COM Express™
Feature
Intel LAN I255 Controller
PCIE_WAKE(Wake On Lan)
Launch UEFI PXE ROM
Launch UEFI PXE ROM
[Enable]
Ipv4 PXE Support
Ipv4 HTTP Support
Ipv6 PXE Support
Ipv6 HTTP Support
PXE boot wait time
Media detect count
©
Copyright PORTWELL 2021
Description
Control the PCI Express Root Port.
Control PCIE Wake# pin for Wake On Lan function.
Enable/Disable UEFI Network Stack.
Enable/Disable Ipv4 PXE boot support. If disabled, IPv4 PXE boot support
will not be available.
Enable/Disable Ipv4 HTTP boot support. If disable, IPv4 HTTP boot
support will not be available.
Enable/Disable Ipv6 PXE boot support. If disable, IPv6 PXE boot support
will not be available.
Enable/Disable Ipv6 HTTP boot support. If disable, IPv6 HTTP boot
support will not be available.
Wait time in seconds to press ESC key to abort the PXE boot. Use either
+/- or numeric keys to set the value.
Number of times the presence of media will be checked. Use either +/- or
numeric keys to set the value.
PCOM-B657VGL User's Guide
PORTWELL PCOM-B657VGL User's Guide
Options
★Enabled , Disabled
★Enabled , Disabled
★Disabled, Enabled
★Enabled , Disabled
★Enabled , Disabled
★Enabled , Disabled
★Enabled , Disabled
★0
★1
