1 Introduction

PCOM-B657VGL is COM Express module based on Intel® 11th Gen H Processor. It is compatible with COMe 3.0/3.1 standard. The
platform adopts 10nm++ process and VNNI instruction set, offers advance computing power with 25~45W theraml and industrial use
condition for wide range applications. PCOM-B657VGL supports PCIe Gen 4.0 x16, and both ECC and Non-ECC DDR4 by different
SKUs, which is best for mission critical use conditions and AI edge computing with TSN enabled.
This module provides 8x PCIe x1 (Option to 2x PCIe x4 and support PCIe storage), four USB 3.2 Gen2 x1, and four SATA III. The
fully integrated and flexible I/O capacity also mapped to wide range of industrial applications.
©
