Note: For easy Device ID and Key entry, scan the QR code on the yellow key card included with your
device. Then copy and paste data into the console. With the QR code, the first line is the Device ID and
the rest is the key.
8. Select the model from the Device Type drop down. Model is on the device label.
9. Set the Join EUI to 7894E80000000000 and click Continue.
10. Review the summary and click Confirmation.
The console shows complete when the device is successfully added.

Mounting the Sensor

To mount the sensor:
Use the large adhesive pad included with a sensor to secure the case in position.

Mounting the Sensor with the Tamper Screw

For increased security, open the case, and fasten it to the wall using the included tamper screw as shown. Then
reassemble the case. The tab will break away and send a tamper alert if the case is forcibly removed.
1. Open the case. To do this, use a pen or similar object to press the button on the opposite side of the
case.
2. Stick the adhesive pad where you want to install the sensor.
3. Attach the case over the adhesive using the included tamper screw as shown.
4. Reassemble the case.
The tab will break away if the case is forcibly removed. If you enabled the sensor's tamper option, the sensor sends
a tamper alert. (Note: Tamper switches are disabled by default.)
®
