Summary of Contents for Proluxe Progrill TW1520
- Page 1 Operations Manual Model: TW1520/TW2025 Tortilla Warming Flat Grills formerly DOUGHPRO. New Name. Same Quality. Superior Service. proluxe.com...
-
Page 2: Electrical Data
Operation Instructions Step 1 Step 2 Carefully unpack and clean grill plates with Place in location where it will be used allowing mild soap then sponge clean with cold water. for clearances per the dimensions indicated. WARNING ALLOW 2” MINIMUM CLEARANCE between adjacent equipment and/or wall areas. -
Page 3: Initial Start-Up
CLEANING Use only cleaners which are safe for ALUMINUM. DO NOT use caustic cleaners, ice or cold water to clean the grill. Turn grill down or OFF during idle periods to prevent carbon buildup. 1. Turn power off and unplug, allow grill to cool. 2. - Page 6 TW2025E 12 4X 14 4X EXPTW2025E NC 102318 CUSTOMER MANUAL...
- Page 7 PARTS LIST FOR TW1520 TORTILLA WARMER TW1520A TW1520B REF # DESCRIPTION 120 ~ AC 240 ~ AC QTY. HEATED PLATEN WITH WIRING ASSY 110843074 110843075 SCREW, PAN HEAD PHILLIPS 6-32 X 1/4 SP63214 SP63214 SCREW, SET 3/8-16 X 1.0 SST38161 SST38161 SCREW, SET3/8-16 X 1/2 SST381612...
- Page 8 PARTS LIST FOR TW2025B TORTILLA WARMER TW2025B REF # DESCRIPTION 240 ~ AC HEAT PLATEN 20 X 25 11082231240 SCREW, PAN HEAD PHILLIPS 6-32 X 1/4 SP63214 SET SCREW SET CUP POINT 3/8-16 x 1.0 SST38161 WASHER, SAE #6 WSAE6 SPACER, LEG 11082249 BOTTOM SHROUD...
- Page 9 PARTS LIST FOR MODEL TW2025E ITEM DESCRIPTION PART NUMBER QTY. SHROUD, TW2025E 110108641 INSULATION, FIBERGLASS 15 X 20 MPSP254 SCREW, PAN HEAD PHILLIPS 10-24 X 1/4 STAINLESS STEEL SP102414S BURN GUARD ASSEMBLY, TW2025E 110108610 LEG, APPLIANCE 4" AE601653 HOUSING, TW1520/TW2025/TW2540 11082322 MARKER STRIP #3, DOUBLE MS6013 TERMINAL BLOCK #3, DOUBLE 6013...
- Page 10 VAC: 120 / 230 AMPS: 14.17 / NA WATTS: 1700 / NA TW1520 WIRE DIAGRAM...
- Page 12 VAC: 240 AMPS: 13.75 WATTS: 3300 TW2025B WIRE DIAGRAM...
- Page 13 The heating elements on the upper and lower platen only; will be replaced by next day air service; under the normal one year warranty. Such repair or replacement will be at the expense of Proluxe on under the normal one year warranty.
-
Page 14: Warranty And Return Policy
Exclusions: 1. WOOD / GAS FIRED OVENS: PROLUXE warranty applies to the main body of the oven being steel / refractory and insulation shall be free from defects in materials and workmanship for a period of four years from the date of purchase. The gas equipment shall be free from defects in materials and workmanship for a period of one (1) year from the date of purchase.
