD SENSOR...
-
Page 14: What Is Covered
PLEASE READ CAREFULLY BEFORE ATTEMPTING TO USE THIS APPLIANCE. LIMITED MACHINE WARRANTY WHAT IS COVERED Doughpro warrants the CS157, from manufacturing defects in workmanship and material sold within the domestic United States. HOW LONG DOES THE COVERAGE LAST One year warranty for parts and labor. The heating elements on the upper and lower platens have a limited lifetime warranty on the elements. -
Page 15: Warranty And Return Policy
Exclusions: 1. WOOD / GAS FIRED OVENS: PROLUXE warranty applies to the main body of the oven being steel / refractory and insulation shall be free from defects in materials and workmanship for a period of four years from the date of purchase. The gas equipment shall be free from defects in materials and workmanship for a period of one (1) year from the date of purchase.
