Specifications - Portwell PCOM-B657VGL User Manual

COM Express™

3 Specifications

Product
Form Factor
Processor
BIOS
Memory
Graphic
Ethernet
Audio
PCI Express
I/O
©
Copyright PORTWELL 2021
➢
PCOM-B657VGL
➢
®
COM Express Type 6, Basic Size (125 X 95mm)
➢ Intel Core i7-11850HE
® TM
➢ Intel Core i5-11500HE
® TM
➢ Intel Core i3- 11100HE
® TM
➢ Intel Celeron 6600HE
® ®
Intel Xeon W-11865MRE
➢
® ®
➢ Intel Xeon W-11555MRE
® ®
➢ Intel Xeon W-11155MRE
® ®
➢ Intel Xeon W-11865MLE
® ®
➢ Intel Xeon W-11555MLE
® ®
➢ Intel Xeon W-11155MLE
® ®
➢
AMI BIOS
➢ 2x SO-DIMM DDR4
➢ Support ECC (selected SKU)
➢ Up to 64GB 3200MHz
➢ Intel UHD Graphics for 11th Gen Intel
®
➢ 1x 2.5 GbE (via Intel ® i225LM/IT)
➢ HDA
➢ PEG (PCIe 4.0 x16)
➢ 8x PCIe 3.0
➢ 4x USB 3.2 Gen2 / 2.0
4x USB 2.0
➢
PCOM-B657VGL User's Guide
PORTWELL PCOM-B657VGL User's Guide
Processors
®
13
