VI.k) Factory settings

The controller is pre-configured for operation. However,
the settings should be customized to the user's needs.
Return to factory settings is possible at any time. When
the factory settings option is activated, all customized
settings of fireplace controller are lost and replaced with
the manufacturer's settings. Then, the parameters may
be customized anew.

VI.l) Fitter's menu

Fitter's menu settings should be configured by a qualified person.
VI.l.1) GSM module
NOTE
This type of control is available only after purchasing and connecting an additional
controlling module ST-65 which is not included in the standard controller set.
GSM Module is an optional device which, cooperating with the fireplace controller, enables
the user remote control of the CH boiler operation via mobile phone. The user is sent an
SMS each time an alarm occurs. Moreover, after sending a certain text message, the user
receives feedback on the current temperature of all the sensors. Remote change of the
pre-set temperatures is also possible after the authorisation code is entered.
GSM Module may operate independently of the fireplace controller. It has two
additional inputs with temperature sensors, one contact input to be used in any configuration
(detecting closing/opening of contacts) and one controlled output (e.g. a possibility of
connecting an additional contractor to control any electric circuit).
When any of the temperature sensors reaches the preset maximum or minimum
temperature, the module automatically sends an SMS message with such information.
A similar procedure is used in the case of opening or closing of the contact input,
which may be used as a simple means of property protection.
If the GSM Module is to be used with the ST-391 controller, it should be activated
by selecting ON option (MENU>Fitter's menu>GSM Module>ON).
