COM Express™
Feature
SATA Controller(s)
Enable VMD controller(RAID mode)
Enable VMD controller(RAID mode) [Enabled]
Map this Root Port under VMD
COMe SATA Port #0~3
Port 0~3
Hot Plug
SATA Device Type
©
Copyright PORTWELL 2021
PORTWELL PCOM-B657VGL User's Guide
Description
Enable/Disable the SATA Device.
Enable/Disable to VMD controller.
Map/UnMap this Root Port to VMD.
Enable or Disable SATA Port
Designates this port as Hot Pluggable
Identify the SATA port is connected to Solid
State Drive or Hard Disk Drive
PCOM-B657VGL User's Guide
Options
★Enabled , Disabled
★Disabled, Enabled
★Disabled, Enabled
★Enabled ,Disabled
★Disabled, Enabled
★Hard Disk Drive, Solid State Drive
