  • Page 1 Door Window Sensor User Guide...
  • Page 2 Trademarks and Registered Trademarks MultiTech, the MultiTech logo, DeviceHQ, xDot, and Conduit are registered trademarks and Reveal and mDot are trademarks of Multi-Tech Systems, Inc. All other products and technologies are the trademarks or registered trademarks of their respective holders.
  • Page 3: Table Of Contents

    CONTENTS Contents Chapter 1 – Quick Start............................4 Sensor Overview ................................4 Part Numbers ................................4 Documentation ................................4 Chapter 2 – Preparing Sensor........................... 5 Preparing an RBS301 Sensor............................5 Preparing an RBS306 Sensor............................5 Quick Start..................................5 Mounting the Sensor ..............................6 Chapter 3 –...
  • Page 4: Chapter 1 - Quick Start

    Outdoor/Industrial LoRaWAN North America, South America RBS306-DWS-EU Outdoor/Industrial LoRaWAN Europe Documentation The following documentation is available at https://www.multitech.com/products/sensors. Document Description Part Number User Guide This document provides overview, safety and regulatory RB00005 information, design considerations, schematics, and general hardware information.
  • Page 5: Chapter 2 - Preparing Sensor

    Console, use the following steps. To use a third-party network, refer to the Connecting Radio Bridge LoRaWAN Sensors on Gateways and Networks (RB00001) , which is available through the sensor page at https://www.multitech.com/products/sensors Create a Radio Bridge console account at: https://console.radiobridge.com/...
  • Page 6: Mounting The Sensor

    PREPARING SENSOR Note: For easy Device ID and Key entry, scan the QR code on the device label. Then copy and paste data into the console. With the QR code, the first line is the Device ID and the rest is the key. Select the model from the Device Type drop down.
  • Page 7 PREPARING SENSOR The tab will break away and send a tamper alert if the case is forcibly removed. Attach the magnet piece to the door so it aligns with the natch on the sensor. Door Window Sensor User Guide...
  • Page 8: Chapter 3 - Hardware Specifications And Information

    Refer to the Sensor Battery Estimator.xlsx spreadsheet on the on the sensor's product page for specific battery life estimates: https://www.multitech.com/products/sensors Battery life depends on the number of transmissions per day. Power required for a message transmission is greater than the “sleep current” for high power radio technologies (e.g, LoRaWAN).
  • Page 9: Mechanical Drawings

    HARDWARE SPECIFICATIONS AND INFORMATION Mechanical Drawings The mechanical drawings provided in this section are for the main body of the sensor. All dimensions use inches unless specified. Indoor RBSx01 Sensors Door Window Sensor User Guide...
  • Page 10: Armored Outdoor/Industrial Rbsx06 Sensors

    HARDWARE SPECIFICATIONS AND INFORMATION Armored Outdoor/Industrial RBSx06 Sensors Door Window Sensor User Guide...
  • Page 11: Chapter 4 - Common Messages

    Sensor Specific Messages chapter. Message Protocol This section defines the protocol and message definitions for the device. Note: MultiTech provides a web-based console at console.radiobridge.com for configuring and monitoring devices. We recommend using this console rather than the protocols defined in this section.
  • Page 12: Reset Message 0X00

    COMMON MESSAGES Message Payload Description 0xfb Link quality Sent after each downlink configuration (refer to Link Quality Message) or to periodically ping the network server (refer to Link Quality Check Period). 0xfe Reserved. 0xff 1-byte status Downlink message ACK. Refer to Downlink ACK for more detail.
  • Page 13: Supervisory Message 0X01

    COMMON MESSAGES Supervisory Message 0x01 Wireless sensors periodically send a supervisory message so the backend system can verify the device is still alive and report error conditions. The supervisory message payload include current sensor status. You can also trigger a supervisory message. To do this: Place a magnet near the triangular notch on the side of the sensor.
  • Page 14: Downlink Messages

    COMMON MESSAGES Bytes Description Current Sub-Band, sub-band currently joined and used for communication to the gateway and network server. Value ranges from 1-8 for US915. For other regions, value depends on available channels. RSSI of last DOWNLINK received, signed integer format values in bytes 1 and 2 in two’s complement format.
  • Page 15 COMMON MESSAGES Radio Config The following table shows the radio config byte definition. Note: Available in firmware version 1.4 or newer. Bits Description Not used (reserved) Enable duty cycle requirement. LoRaWAN EU868 only. To enforce the EU868 band duty cycle requirements, enable before production deployment.
  • Page 16: Advanced Configuration

    COMMON MESSAGES Bit 7:6 Bits 5:0 Sampling period defined in increments of 250ms (0.25-15 seconds). Sampling period defined in increments of seconds (1-63 seconds). Sampling period defined in increments of minutes (1-63 minutes). Sampling period defined in increments of hours (1-63 hours). Advanced Configuration Use this command for advanced configuration parameters that apply to all sensor types.
  • Page 17: Downlink Ack

    COMMON MESSAGES Downlink ACK The cloud app uses this downlink ACK message to verify the that sensor received the downlink message received and it was considered valid. The sensor replies to the downlink data with a 0xFF message (downlink ACK) with the payload shown in the following table.
  • Page 18: Chapter 5 - Sensor-Specific Messages

    SENSOR-SPECIFIC MESSAGES Chapter 5 – Sensor-Specific Messages Uplink Messages The uplink message (sensor to web application) specific to the sensor is defined in following table. The common uplink messages are not included in this section (see common messages document). Event Payload Description 0x00 Sensor is “closed”...
  • Page 19: Chapter 6 - Regulatory Information

    (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Per FCC 15.21, Changes or modifications not expressly approved by MultiTech could void authority to operate the devices.
