COM Express™

3.3 Electrical Characteristics

Input voltage
RTC Battery
Power on mode
©
Copyright PORTWELL 2021
PORTWELL PCOM-B657VGL User's Guide
+12V ± 5%
From Carrier
ATX Mode & AT Mode

Table 5 Electrical characteristics

Figure 2 PCOM-B657VGL Power on sequence

PCOM-B657VGL User's Guide 17
