NRS Healthcare G21808 User Instructions

G21808
G21819

GENERAL SAFETY WARNING

Please make sure that you read and follow these
instructions carefully. Failure to do so can result
in injury. Keep these instructions in a safe place
for future reference.

INTENDED USE

The Rise Easy Bed Aid is designed to assist the user in rising from, or sitting up in bed, without interfering
with bed clothes. It is available in two sizes and is suitable for most beds including profi ling beds. It can be
used on either the left or right hand side of the bed.

SAFETY

Do not place obstructions (for example a bedside
cabinet) adjacent to the bed rail. It is important that
the arm is free to be moved away from the bed.
Do not use if feet of bed are too large to fi t onto base
plate pads.
It is recommended that this device is only used for
clients up to 127Kg (20st).

MANUAL HANDLING GUIDANCE

During installation, it is necessary to lift the bed
head onto the bed rail base plates. Please ensure
that the person(s) installing the device is capable of
doing this operation safely using the correct manual
handling techniques and employ caution when lifting
the bed.
ASSEMBLY & INSTALLATION INSTRUCTIONS
1. Remove all parts from the packaging. Check all
parts are undamaged.
2. Ensuring there are no obstruction (E.g. Bed side
cabinet) on the side which the client will exit the
bed; move the bed approximately 300mm (12")
from the wall
3. Place the 2 base plate sections on the fl oor
and push both silver coloured connecting rods
into both tubes on base plates to the bed size
required.
Note: Do not pull past the warning dimples.
4. Slide assembly behind the head section of the
bed and align base plates to bed castors/feet.
USER INSTRUCTIONS
RISE EASY BED AID
Single 762mm (30") to 1220mm (48")
Double1372mm (54") to 1525mm (60")
5. Lift the bed and slide assembly under the
castors/feet of the bed. Lower bed onto the
base plate ensuring the castors/feet sit onto the
base plate. Carefully move the bed/Base plate
assembly back to the wall.
6. The hand rail may now be fi tted on the
appropriate side of the bed. Slide the handrail
over the location tube and push down until it hits
the location stop pin.
7. Check that the bed rail feels secure and can be
swung away from the bed.
Hand
Rail
Location Tube
Stop Pin
Diagram 1: Installation Diagram
1

MAXIMUM USER WEIGHT

20st
127kg
Warning
Dimples
Connecting Rod
(x2 - Silver)
Base Plate
